ET-2200 Series Ethernet I/O
Modules User Manual
Ethernet I/O Module
W
ARRANTY
All products manufactured by ICP DAS are warranted
against defective materials for a period of one year from
the date of delivery to the original purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent to
the use of this product. ICP DAS reserves the right to
change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate
and reliable. However, no responsibility is assumed by ICP
DAS for its use, nor for any infringements of patents or
other rights of third parties resulting from its use.
C
OPYRIGHT
Copyright © 2016 by ICP DAS. All rights are reserved.
T
RADEMARK
Names are used for identification only and may be
registered trademarks of their respective companies.
C
U
ONTACT
S
If you have any questions, please feel free to contact us via
email at:
service@icpdas.com, service.icpdas@gmail.com
Ver. 1.1.3 Feb. 2016
S
UPPORT
This manual relates to the following
modules:
ET-2242, ET-2251, ET-2254, ET-2254P,
ET-2255 , ET-2260, ET-2261 and
ET-2268

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ET-2242 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP DAS USA ET-2242

Summary of Contents for ICP DAS USA ET-2242

  • Page 1 This manual relates to the following Copyright © 2016 by ICP DAS. All rights are reserved. modules: RADEMARK ET-2242, ET-2251, ET-2254, ET-2254P, Names are used for identification only and may be ET-2255 , ET-2260, ET-2261 and registered trademarks of their respective companies.

  • Page 2: Table Of Contents

    ................................. 9 PPEARANCE ..............................11 PECIFICATION 2.2.1 System Specification ............................11 2.2.2 I/O Specification ............................... 12 2.2.2.1 ET-2242 ..................................12 2.2.2.2 ET-2251 ..................................12 2.2.2.3 ET-2254/2254P ................................13 2.2.2.4 ET-2255 ..................................14 2.2.2.5 ET-2260 ..................................15 2.2.2.6 ET-2261 ..................................16 2.2.2.7 ET-2268 ..................................
  • Page 3 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules ..........................33 OGGING IN TO THE ERVER ................................35 ................................36 ETWORK 4.3.1 IP Address Configuration ..........................36 4.3.1.1 Dynamic Configuration ............................... 38 4.3.1.2 Manual Configuration ..............................
  • Page 4 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.5 05(0x05) Force a Single Coil (Write DO) ......................84 6.2.6 06(0x06) Preset a Single Register (Write AO) ....................86 6.2.7 15(0x0F) Force Multiple Coils (Write DOs) ......................88 6.2.8 16(0x10) Preset Multiple Registers (Write AOs) ....................

  • Page 5: Introduction

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 1. Introduction The ET-2200 series modules, a IP-based Ethernet I/O module, features a built-in web server which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. In addition, the ET-2200 also supports Modbus TCP/UDP protocol that makes perfect integration to SCADA software.
  • Page 6 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4. Built-in Multi-function I/O  All Digital Output modules provide: A Power-on Value (On boot up, the digital output value is set as the Power-on value) ...
  • Page 7 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  DIO Synchronization (Mirror Local DI to DO): ET-2200 series modules also provide a DIO synchronization function. The DIO synchronization is divided into three modes: Level Sync, Rising Active and Falling Active.
  • Page 8 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6. Daisy-chain Ethernet Cabling The ET-2200 has a built-in two-port Ethernet switch to implement daisy-chain topology. The cabling is much easier and total costs of cable and switch are significantly reduced.

  • Page 9: Hardware Information

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2. Hardware Information 2.1 Appearance The front panel and top panel of the ET-2200 module contain the I/O connector, LEDs, Ethernet Port and power connector.
  • Page 10 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules I/O Connector For more detailed information regarding the pin assignments for the I/O connector, refer to Section 2.3 Pin Assignments DC Power Input Connector The definition for +Vs and GND for use as the power supply applies to all types of ET-2200 series module.

  • Page 11: Specification

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2 Specification 2.2.1 System Specification Model ET-2242 ET-2251 ET-2254(P) ET-2255 ET-2260 ET-2261 ET-2268 System 32-bit ARM Communication Ethernet Port 2 x RJ-45, 10/100 Base-Tx, switch Ports...

