ET-2200 Series Ethernet I/O

Modules User Manual

Ethernet I/O Module

ARRANTY

All products manufactured by ICP DAS are warranted

against defective materials for a period of one year from

the date of delivery to the original purchaser.

ARNING

ICP DAS assumes no liability for damages consequent to

the use of this product. ICP DAS reserves the right to

change this manual at any time without notice. The

information furnished by ICP DAS is believed to be accurate

and reliable. However, no responsibility is assumed by ICP

DAS for its use, nor for any infringements of patents or

other rights of third parties resulting from its use.

OPYRIGHT

RADEMARK

Names are used for identification only and may be

registered trademarks of their respective companies.

ONTACT

If you have any questions, please feel free to contact us via

email at:

service@icpdas.com, service.icpdas@gmail.com

Ver. 1.1.3 Feb. 2016

UPPORT

This manual relates to the following

modules:

ET-2242, ET-2251, ET-2254, ET-2254P,

ET-2255 , ET-2260, ET-2261 and

ET-2268

Table of Contents

Need help?

Do you have a question about the ET-2200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ICP DAS USA ET-2200 Series

Page 1 ET-2200 Series Ethernet I/O Modules User Manual Ethernet I/O Module Ver. 1.1.3 Feb. 2016 ARRANTY All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser.
Page 2: Table Of Contents
ET-2200 Series Ethernet I/O Modules ABLE OF ONTENTS INTRODUCTION ..............................5 ................................5 EATURES HARDWARE INFORMATION ..........................9 ................................. 9 PPEARANCE ..............................11 PECIFICATION 2.2.1 System Specification ............................11 2.2.2 I/O Specification ............................... 12 2.2.2.1 ET-2242 ..................................12 2.2.2.2 ET-2251 ..................................12 2.2.2.3 ET-2254/2254P ................................
Page 3 ET-2200 Series Ethernet I/O Modules ..........................33 OGGING IN TO THE ERVER ................................35 ................................36 ETWORK 4.3.1 IP Address Configuration ..........................36 4.3.1.1 Dynamic Configuration ............................... 38 4.3.1.2 Manual Configuration ..............................38 4.3.2 General Settings ............................... 39 4.3.3 Restore Factory Defaults ..........................40 4.3.4 Firmware Update..............................
Page 4 ET-2200 Series Ethernet I/O Modules 6.2.5 05(0x05) Force a Single Coil (Write DO) ......................84 6.2.6 06(0x06) Preset a Single Register (Write AO) ....................86 6.2.7 15(0x0F) Force Multiple Coils (Write DOs) ......................88 6.2.8 16(0x10) Preset Multiple Registers (Write AOs) ....................90 ............................
Page 5: Introduction
ET-2200 Series Ethernet I/O Modules 1. Introduction The ET-2200 series modules, a IP-based Ethernet I/O module, features a built-in web server which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. In addition, the ET-2200 also supports Modbus TCP/UDP protocol that makes perfect integration to SCADA software.
Page 6 'off' time. Consequently, it is not necessary to keep switching from ON to OFF from a remote controller. In this way, the ET-2200 series module reduces the complexity required for the control system and enhances timing accuracy.
Page 7 ET-2200 Series Ethernet I/O Modules  DIO Synchronization (Mirror Local DI to DO): ET-2200 series modules also provide a DIO synchronization function. The DIO synchronization is divided into three modes: Level Sync, Rising Active and Falling Active. Level Sync (DO = DI) Mode: The synchronization operation in DI and DO.
Page 8 ET-2200 Series Ethernet I/O Modules 6. Daisy-chain Ethernet Cabling The ET-2200 has a built-in two-port Ethernet switch to implement daisy-chain topology. The cabling is much easier and total costs of cable and switch are significantly reduced. 7. LAN Bypass Bypass feature...
Page 9: Hardware Information
3. I/O Connector 6. 2-port Ethernet Switch PWR LED Indicator Once power is supplied to the ET-2200 series module, the system LED indicator will illuminate. I/O Indicator The exact design and functionality depends on the module type which indicates the I/O status.
