White Under Desk and Wall PC Mount
Instruction Manual
SKU: MOUNT-PC01W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pc01w
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-PC01W
Summary of Contents for Vivo MOUNT-PC01W
- Page 1 White Under Desk and Wall PC Mount Instruction Manual SKU: MOUNT-PC01W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pc01w GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Apply pads (E) to top, bottom, and side of the PC mount (A) as shown. STEP 2A-1 OPTION A: Under Desk Installation Secure PC mount (A) to bottom of desk using 4.6x16 screws (B) and washers (F). - Page 4 STEP 2A-2 Loosen two screws on top of mount (one on each side) and slide side support bracket out to maximum width. STEP 2A-3 Loosen set screws for lower support using the Allen wrench (G) and slide the support down. Place PC tower on mount, slide bottom support up until mount is fit vertically to PC, and tighten set screws using the Allen wrench.
- Page 5 STEP 2B-1 OPTION B: Wood Wall Installation Loosen two screws on top of mount (one on each side) and slide side support bracket out to maximum width. Loosen set screws for lower support using the Allen wrench (G) and slide the support down. STEP 2B-2A For solid wood wall, place mount (A) against wall and mark drilling locations.
- Page 6 STEP 2B-2B OPTION C: Concrete Wall Installation For concrete wall installation, place PC mount (A) against the wall and mark locations with a pencil. Drill 1.2” (35mm) deep holes at marked locations using a 1/4” (6mm) drill bit. Insert anchors (D) into holes, and insert two 4.8x38 screws (C) into top holes, leaving 3mm if thread exposed.
- Page 7 STEP 2B-3 Place PC tower on mount, slide bottom support up until mount is fit vertically to PC, and tighten set screws using the Allen wrench (G). Slide side bracket into place to hold PC, and tighten screws using a Phillips screwdriver.