  • Page 12: I/O Specification

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2 I/O Specification 2.2.2.1 ET-2242 Model ET-2242 Digital Output Channels Type Open collector Sink/Source (NPN/PNP) Sink Load Voltage +3.5 V ~ +50 V PASS Max.

  • Page 13: 2254/2254P

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2.3 ET-2254/2254P Model ET-2254 ET-2254P I/O Type By Wire Connection, Configurable Universal DIO I/O Channels Digital Input Type Dry Contact Sink/Source (NPN/PNP) Source On Voltage Level Close to GND...

  • Page 14: 2255

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2.4 ET-2255 Model ET-2255 Digital Input/Counter Channels Contact Wet Contact Sink/Source (NPN/PNP) Sink/Source +5 V ~ +50 V On Voltage Level Off Voltage Level +1 V Max.

  • Page 15: 2260

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2.5 ET-2260 Model ET-2260 Digital Input/Counter Channels Contact Wet Contact Sink/Source (NPN/PNP) Sink/Source +5 V ~ +50 V On Voltage Level Off Voltage Level +3.5 V Max.

  • Page 16: 2261

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2.6 ET-2261 Model ET-2261 Power Relay Channels Type Power Relay, Form A (SPST N.O.) 5 A @ 250 V /24 V (Resistive Load) Contact Rating Min.

  • Page 17: 2268

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.2.2.7 ET-2268 Model ET-2268 Relay Output Channels 8 (Form A x 4, Form C x 4) Relay Type Signal Relay 2 A @ 30 V Contact Rating 0.24 A @ 220 V 0.25 A @ 250 V...

  • Page 18: Pin Assignments

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.3 Pin Assignments 2.3.1 ET-2242 2.3.2 ET-2251 Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 18 -...

  • Page 19: 2254/2254P

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.3.3 ET-2254/2254P 2.3.4 ET-2255 Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 19 -...

  • Page 20: 2260

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.3.5 ET-2260 2.3.6 ET-2261 Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 20 -...

  • Page 21: 2268

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.3.7 ET-2268 Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 21 -...

  • Page 22: Wiring Connections

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.4 Wiring Connections 2.4.1 Input Wiring  Input Wiring for the ET-2251/2255/2260: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 22 -...

  • Page 23: Output Wiring

    +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  Input Wiring for the ET-2254/2254P: 2.4.2 Output Wiring  Output Wiring for ET-2242/2254/2254P/2255:  Output Wiring for ET-2260/2261: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 23 -...
  • Page 24 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  Output Wiring for ET-2268: Note for the ET-2260/2261/2268: When inductive loads are connected to the relays, a large counter electromotive force may occur when the relay actuates because of the energy stored in the load.

  • Page 25: Wiring To The Connector

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.5 Wiring to the Connector  Insulated Terminals Dimensions: Dimensions (Unit: mm) Item NO. CE007512 12.0 18.0  A tip for connecting the wire to the connector 2.

  • Page 26: Dimensions

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 2.6 Dimensions The following diagrams provide the dimensions of the ET-2200 series module and can be used as a reference when defining the specifications for any custom enclosures. All dimensions are in millimeters.

  • Page 27: Getting Started

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 3. Getting Started This chapter provides a basic overview of how to configure and operate your ET-2200 series module. 3.1 Configuring the Boot Mode The ET-2200 series modules have two operating modes that can be selected by using the switch mechanism incorporated on the chassis.

  • Page 28: Connecting The Power And The Host Pc

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 3.2 Connecting the Power and the Host PC Step 1: Connect both the ET-2200 module and the Host PC to the same sub network or the same Ethernet Switch Ensure that the network settings on the Host PC have been correctly configured and are functioning normally.