Page 10 Electronic circuits are constantly vulnerable to Electrostatic Discharge (ESD), which becomes worse in a continental climate area. ET-2200 series module feature a new design for the frame ground, which provides a path that bypasses ESD, resulting in an enhanced ESD protection capability and ensuring that the module is more reliable.
Page 11: Specification
ET-2200 Series Ethernet I/O Modules 2.2 Specification 2.2.1 System Specification Model ET-2242 ET-2251 ET-2254(P) ET-2255 ET-2260 ET-2261 ET-2268 System 32-bit ARM Communication Ethernet Port 2 x RJ-45, 10/100 Base-Tx, switch Ports Protocol Modbus TCP, Modbus UDP Security Password and IP Filter...
Page 12: I/O Specification
ET-2200 Series Ethernet I/O Modules 2.2.2 I/O Specification 2.2.2.1 ET-2242 Model ET-2242 Digital Output Channels Type Open collector Sink/Source (NPN/PNP) Sink Load Voltage +3.5 V ~ +50 V PASS Max. Load Current 650 mA/Channel PASS Overload Protection 1.4 A (with short-circuit protection)
Page 13: 2254/2254P
ET-2200 Series Ethernet I/O Modules 2.2.2.3 ET-2254/2254P Model ET-2254 ET-2254P I/O Type By Wire Connection, Configurable Universal DIO I/O Channels Digital Input Type Dry Contact Sink/Source (NPN/PNP) Source On Voltage Level Close to GND Off Voltage Level Open Input Impedance 3 kΩ, 0.5 W...
Page 14: 2255
ET-2200 Series Ethernet I/O Modules 2.2.2.4 ET-2255 Model ET-2255 Digital Input/Counter Channels Contact Wet Contact Sink/Source (NPN/PNP) Sink/Source On Voltage Level +5 V ~ +50 V +1 V Max. Off Voltage Level Input Impedance 7.5 kΩ Max. Count 4,294,967,295 (32 bits) Counters Max.
Page 15: 2260
ET-2200 Series Ethernet I/O Modules 2.2.2.5 ET-2260 Model ET-2260 Digital Input/Counter Channels Contact Wet Contact Sink/Source (NPN/PNP) Sink/Source On Voltage Level +5 V ~ +50 V +3.5 V Max. Off Voltage Level Input Impedance 7.5 kΩ Max. Count 4,294,967,295 (32 bits) Counters Max.
Page 16: 2261
ET-2200 Series Ethernet I/O Modules 2.2.2.6 ET-2261 Model ET-2261 Power Relay Channels Type Power Relay, Form A (SPST N.O.) Contact Rating 5 A @ 250 V /24 V (Resistive Load) Min. Contact Load 10 mA @ 5 V Operate Time 10 ms (max.)
Page 17: 2268
ET-2200 Series Ethernet I/O Modules 2.2.2.7 ET-2268 Model ET-2268 Relay Output Channels 8 (Form A x 4, Form C x 4) Relay Type Signal Relay 2 A @ 30 V Contact Rating 0.24 A @ 220 V 0.25 A @ 250 V Min.
Page 22: Wiring Connections
ET-2200 Series Ethernet I/O Modules 2.4 Wiring Connections 2.4.1 Input Wiring  Input Wiring for the ET-2251/2255/2260: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 22 -...
Page 23: Output Wiring
ET-2200 Series Ethernet I/O Modules  Input Wiring for the ET-2254/2254P: 2.4.2 Output Wiring  Output Wiring for ET-2242/2254/2254P/2255:  Output Wiring for ET-2260/2261: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 23 -...
Page 24 ET-2200 Series Ethernet I/O Modules  Output Wiring for ET-2268: Note for the ET-2260/2261/2268: When inductive loads are connected to the relays, a large counter electromotive force may occur when the relay actuates because of the energy stored in the load. These fl yback voltages can severely damage the relay contacts and greatly shorten the relay life.
Page 25: Wiring To The Connector
ET-2200 Series Ethernet I/O Modules 2.5 Wiring to the Connector  Insulated Terminals Dimensions: Dimensions (Unit: mm) Item NO. CE007512 12.0 18.0  A tip for connecting the wire to the connector 2. While holding the screwdriver in place, insert the wire into the terminal block.
Page 26: Dimensions
ET-2200 Series Ethernet I/O Modules 2.6 Dimensions The following diagrams provide the dimensions of the ET-2200 series module and can be used as a reference when defining the specifications for any custom enclosures. All dimensions are in millimeters. Left Side View...
Page 27: Getting Started
This chapter provides a basic overview of how to configure and operate your ET-2200 series module. 3.1 Configuring the Boot Mode The ET-2200 series modules have two operating modes that can be selected by using the switch mechanism incorporated on the chassis. Note that the module must be rebooted after changing the operating mode.
Page 28: Connecting The Power And The Host Pc
