Pepperl+Fuchs KCD2-SCS-Ex2.SP System Manual page 50

K-System – Isolated Barriers
Technical Specifications
Housing Type E
Figure 7.7
Housing Power Supply 4 A
Figure 7.8
50
40 mm
Dimensions (W x H x D): 40 x 93 x 115 mm (1.6 x 3.7 x 4.5 inch)
99 mm
88 mm
Dimensions (W x H x D): 140 x 99 x 103,5 mm (5.5 x 3.9 x 4.1 inch)
115 mm
140 mm
Primary Secondary
PE L1 N
+ -
