Wiring Diagram - Directed Directechs DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
CAN Junction
(green CAN junction connector
behind glove box)
OBDII Diagnostic
Warning!
1 8
Only 10A
9 16
(+) 12V:
Gray/Red, pin 16
BCM
(Black-Gray conn. above
passenger kick panel)
OR
40A
1 2
(+) 12V:
Violet/Red,
pin 3
3 4
7 403.CHRYSLER15 1.16 2021 Jeep Wrangler (Smart Key)
©2023 Directed. All rights
CAN C High:
1 Tan/White, pin 1
2
1
3
2
CAN C Low:
Yellow, pin 2 3
(+) PTS: Violet/Lt. Blue or Violet/Blue,
pin 4
Keyless
Ignition Node
(black conn. at
Start-Stop button)
Immobilizer Data:
White/Green, pin 5
CUT
CAN Junction
(white CAN junction connector behind glove box)
HS CAN 3 High: Tan/Black: 3
HS CAN 3 Low: Tan: 4
HS CAN 2 High: Orange/Green: 5
HS CAN 2 Low: Orange/Brown: 6
Immo. Data Interr. (veh. side): Yellow: 8
Immo. Data Interr. (conn. side): Orange/Yellow: 9
(+) 12V Input: Red: 13
(-) Ground: Black: 14
(+) PTS Output: Gray/Black: 7
(MUX) Parking Light Output: Violet/Brown: 9
Headlight Switch
(black 10-pin conn.)
(MUX) Parking Lights:
White/Brown, pin 1
1
2 3 4
6 7 8 9
).
CAN IHS High:
Orange, pin 1
1
2
CAN IHS Low:
3
White/Orange,
pin 2
1
2
3
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
Remote Start Safety
5
10
6: White/Black:
(-) Hood Input
Override Switch
Hood Pin