ET-2200 Series Ethernet I/O Modules 3.2 Connecting the Power and the Host PC Step 1: Connect both the ET-2200 module and the Host PC to the same sub network or the same Ethernet Switch Ensure that the network settings on the Host PC have been correctly configured and are functioning normally.
Page 29: Configuring The Network Settings
ET-2200 Series Ethernet I/O Modules 3.3 Configuring the Network Settings Step 1: Get the eSearch Utility The eSearch Utility can be obtained either from the companion CD at: CD:\Napdos\Software\eSearch\ Or from the ICP DAS web site at: http://ftp.icpdas.com/pub/cd/tinymodules/napdos/software/esearch/ Step 2: Install the eSearch Utility Follow the steps as suggested by the eSearch setup wizard to finish the installation.
Page 30 ET-2200 Series Ethernet I/O Modules Step 4: Once the search process in complete, double-click the name of the ET-2200 module to open the “Configure Server (UDP)” dialog box Factory Default Settings for the ET-2200 Series, as follows: 192.168.255.1 Gateway 192.168.0.1 Mask 255.255.0.0...
Page 31: Modbus Tcp Testing
ET-2200 Series Ethernet I/O Modules Step 6: Wait for 2 seconds and then click the “Search Servers” button again to ensure that the ET-2200 module is operating correctly using the new configuration 3.4 Modbus TCP Testing Step 1: In the eSearch Utility, Select the “Modbus TCP Master”...
Page 32 ET-2200 Series Ethernet I/O Modules Step 2: Enter the “IP address” “TCP Port” information for the ET-2200 module in the “Modbus TCP” section, and then click the “Connect” button to connect to the ET-2200. Step 3: Refer to the “Protocol Description”...
Page 33: Web Configuration
I/O accessibility to the ET-2200 series module via a web browser. 4.1 Logging in to the Web Server You can access the embedded ET-2200 series web server from any computer that has an Internet connection. Step 1: Lauch web browser Open a standard web browser.
Page 34 ET-2200 Series Ethernet I/O Modules Step 3: Enter the password Once the login screen is displayed, enter the password in the login password field (use the default password “Admin”), and then click the “Submit” button to enter the configuration web page.
Page 35: Home
The Model Name, Firmware version, IP Address, Initial Switch position, Alias Name, MAC Address, and the TCP Port and System Timeout values. If the firmware for the ET-2200 series module is updated, you can use this page to check the version information for the ET-2200 software.
Page 36: Network
Clicking the Network tab will display the IP Address Configuration page allowing you verify the current settings and configure the IP Address parameters, configure the general parameters and restore the default settings for the ET-2200 series module, each of which will be described in more detail below.
Page 37 ET-2200 Series Ethernet I/O Modules Item Description Static IP: If there is no DHCP server installed in your network, you can configure the network settings manually. Refer to Section 4.3.1.2 “Manual Configuration” for more details. Address Type DHCP: Dynamic Host Configuration Protocol (DHCP) is a network application protocol that automatically assigns an IP address to each device.
Page 38: Dynamic Configuration
ET-2200 Series Ethernet I/O Modules 4.3.1.1 Dynamic Configuration Dynamic configuration is very easy to perform. If a DHCP server is connected to you network, a network address can be dynamically configured by using the following procedure: Step 1: Select “DHCP” from the Address Type drop-down menu.
Page 39: General Settings
ET-2200 Series Ethernet I/O Modules 4.3.2 General Settings The following table provides an overview of the parameters contained in the General Settings section: Item Description This parameter is used to set the Ethernet speed. The default value is Ethernet Speed Auto (Auto = 10/100 Mbps Auto-negotiation).
Page 40: Restore Factory Defaults
ET-2200 Series Ethernet I/O Modules 4.3.3 Restore Factory Defaults  Restore all options to their factory default states To reset all parameters to their original factory default settings, use the following procedure: Step 1: Click the “Restore Defaults” button to reset the configuration.
Page 41 ET-2200 Series Ethernet I/O Modules  Forced Reboot The Forced Reboot function: can be used to force the ET-2200 module to reboot or to remotely reboot the device. After the ET-2200 module has rebooted, the original login screen will be displayed requesting that you enter your Login Password before continuing.
