Product Specifications
Figure 2.5
Transparent Front Flap
The KC and KF devices have a transparent front flap.
Figure 2.6
This front flap has several functions:
•
Protection of the device against electrostatic discharge
•
Protection of the operating elements from pollution, see chapter 2.6
•
Integrated label carrier for individual labeling, see chapter 2.7
FLT
OUT
RS232
KF device housing (40 mm)
Transparent front flap for KC and KF devices, example
