MAINTENANCE: SHELF ASSEMBLY REMOVAL

1. Shelf Assembly Removal
• For lighted shelving, unplug the light cord.
• Light shelf cord harnesses plug into the
back side of the header electrical box.
• Detach cord from the rear frame support.
• Slide light assembly back to unlock, then rotate
up to separate from brackets.
• Slide rear support back to unlock and rotate up
to separate from brackets.
• Remove brackets.
• Note: It may be necessary to remove the
nylon shipping bracket retainers. Pliers will
be required to accomplish this task.
Shelf Supports
Shelf Bracket
Shelf Light
Bracket
Retainers
Tray (Optional)
Separately
Purchased