Page 42: Firmware Update
ET-2200 Series Ethernet I/O Modules 4.3.4 Firmware Update For detailed information about how to remote update the Firmware for the ET-2200 module, refer to the ET-2200_Firmware_Update_vxxx_en.pdf. The location of the user manual on the CD and the download address are shown below: CD:\\ NAPDOS\ET2200\Firmware\ http://ftp.icpdas.com/pub/cd/6000cd/napdos/et2200/firmware/...
Page 43: I/O Settings
Clicking the I/O Settings tab will display the DO Control and DI/DO Configuration page allowing you configure the Digital Input and Digital Output parameters for the ET-2200 series module. This page including Digital Output control, DI/DO Configuration, etc., each of which will be described in more detail below.
Page 44: Di/Do Configuration
ET-2200 Series Ethernet I/O Modules 4.4.2 DI/DO Configuration The following table provides an overview of the parameters contained in the DI/DO Configuration section: Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 44 -...
Page 45 ET-2200 Series Ethernet I/O Modules Item Description Digital Output This parameter is used to configure the Host Watchdog timeout value. If Host Watchdog Timeout there is no Modbus TCP communication activity for the specified period (Seconds) (the timeout), then the Host Watchdog will activate an alarm.
Page 46 ET-2200 Series Ethernet I/O Modules This parameter is used to define the scan mode for the frequency measurement. 1000 ms: This mode provides a normal update rate and normal accuracy. The acceptable frequency range for the input signal is 1 Hz to 3 kHz (± 1 Hz error).
Page 47: Sync
Clicking the Sync tab will display the DIO Synchronization page allowing you configure the Synchronous DIO, Min-switching time of DO and Auto-off Time of DO for the ET-2200 series module, each of which will be described in more detail below.
Page 48 ET-2200 Series Ethernet I/O Modules Item Description Synchronous DIO (Local Mirror) Note: The ET-2254 supprots these functions when low 8-bit are DI0 to DI7 and high 8-bit are DO8 to DO15. This parameter is used to enable the synchronization operation in Level Sync (DO = DI) Digital Input/Output function.
Page 49: Pwm
Clicking the PWM tab will display the PWM Configuration page allowing you enable and configure the PWM parameters for the ET-2200 series module, including the PWM Alarm and duty cycle, etc., each of which will be described in more detail below.
Page 50 ET-2200 Series Ethernet I/O Modules Item Description Default Value Enable PWM This parameter is used to enable the PWM output function. This parameter is used to enable the PWM output alarm Enable PWM Alarm function when Host/Slave watchdog timeout. This parameter is used to set the duty cycle for the DO channels.
Page 51: Pair Connection
4.7.1 I/O Pair-Connection Settings The I/O pair connection function is a specific feature of the ET-2200 series module that can be used to enable a pair of DI-to-DO connections via the Modbus TCP (Ethernet) protocol. The following table provides an overview of the parameters contained in the I/O Pair-Connection Settings section: Copyright ©...
Page 52 ET-2200 Series Ethernet I/O Modules Item Description Default This parameter is used to define the Server mode for the ET-2200 series module. Mode = Disable: Server mode (Slave). Mode Mode = POLL: Poll remote DI to local DO in the Client mode Disable (Master).
Page 53 ET-2200 Series Ethernet I/O Modules For “POLL” mode, this parameter specifies the base address of the Local DO register that will be mapped to the Remote DI device. The range depends on the type of the ET-2200 module being used.
Page 54: Filter
4.8.1 Filter Settings The Filter Settings page is used to query or edit the IP Filter List (Available IP) for the ET-2200 series module. The IP filter list restricts the access of incoming packets based on the IP address. If one or more IP addresses are saved to the IP Filter table, only Clients whose IP address is specified in the IP Filter List (Available IP) will be able to access the ET-2200 series module.
Page 55 ET-2200 Series Ethernet I/O Modules The following table provides an overview of the parameters contained in the IP Address Configuration section: Item Description Add “IP” to the List This parameter is used to add an IP address to the Available IP List.
