AP560h Features

AP560h Features
The AP560h access point has the following features:
•
Radios: Two radios
1 dual-band, 2.4GHz and 5GHz, and 1 band-locked 5GHz
◦
1 IoT Radio (2.4 GHz)
◦
•
Two Ethernet ports
1 x 100/1000/2500/5000 Mbps auto-negotiation Ethernet port, RJ45
◦
1 x 10/100/1000 Mpbs auto-negotiation Ethernet port, RJ45
◦
•
Dimensions: 11.3 in. × 18.9 in. × 3.5 in. (288 mm × 481 mm × 88 mm)
•
LEDs: Two top-mounted LEDs
•
One security hanger hole
•
Power: PoE 802.3at
•
Antennas:
Two software selectable internal antennas (30 degree and 70 degree directional
◦
antennas)
•
Temperature:
Operating temperature: -40°C to +55°C (-40°F to +131°F)
◦
Storage temperature: -40°C to +70°C (-40°F to +158°F)
◦
•
Enclosure: Plastic only
Figure 1: AP560h front view
10 ExtremeWireless™ AP560h Access Point
AP560h Overview
