For your safety

Part of the complete documentation

Symbol Description
Time representation (e.g.: wait 4 s /
actuate)
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use
2.3
Part of the complete documentation
These operating instructions are part of the complete documentation and valid only in
combination with all other parts of these instructions! Read and observe the operating
instructions for all system components, especially the safety instructions!
The illustration shows a general example of a welding system.
Item
Documentation
A.1
Wire feeder
A.2
Conversion instructions
A.3
Power source
A.4
Cooling unit, voltage converter, tool box etc.
A.5
Trolley
A.6
Welding torch
A.7
Remote control
A.8
Control
A
Complete documentation
6
Symbol Description
Signal light flashes red
Figure 2-1
099-0M37XK-EW501
16.07.2018