Page 56: Monitor
ET-2200 Series Ethernet I/O Modules 4.9 Monitor After clicking the Monitor tab, the Current Connection Status page will be displayed showing detailed information regarding the current status of the serial port connection settings for the ET-2200 series module. Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved.
Page 57: Change Password
ET-2200 Series Ethernet I/O Modules 4.10 Change Password After clicking the Password tab, the Change Password page will be displayed. To change a password, first enter the old password in the “Current password” field (use the default password “Admin”) and then enter a new password in the “New password” field. Re-enter the new password in the “Confirm new password”...
Page 58: Logout
ET-2200 Series Ethernet I/O Modules 4.11 Logout Clicking the Logout tab will immediately log you out from the system and return you to the login page. Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. - 58 -...
Page 59: I/O Pair Connection Applications
ET-2200 Series Ethernet I/O Modules 5. I/O Pair Connection Applications The ET-2200 series modules can be used to create DI-to-DO pair connections via the Ethernet. Once the configuration is complete, the modules can then poll the status of the local DI channels and then use the Modbus/TCP protocol to continuously write to a remote DO device in the background.
Page 60 Step 2: Configure the Ethernet Settings Contact your Network Administrator to obtain the correct network configuration information for the ET-2200 series modules (e.g., ET-2260 #1 and #2), such as the IP Address, Subnet Mask, and Gateway details. Refer to Section 3.3 “Configuring the Network Settings”...
Page 61: Polling Mode
ET-2200 Series Ethernet I/O Modules 3. Click the “Pair Connection” tab to display the I/O Pair-connection Settings page. Figure 5-1.4 5.1.1 Polling Mode 4. In the “I/O Pair-connection Settings”, select “POLL” from the “Mode” drop-down options. 5. Enter the IP address for ET-2260 #2 module in the “Remote IP” field.
Page 62: Push Mode
ET-2200 Series Ethernet I/O Modules 5.1.2 Push Mode 4. In the “I/O Pair-connection Settings”, select “PUSH” from the “Mode” drop-down options. 5. Enter the IP address for ET-2260 #2 module in the “Remote IP” field. 6. Enter the TCP Port for ET-2260 #2 module in the “Remote Port” field.
Page 63: Two Modules Pushing The Local Di To Each Other (1-To-1, Push Mode)
Step 2: Configure the Ethernet Settings Contact your Network Administrator to obtain the correct network configuration information for the ET-2200 series modules (e.g., ET-2260 #1 and #2), such as the IP Address, Subnet Mask, and Gateway details. Refer to Section 3.3 “Configuring the Network Settings”...
Page 64 ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module 1. In the eSearch Utility, select ET-2260 #1 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 65 ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module 1. In the eSearch Utility, select ET-2260 #2 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 66: Several Modules Polling The Remote Di (M-To-1) (Polling Mode)
(M-to-1) (Polling Mode) Step 1: Connect the device to a Network, a PC and a Power supply. Confirm that the ET-2200 series modules and remote slave device are functioning correctly. Refer to Chapter 3 “Getting Started” for more details. An example configuration shown below: Note that ET-2260 and PETL-7060 module is used in this example.
Page 67 ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module 1. In the eSearch Utility, select ET-2260 #1 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 68 ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module 1. In the eSearch Utility, select ET-2260 #2 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 69: Several Modules Pushing The Local Di (M-To-1) (Push Mode)
Step 2: Configure the Ethernet Settings Contact your Network Administrator to obtain the correct network configuration information for the ET-2200 series modules and remote slave device (e.g., ET-2260 #1, #2 and PETL-7060), such as the IP Address, Subnet Mask, and Gateway details. Refer to Section 3.3 “Configuring the Network...