  • Page 29: Configuring The Network Settings

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 3.3 Configuring the Network Settings Step 1: Get the eSearch Utility The eSearch Utility can be obtained either from the companion CD at: CD:\Napdos\Software\eSearch\ Or from the ICP DAS web site at: http://ftp.icpdas.com/pub/cd/tinymodules/napdos/software/esearch/...
  • Page 30 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 4: Once the search process in complete, double-click the name of the ET-2200 Co figure “er er UDP module to open the dialog box Factory Default Settings for the ET-2200 Series, as follows:...

  • Page 31: Modbus Tcp Testing

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 6: Wait for 2 seconds and then click the Search Servers button again to ensure that the ET-2200 module is operating correctly using the new configuration 3.4 Modbus TCP Testing Step 1: In the eSearch Utility, Select the Modbus TCP Master...
  • Page 32 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 2: Enter the IP address TCP Port information for the ET-2200 module in the Modbus TCP section, and then click the Connect button to connect to the ET-2200.

  • Page 33: Web Configuration

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4. Web Configuration All ET-2200 series module contain an advanced embedded web configuration system that provides I/O accessibility to the ET-2200 series module via a web browser. 4.1 Logging in to the Web Server You can access the embedded ET-2200 series web server from any computer that has an Internet connection.
  • Page 34 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 3: Enter the password Once the login screen is displayed, enter the password in the login password field (use the default pass ord Admin ), and then click the “u it button to enter the configuration web page.

  • Page 35: Home

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.2 Home Clicking the Home tab will display to the main Status & Configuration page, which is divided into three sections. The first section provides basic information related to the ET-2200 series module hardware and software including items: The Model Name, Firmware version, IP Address, Initial Switch position, Alias Name, MAC Address, and the TCP Port and System Timeout values.

  • Page 36: Network

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.3 Network Clicking the Network tab will display the IP Address Configuration page allowing you verify the current settings and configure the IP Address parameters, configure the general parameters and restore the default settings for the ET-2200 series module, each of which will be described in more detail below.
  • Page 37 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Item Description Static IP: If there is no DHCP server installed in your network, you can configure the network settings manually. Refer to Section 4.3.1.2 Ma ual Co figuratio for more details.

  • Page 38: Dynamic Configuration

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.3.1.1 Dynamic Configuration Dynamic configuration is very easy to perform. If a DHCP server is connected to you network, a network address can be dynamically configured by using the following procedure: Step 1: Select DHCP from the Address Type drop-down menu.

  • Page 39: General Settings

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.3.2 General Settings The following table provides an overview of the parameters contained in the General Settings section: Item Description This parameter is used to set the Ethernet speed. The default value is Ethernet Speed Auto (Auto = 10/100 Mbps Auto-negotiation).

  • Page 40: Restore Factory Defaults

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.3.3 Restore Factory Defaults  Restore all options to their factory default states To reset all parameters to their original factory default settings, use the following procedure: Step 1: Click the Restore Defaults button to reset the configuration.
  • Page 41 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  Forced Reboot The Forced Reboot function: can be used to force the ET-2200 module to reboot or to remotely reboot the device. After the ET-2200 module has rebooted, the original login screen will be displayed requesting that you enter your Login Password before continuing.

  • Page 42: Firmware Update

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.3.4 Firmware Update For detailed information about how to remote update the Firmware for the ET-2200 module, refer to the ET-2200_Firmware_Update_vxxx_en.pdf. The location of the user manual on the CD and the download address are shown below: CD:\\ NAPDOS\ET2200\Firmware\ http://ftp.icpdas.com/pub/cd/6000cd/napdos/et2200/firmware/ Copyright ©...

  • Page 43: I/O Settings

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.4 I/O Settings Clicking the I/O Settings tab will display the DO Control and DI/DO Configuration page allowing you configure the Digital Input and Digital Output parameters for the ET-2200 series module. This page including Digital Output control, DI/DO Configuration, etc., each of which will be described in more detail below.

