Directed Directechs DS3+ Installation Manual page 12

Module
Conn./Pin Color Description
H2/17 Black/White No Connection
H2/18 Orange/Black No Connection
H2/19 Blue No Connection
H2/20 Green No Connection
H2/21 Gray
(-) Hood Switch Input
H2/22 Violet/White No Connection
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. Parking Lights Interrupt (connector side)
H3/2 Blue/Red Relay N.O. (+) Parking Lights Output
H3/3 Blue Relay COM. Parking Lights Interrupt (Vehicle side)
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM. No Connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red
Relay N.O. Key Wrap
H3/8 Lt. Green
Relay COM. Key Wrap
H3/9 Lt. Green/White
Relay N.C. Key Wrap
H3/10 Black (-) Ground
H3/11 White Relay COM. No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black No Connection
H4/3 Pink/Black No Connection
H4/4 Pink/White No Connection
H4/5 Red No Connection
H4/6 Green No Connection
H4/7 Violet No Connection
H4/8 Orange No Connection
H4/9 Red/White No Connection
12 933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)
©2023 Directed. All rights
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
[1] The installation of an aftermarket hood pin is ONLY required on vehicles
that are NOT equipped with a factory hood pin or if not supported in
data.
No Connection
Connects To
Wire Location
Headlight Switch, black 10 pin plug, pin 8
Headlight Switch, black 10 pin plug, pin 3
Headlight Switch, black 10 pin plug, pin 8
No Connection
No Connection
VESCM under driver dash, brown 52 pin plug, pin 42
[3] Immobilizer Reader Coil in steering column, black 2 pin plug, pin 1
[3] Immobilizer Reader Coil in steering column, black 2 pin plug, pin 1
[3] Immobilizer Reader Coil in steering column, black 2 pin plug, pin 1
No Connection
VESCM under driver dash, brown 52 pin plug, pin 42
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
Cut Red/Yellow or Red/White Mandatory
+ Gray/Yellow Mandatory
Cut Red/Yellow or Red/White Mandatory
+ Red/Yellow (40A) Mandatory
RF Blue Remote Start
Only
RF Blue Remote Start
Only
RF Blue Remote Start
Only
(chassis ground) Mandatory
+ Red/Yellow (40A) Mandatory
(+/-) Wire Color Connection