Page 70 ET-2200 Series Ethernet I/O Modules Step 3: Configure the I/O Pair connection on the ET-2260 #1 module 1. In the eSearch Utility, select ET-2260 #1 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 71 ET-2200 Series Ethernet I/O Modules Step 4: Configure the I/O Pair connection on the ET-2260 #2 module 1. In the eSearch Utility, select ET-2260 #2 module and then click the “Web” button to launch the browser program and connect to the web server.
Page 72: Modbus Information
ET-2200 Series Ethernet I/O Modules 6. Modbus Information The ET-2200 series is a family of IP-based Modbus I/O devices that allow you to remotely control DI/DO terminals via an Ethernet connection and uses a master-slave communication technique in which only one device (the master) can initiate a transaction (called queries), while other devices (slaves) respond by either supplying the requested data to the master, or by taking the action requested in the query.
Page 73: Modbus Message Structure
ET-2200 Series Ethernet I/O Modules 6.2 Modbus Message Structure Modbus devices communicate using a master-slave (client-server) technique in which only one device (the master/client) can initiate transactions (called queries). The other devices (slaves/servers) respond by either supplying the requested data to the master, or by taking the action requested in the query.
Page 74 ET-2200 Series Ethernet I/O Modules  RTU Data Structure Byte 06 Byte 07 Bytes 08 - 09 Bytes 10 - 11 Data Field Net ID Function Code Reference Number (Station Number) Number of Points (Address Mapping)  Net ID specifies the address of the receiver (Modbus/TCP slave).
Page 75 ET-2200 Series Ethernet I/O Modules Data Field Data is transmitted in 8-, 16- and 32-bit format. The data for 16-bit registers is transmitted in high-byte first format. For example: 0x0A0B ==> 0x0A, 0x0B. The data for 32-bit registers is transmitted as two 16-bit registers, and is low-word first. For example: 0x0A0B0C0D ==> 0x0C, 0x0D, 0x0A, 0x0B.
Page 76: 0X01) Read The Status Of The Coils (Readback Dos)
ET-2200 Series Ethernet I/O Modules 6.2.1 01(0x01) Read the Status of the Coils (Readback DOs) This function code is used to read either the current status of the coils or the current digital output readback value from the ET-2200 series module. [Request] Byte...
Page 77 ET-2200 Series Ethernet I/O Modules Example: Function 01 (0x01), Readback Dos  Reads the Digital Output value [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 01 00 00 00 02 [Leading 6 bytes] [Response] Response: 01 02 00 00 00 04 01 01 01 03 ...
Page 78: 0X02) Read The Status Of The Input (Read Dis)
ET-2200 Series Ethernet I/O Modules 6.2.2 02(0x02) Read the Status of the Input (Read DIs) This function code is used to read the current digital input value from the ET-2200 series module. [Request] Byte Description Size Value Net ID (Station Number)
Page 79 ET-2200 Series Ethernet I/O Modules Example: Function 02 (0x02), Read DIs  Reads the Digital Input value [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 02 00 00 00 02 [Leading 6 bytes] [Response] Response: 01 02 00 00 00 04 01 02 01 03 ...
Page 80: 0X03) Read The Holding Registers (Readback Aos)
This function code is used to readback either the current values in the holding registers or the analog output value from the ET-2200 series module. These registers are also used to store the preset values for the digital counter, the host watchdog timer, the module name and the TCP timeout, etc.
Page 81 ET-2200 Series Ethernet I/O Modules Example: Function 03 (0x03), Read AOs  Reads the name of the module for the ET-2260 [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 03 01 03 00 01 [Leading 6 bytes]...
Page 82: 0X04) Read The Input Registers (Read Ais)
This function code is used to read either the input registers or the current analog input value from the ET-2200 series module. These registers are also used to store the current value for the digital counter, the number of DI channels and the number of DO channels, etc.
Page 83 ET-2200 Series Ethernet I/O Modules Example: Function 04 (0x04), Read AIs  Reads the number of the DI channels on the ET-2260 [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 04 00 64 00 01 [Leading 6 bytes]...
Page 84: 0X05) Force A Single Coil (Write Do)