  • Page 44: Di/Do Configuration

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.4.2 DI/DO Configuration The following table provides an overview of the parameters contained in the DI/DO Configuration section: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 44 -...
  • Page 45 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Item Description Digital Output This parameter is used to configure the Host Watchdog timeout value. If Host Watchdog Timeout there is no Modbus TCP communication activity for the specified period (Seconds) (the timeout), then the Host Watchdog will activate an alarm.
  • Page 46 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules This parameter is used to define the scan mode for the frequency measurement. 1000 ms: This mode provides a normal update rate and normal accuracy. The acceptable frequency range for the input signal is 1 Hz to 3 kHz (±...

  • Page 47: Sync

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.5 Sync Clicking the Sync tab will display the DIO Synchronization page allowing you configure the Synchronous DIO, Min-switching time of DO and Auto-off Time of DO for the ET-2200 series module, each of which will be described in more detail below.
  • Page 48 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Item Description Synchronous DIO (Local Mirror) Note: The ET-2254 supprots these functions when low 8-bit are DI0 to DI7 and high 8-bit are DO8 to DO15.

  • Page 49: Pwm

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.6 PWM Clicking the PWM tab will display the PWM Configuration page allowing you enable and configure the PWM parameters for the ET-2200 series module, including the PWM Alarm and duty cycle, etc., each of which will be described in more detail below.
  • Page 50 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Item Description Default Value Enable PWM This parameter is used to enable the PWM output function. This parameter is used to enable the PWM output alarm Enable PWM Alarm function when Host/Slave watchdog timeout.

  • Page 51: Pair Connection

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.7 Pair Connection Clicking the Pair tab will display the I/O Pair Connection Settings page allowing you enable and configure the DI-to-DO pair connections for the ET-2200 series module, which will be described in more detail below.
  • Page 52 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Item Description Default This parameter is used to define the Server mode for the ET-2200 series module. Mode = Disable: Server mode (Slave). Mode = POLL: Poll remote DI to local DO in the Client mode Mode Disable...
  • Page 53 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules For POLL mode, this parameter specifies the base address of the Local DO register that will be mapped to the Remote DI device.

  • Page 54: Filter

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.8 Filter Clicking the Filter tab will display the Filter Settings page allowing you configure the IP Filter list for the ET-2200 series module, which will be described in more detail below. 4.8.1 Filter Settings The Filter Settings page is used to query or edit the IP Filter List (Available IP) for the ET-2200 series module.
  • Page 55 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules The following table provides an overview of the parameters contained in the IP Address Configuration section: Item Description Add IP to the List This parameter is used to add an IP address to the Available IP List.

  • Page 56: Monitor

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.9 Monitor After clicking the Monitor tab, the Current Connection Status page will be displayed showing detailed information regarding the current status of the serial port connection settings for the ET-2200 series module.

  • Page 57: Change Password

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.10 Change Password After clicking the Password tab, the Change Password page will be displayed. To change a password, first enter the old password in the Curre t pass ord field (use the default password Ad i ) and then enter a new password in the Ne pass ord field.

  • Page 58: Logout

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 4.11 Logout Clicking the Logout tab will immediately log you out from the system and return you to the login page. Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 58 -...

  • Page 59: I/O Pair Connection Applications

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 5. I/O Pair Connection Applications The ET-2200 series modules can be used to create DI-to-DO pair connections via the Ethernet. Once the configuration is complete, the modules can then poll the status of the local DI channels and then use the Modbus/TCP protocol to continuously write to a remote DO device in the background.
  • Page 60 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 2: Configure the Ethernet Settings Contact your Network Administrator to obtain the correct network configuration information for the ET-2200 series modules (e.g., ET-2260 #1 and #2), such as the IP Address, Subnet Mask, and Gateway details.

  • Page 61: Polling Mode

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 3. Click the Pair Co e tio tab to display the I/O Pair-connection Settings page. Figure 5-1.4 5.1.1 Polling Mode 4. In the I/O Pair-connection Settings , select POLL fro the Mode drop-down options. 5.

  • Page 62: Push Mode

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 5.1.2 Push Mode 4. In the I/O Pair-connection Settings , select PUSH fro the Mode drop-down options. 5. Enter the IP address for ET-2260 #2 module in the Remote IP field. 6.

