Wiring diagram with T-Harness (THVWN1)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
OBDll Diagnostic
Connector
NOT USED
PKL 2
PKL 1
Headlight Switch
(black connector)
VESCM
(under driver's side dash)
5 933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)
©2023 Directed. All rights
Optional THVWN1
Parking Lights
Key Wrap
NOT USED
Key 1 Ignition 2 PTS
ESCLCM
(black connector under steering column)
VESCM
(brown connector)
42 25 1
28
29 12
(+) Brake:
Black/Red,
pin 17
52 41 24 11
(connector side view)
(-) GWA Output:
Dk.Blue/Black
Starter
Kill
Relay
Refer to the Optional starter
disable connection section for relay
and connection details.
(+) Siren Output:
Brown/Red
(-) Hood Input: Gray
(+) Brake Activation
Output: White
8-pin White Connector
A module can also be used for
Cut the Dk.Blue/Black loop
this installation.
labeled GWA and extend
the wires coming from the
module side.
Extend wire.
22-pin White Connector
IMPORTANT:
Position the
fuses correctly!
12-pin Black Connector
Slide to open
Legend:
Siren
Hood Pin
NOT USED
PKL 3 Key 2
6
).
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
Key 3
