SELF-SERVICE FLOOR MODEL UNITS
Models: CSF3931
39"L x 73 1/4"H* x 31"D
CSF4231
42"L x 73 1/4"H* x 31"D**
* Includes Top Sign
** Without Package Ledge. 36 1/2"D With Package Ledge.
I:\Oper Manuals\Addenda\CSF[L]31_99696.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
OPERATING MANUAL
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts
Model Shown With
Optional Upper Signage
PN 99696
Rev B Date: 8.27.2007
Advertisement
Table of Contents
Related Manuals for Structural Concepts Addenda CSF3931
Summary of Contents for Structural Concepts Addenda CSF3931
- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION & OPERATING MANUAL PN 99696 SELF-SERVICE FLOOR MODEL UNITS Model Shown With Optional Upper Signage Models: CSF3931 39”L x 73 1/4”H* x 31”D CSF4231 42”L x 73 1/4”H* x 31”D** * Includes Top Sign ** Without Package Ledge.
-
Page 2: Table Of Contents
TABLE OF CONTENTS OVERVIEW AND WARNINGS ……………………..…………………..…….…………..…..……… INSTALLATION ………….………………………………………………………………………………… START-UP AND OPERATION ……….. …..….…………………...………...…..……………………… MAINTENANCE FUNDAMENTALS ………………………….………………………………..…..SERIAL LABEL & LOCATION / INFORMATION LISTED / ADD’L TECH INFO & SERVICE ..…… TROUBLESHOOTING ……………….……………………………………………….………….……….. ILLUSTRATED PARTS BREAKDOWN …………………………………………………….…...……… PARTS LIST ……………..…………………………………………………………………………………... -
Page 3: Overview And Warnings
OVERVIEW AND WARNINGS OVERVIEW • This merchandiser is designed for the display of non-hazardous, unpackaged bakery products. • These cases should be installed and operated according to the following instructions to insure proper performance. • This unit is designed for the display of products in ambient store conditions where temperatures and humidity are maintained at a maximum of 75°... -
Page 4: Installation
INSTALLATION Remove Unit From Skid • Position the unit near a suitable electrical outlet. • Caution: case must always remain supported or center of gravity imbalance will cause case to fall. • Slide unit to rear of skid and tip backward off skid. Position and Level Units For your safety, equipment is furnished with a properly grounded cord connector. -
Page 5: Start-Up And Operation
START-UP AND OPERATION For your safety, equipment is fur- nished with a properly grounded cord connector. Do not attempt to defeat the grounded connector. Internal Light Switch Merchandiser Start-Up • Do not use an extension cord with this appliance. • Do not operate this equipment with a damaged cord, plug or outlet. -
Page 6: Maintenance Fundamentals
MAINTENANCE FUNDAMENTALS Shelf Assembly Removal • Shelves can be removed for repositioning, removal (for individual merchandising re- quirements) and cleaning. • Slide the front shelf support back rotate up and lift straight up to separate from brackets. • Slide the rear shelf support back rotate up Bracket and lift straight up to separate from brackets. - Page 7 MAINTENANCE FUNDAMENTALS Light Fixtures Light fixtures are located on the sides of each door assembly, both sides (just in- side doors). • Open the door all the way. • Access lamp by removing the lamp cover/diffuser. • Apply gentle squeezing pressure to lamp cover;...
-
Page 8: Serial Label & Location / Information Listed / Add'l Tech Info & Service
• For additional technical information and service, see the TECHNICAL SERVICE page in this manual for instructions on contacting Structural Concepts’ Technical Service Department. • See images below for samples of both refrigerated and non-refrigerated serial labels. -
Page 9: Troubleshooting
TROUBLESHOOTING Case Lights Not Working Check bulbs for proper installation and connection. Check for burned out bulbs. Confirm the utility power is on. System is not Operating Check the circuit breaker box for tripped circuits. -
Page 10: Illustrated Parts Breakdown
ILLUSTRATED PARTS BREAKDOWN... -
Page 11: Parts List
PARTS LIST PARTS LIST Sign Upright Tube Light Assembly Acrylic Sign, Side Acrylic, End Glass Shelf Assembly Acrylic, Top Glass Tissue Holder Acrylic Sign Front End Panel Shelf Support Front Knob, Front Panel / Storage Door Shelf Support Rear Mid-Shelf Shelf Bracket Front Panel / Storage Door Bulb... -
Page 12: Cleaning Schedule
CLEANING SCHEDULE Cleaning Daily Weekly Monthly Task Clean all case exterior surfaces with a house- Clean Case Exterior hold or commercial glass cleaner and a soft cloth. Clean the interior case deck and shelving Clean Case Interior surfaces with a warm water and mild soap solution. -
Page 13: Warranty
WARRANTY All sales by Structural Concepts Corporation (SCC) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty; Remedies; Limitations. SCC warrants that if any Goods are found by an authorized representative of SCC not to be of good material or workmanship within one year of the date of shipments SCC will, at its option after inspection by an authorized representative, replace any defective Good or pay the reasonable cost of replacement for any such defective Goods, provided that written notice of the defect is given to SCC within 30 days of the appearance of such defect. -
Page 14: Technical Service
TECHNICAL SERVICE STRUCTURAL CONCEPTS CORPORATION TECHNICAL SERVICE DEPARTMENT 1.800.433.9489 888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts...