  • Page 63: Two Modules Pushing The Local Di To Each Other (1-To-1, Push Mode)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 5.2 Two Modules Pushing the Local DI to each other (1-to-1, Push Mode) Step 1: Connect the device to a Network, a PC and a Power supply. Getti g Confirm that the ET-2200 series modules are functioning correctly.
  • Page 64 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #1 module and then click the Web browser program and connect to the web server.
  • Page 65 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #2 module and then click the Web browser program and connect to the web server.

  • Page 66: Several Modules Polling The Remote Di (M-To-1) (Polling Mode)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 5.3 Several Modules Polling the Remote DI (M-to-1) (Polling Mode) Step 1: Connect the device to a Network, a PC and a Power supply. Confirm that the ET-2200 series modules and remote slave device are functioning correctly.
  • Page 67 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #1 module and then click the Web browser program and connect to the web server.
  • Page 68 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #2 module and then click the Web browser program and connect to the web server.

  • Page 69: Several Modules Pushing The Local Di (M-To-1) (Push Mode)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 5.4 Several Modules Pushing the Local DI (M-to-1) (Push Mode) Step 1: Connect the device to a Network, a PC and a Power supply. Confirm that the ET-2200 series modules and remote slave device are functioning correctly.
  • Page 70 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #1 module and then click the Web browser program and connect to the web server.
  • Page 71 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module utto to lau h the 1. In the eSearch Utility, select ET-2260 #2 module and then click the Web browser program and connect to the web server.

  • Page 72: Modbus Information

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6. Modbus Information The ET-2200 series is a family of IP-based Modbus I/O devices that allow you to remotely control DI/DO terminals via an Ethernet connection and uses a master-slave communication technique in which only one device (the master) can initiate a transaction (called queries), while other devices (slaves) respond by either supplying the requested data to the master, or by taking the action requested in the query.

  • Page 73: Modbus Message Structure

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2 Modbus Message Structure Modbus devices communicate using a master-slave (client-server) technique in which only one device (the master/client) can initiate transactions (called queries). The other devices (slaves/servers) respond by either supplying the requested data to the master, or by taking the action requested in the query.
  • Page 74 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  RTU Data Structure Byte 06 Byte 07 Bytes 08 - 09 Bytes 10 - 11 Data Field Net ID Function Code Reference Number (Station Number) Number of Points...
  • Page 75 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Data Field Data is transmitted in 8-, 16- and 32-bit format. The data for 16-bit registers is transmitted in high-byte first format. For example: 0x0A0B ==> 0x0A, 0x0B. The data for 32-bit registers is transmitted as two 16-bit registers, and is low-word first.

  • Page 76: 0X01) Read The Status Of The Coils (Readback Dos)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.1 01(0x01) Read the Status of the Coils (Readback DOs) This function code is used to read either the current status of the coils or the current digital output readback value from the ET-2200 series module.
  • Page 77 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 01 (0x01), Readback Dos  Reads the Digital Output value [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 01 00 00 00 02 [Leading 6 bytes] [Response]...

  • Page 78: 0X02) Read The Status Of The Input (Read Dis)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.2 02(0x02) Read the Status of the Input (Read DIs) This function code is used to read the current digital input value from the ET-2200 series module. [Request] Byte Description...
  • Page 79 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 02 (0x02), Read DIs  Reads the Digital Input value [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 02 00 00 00 02 [Leading 6 bytes] [Response]...

  • Page 80: 0X03) Read The Holding Registers (Readback Aos)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.3 03(0x03) Read the Holding Registers (Readback AOs) This function code is used to readback either the current values in the holding registers or the analog output value from the ET-2200 series module.
  • Page 81 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 03 (0x03), Read AOs  Reads the name of the module for the ET-2260 [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 03 01 03 00 01 [Leading 6 bytes] [Response]...