ET-2200 Series Ethernet I/O Modules 6.2.5 05(0x05) Force a Single Coil (Write DO) This function code is used to set the status of a single coil or a single digital output value for the ET-2200 series module. [Request] Byte Description...
Page 85 ET-2200 Series Ethernet I/O Modules Example: Function 05 (0x05), Write DO  Sets channel DO1 to ON [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 05 00 01 FF 00 [Leading 6 bytes] [Response] Response: 01 02 00 00 00 06 01 05 00 01 FF 00 ...
Page 86: 0X06) Preset A Single Register (Write Ao)
ET-2200 Series Ethernet I/O Modules 6.2.6 06(0x06) Preset a Single Register (Write AO) This function code is used to set a specific holding register to store the configuration values for the ET-2200 series module. [Request] Byte Description Size Value Net ID (Station Number)
Page 87 ET-2200 Series Ethernet I/O Modules Example: Function 06 (0x06), Write AO  Sets the system timeout to 60 seconds [Leading 6 bytes] [Request] Command: 01 02 00 00 00 06 01 06 01 08 00 3C [Leading 6 bytes] [Response]...
Page 88: 0X0F) Force Multiple Coils (Write Dos)
ET-2200 Series Ethernet I/O Modules 6.2.7 15(0x0F) Force Multiple Coils (Write DOs) This function code is used to set multiple coils status or write multiple digital output values for the ET-2200 series module. [Request] Byte Description Size Value Net ID (Station Number)
Page 89 ET-2200 Series Ethernet I/O Modules Example: Function 15 (0x0F), Write DOs  Sets the safe value (DO0 ~ DO1) [Leading 6 bytes] [Request] Command: 01 02 00 00 00 08 01 0F 01 0B 00 02 01 03 [Leading 6 bytes]...
Page 90: 0X10) Preset Multiple Registers (Write Aos)
ET-2200 Series Ethernet I/O Modules 6.2.8 16(0x10) Preset Multiple Registers (Write AOs) This function code is used to set multiple holding registers that are used to store the configuration values for the ET-2200 series module. [Request] Byte Description Size Value...
Page 91 ET-2200 Series Ethernet I/O Modules Example: Function 16 (0x10), Write AOs  Sets the preset value for the digital counter [Leading 6 bytes] [Request] Command: 01 02 00 00 00 0B 01 10 00 32 00 01 02 03 E8 00 00...
Page 92: Modbus Register Table
ET-2200 Series Ethernet I/O Modules 6.3 Modbus Register Table Data from 16-bit registers is transmitted in high-byte first order. For example: 0x0A0B ==> 0x0A, 0x0B. Data from 32-bit registers is transmitted as two 16-bit registers, and is in low-word first order.
Page 93 ET-2200 Series Ethernet I/O Modules  4xxxx: AO Address (Base 0) Starting Bits per Access Points Description Range Address Point Type 1 = Reset at Power-on 2 = Reset by the WDT CPU Reset Status (0xFF) 3 = Reset using the reset command <5: Disabled...
Page 94: Specific Functions
ET-2200 Series Ethernet I/O Modules 6.3.2 Specific Functions The nDI and nDO parameters for each ET-2200 series module used in the following Modbus Address Tables are as follows: Universal DIO Number of DO channels Number of DI channels Model Name...
Page 95 ET-2200 Series Ethernet I/O Modules 0 = Disable Enables frequency measurement for all 1 to nDI 1 = Enable R/W/F (0xBE) DI Channels (Default= 0) 0 = Off Sets the Power-on value for all DO 1 to nDO 1 = On...
Page 96 ET-2200 Series Ethernet I/O Modules  1xxxx: DI Address (Base 0) Starting Bits per Access Points Description Range Address Point Type The status of all Digital Input 0 = Off 1 to nDI (0x00) Channels 1 = On The status of all high latched DI...
Page 97 ET-2200 Series Ethernet I/O Modules  3xxxx: AI Address (Base 0) Starting Bits per Access Points Description Value Address Point Type 0 to 1 to nDI The Digital Counter Value (0x10) 4294967296 The frequency Value * 1,000. 0 to 1 to nDI...
Page 98 ET-2200 Series Ethernet I/O Modules  4xxxx: AO Address (Base 0) Starting Bits per Access Points Description Range Address Point Type The preset value for the high speed 0 to 1 to nDI R/W/E (0x32) digital counter 4294967296 Note: “Preset DI Counter Value (0x32)” that the records data as 32-bit value and is transmitted as two 16-bit registers.
Page 99 ET-2200 Series Ethernet I/O Modules The Min-Switching Time for all DO 1 to 65535 1 to nDO R/W/F (0x10C) Channels second The Auto-off Time for all DO 1 to 65535 1 to nDO R/W/F (0x11C) Channels second “R”: Read “W”: Write Notes “F”: Settings are recorded in flash by default...
