Single Monitor Pegboard Panel Mount
Instruction Manual
SKU: MOUNT-PB1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pb1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Table of Contents
Related Manuals for Vivo MOUNT-PB1
Summary of Contents for Vivo MOUNT-PB1
- Page 1 Single Monitor Pegboard Panel Mount Instruction Manual SKU: MOUNT-PB1 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pb1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Attach one set of Prongs (B) to the top of Mount Base (A) using M4x8mm Screws (S-B) and a Phillips head screwdriver. Ensure that VESA Head (A1) is pointing up as shown below. Horizontal Adjustments Allows for greater tilt adjustment Prongs can be installed in two different orientations to allow for additional adjustment in the horizontal or...
- Page 4 STEP 2 Attach Mounts Base (A) with Prongs (B) to the pegboard. Instal remaining set of Prongs (B) to pegboard, slightly lifting Mount Base (A) forward to get the Prongs behind the Base. Secure Prongs (B) using M4x8mm Screws (S-B) and a Phillips head screwdriver. STEP 3 Secure VESA Plate (C) to monitor using appropriate Screws (M-A thru M-D), Washers (M-E), and a Phillips head screwdriver.
- Page 5 STEP 4 Slide monitor with VESA Plate (C) onto the Mount Base (A). Secure VESA Plate (C) in place using M6x10mm Thumbscrew (S-A).
- Page 6 Adjust as Desired If monitor is sagging or adjustments need to be made, use 6mm Allen Wrench (T-A) to tighten or loosen swivel joint on VESA Head (A1). Adjust the positioning of monitor by loosen the four nuts on the Mount Base (A) using the Wrench (T-B).
- Page 7 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