  • Page 82: 0X04) Read The Input Registers (Read Ais)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.4 04(0x04) Read the Input Registers (Read AIs) This function code is used to read either the input registers or the current analog input value from the ET-2200 series module.
  • Page 83 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 04 (0x04), Read AIs  Reads the number of the DI channels on the ET-2260 [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 04 00 64 00 01 [Leading 6 bytes]...

  • Page 84: 0X05) Force A Single Coil (Write Do)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.5 05(0x05) Force a Single Coil (Write DO) This function code is used to set the status of a single coil or a single digital output value for the ET-2200 series module.
  • Page 85 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 05 (0x05), Write DO  Sets channel DO1 to ON [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 05 00 01 FF 00 [Leading 6 bytes] [Response]...

  • Page 86: 0X06) Preset A Single Register (Write Ao)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.6 06(0x06) Preset a Single Register (Write AO) This function code is used to set a specific holding register to store the configuration values for the ET-2200 series module.
  • Page 87 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 06 (0x06), Write AO  Sets the system timeout to 60 seconds [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 06 01 08 00 3C [Leading 6 bytes] [Response]...

  • Page 88: 0X0F) Force Multiple Coils (Write Dos)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.7 15(0x0F) Force Multiple Coils (Write DOs) This function code is used to set multiple coils status or write multiple digital output values for the ET-2200 series module.
  • Page 89 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 15 (0x0F), Write DOs  Sets the safe value (DO0 ~ DO1) [Leading 6 bytes] [Request] Command: 01 02 00 00 00 08 01 0F 01 0B 00 02 01 03 [Leading 6 bytes] [Response]...

  • Page 90: 0X10) Preset Multiple Registers (Write Aos)

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.2.8 16(0x10) Preset Multiple Registers (Write AOs) This function code is used to set multiple holding registers that are used to store the configuration values for the ET-2200 series module.
  • Page 91 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules Example: Function 16 (0x10), Write AOs  Sets the preset value for the digital counter [Leading 6 bytes] [Request] Command: 01 02 00 00 00 0B 01 10 00 32 00 01 02 03 E8 00 00 [Leading 6 bytes] [Response]...

  • Page 92: Modbus Register Table

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 6.3 Modbus Register Table Data from 16-bit registers is transmitted in high-byte first order. For example: 0x0A0B ==> 0x0A, 0x0B. Data from 32-bit registers is transmitted as two 16-bit registers, and is in low-word first order. For example: 0x0A0B0C0D ==>...
  • Page 93 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  4xxxx: AO Address (Base 0) Starting Bits per Access Points Description Range Address Point Type 1 = Reset at Power-on 2 = Reset by the WDT CPU Reset Status (0xFF) 3 = Reset using the reset...

  • Page 94: Specific Functions

    The nDI and nDO parameters for each ET-2200 series module used in the following Modbus Address Tables are as follows: Universal DIO Number of DO channels Number of DI channels Model Name (UDIO) (nDO) (nDI) ET-2242 ET-2251 ET-2254 Depend on your Depend on your ET-2254P configuration configuration ET-2255...
  • Page 95 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules 0 = Disable Enables frequency measurement for all 1 to nDI 1 = Enable R/W/F (0xBE) DI Channels (Default= 0) 0 = Off Sets the Power-on value for all DO 1 to nDO 1 = On...
  • Page 96 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  1xxxx: DI Address (Base 0) Starting Bits per Access Points Description Range Address Point Type The status of all Digital Input 0 = Off 1 to nDI (0x00)
  • Page 97 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  3xxxx: AI Address (Base 0) Starting Bits per Access Points Description Value Address Point Type 0 to 1 to nDI The Digital Counter Value (0x10) 4294967296 The frequency Value * 1,000.
  • Page 98 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules  4xxxx: AO Address (Base 0) Starting Bits per Access Points Description Range Address Point Type The preset value for the high speed 0 to 1 to nDI R/W/E...
  • Page 99 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ET-2200 Series Ethernet I/O Modules The Min-Switching Time for all DO 1 to 65535 1 to nDO R/W/F (0x10C) Channels second The Auto-off Time for all DO 1 to 65535 1 to nDO R/W/F...
