Function

Isolated barriers are isolators used for protection of intrinsically safe circuits in hazardous
areas. In addition to the required current, voltage and power limitation, the isolated barriers
have a galvanic isolation between the field circuit and the controller.
Figure 2.1
The K-System consists of wide range of isolated barriers suitable for mounting on 35 mm
DIN mounting rail. K-System is easy to specify, integrate and expand. Our extensive line
of intrinsic safe isolators for hazardous location applications contains over 150 different
devices.
Figure 2.2
Sensor
Actuator
Function – isolating, amplifying and transforming signals
K-System on Power Rail
Control
system
