For your safety

2
2.1

Notes on the use of these operating instructions

Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
•
Safety notes include the "DANGER" keyword in the heading with a general warning symbol.
•
The hazard is also highlighted using a symbol on the edge of the page.
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
•
Safety notes include the "WARNING" keyword in the heading with a general warning
symbol.
•
The hazard is also highlighted using a symbol in the page margin.
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
•
The safety information includes the "CAUTION" keyword in its heading with a general
warning symbol.
•
The risk is explained using a symbol on the edge of the page.
Technical aspects which the user must observe to avoid material or equipment damage.
Instructions and lists detailing step-by-step actions for given situations can be recognised via bullet
points, e.g.:
•
Insert the welding current lead socket into the relevant socket and lock.
2.2

Explanation of icons

Symbol Description
Indicates technical aspects which the
user must observe.
Switch off machine
Switch on machine
Incorrect / Invalid
Correct / Valid
Input
Navigation
Output
099-0M37XK-EW501
16.07.2018
Notes on the use of these operating instructions
DANGER
WARNING
CAUTION
Symbol Description
Activate and release / Tap / Tip
Release
Press and hold
Switch
Turn
Numerical value – adjustable
Signal light lights up in green
Signal light flashes green
Signal light lights up in red
