Black Under Desk Leg Clamp PC Mount
Instruction Manual
SKU: MOUNT-PC01C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pc01c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-PC01C
Summary of Contents for Vivo MOUNT-PC01C
- Page 1 Black Under Desk Leg Clamp PC Mount Instruction Manual SKU: MOUNT-PC01C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pc01c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Apply Pads (C) to top, bottom, and side of Mount (B) as shown. STEP 2 Loosen the sets screws on the either side of Mount (B) using 4mm Allen Wrench (T-A) to adjust the height.
- Page 4 STEP 3 Insert M5x6mm Screws (S-A) into Clamp (A) leaving a 2mm gap. STEP 4 Insert the heads of M5x6mm Screws (S-A) with Clamp (A) into the slots in Mount (B). Slots...
- Page 5 STEP 5 Secure Clamp (A) to Mount (B) using M5x6mm Screws (S-A) in the lower holes. Tighten all screws using a Phillips screwdriver. STEP 6 Remove the protective film from Clamp (A) and assemble Clamp (A) to the desk leg by tightening both knobs.
- Page 6 STEP 7 Loosen two screws on top of Mount (B) and slide side support bracket out to maximum width. STEP 8 Place PC tower in Mount (B), slide bottom support up until Mount (B) is fit vertically to PC, and tighten set screws using 4mm Allen Wrench (T-A).
- Page 7 STEP 9 The PC mount is now ready for use.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
