Pole Mount Pneumatic Monitor Arm for VESA
75x75mm and 100x100mm
Instruction Manual
SKU: MOUNT-POLE05O
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pole05o
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-POLE05O
Summary of Contents for Vivo MOUNT-POLE05O
- Page 1 Pole Mount Pneumatic Monitor Arm for VESA 75x75mm and 100x100mm Instruction Manual SKU: MOUNT-POLE05O Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pole05o GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 While holding Arm (A) closed, cut the shipping tie and gently release Arm (A). - Page 4 STEP 2 Poles 28-45mm in Diameter: Assemble Arm (A) with Pole Clamp (B) to the pole using M8x50mm Screws (S-A), M8 Nuts (S-C) and 5mm Allen Wrench (T-B). Poles 46-60mm in Diameter: Assemble Arm (A) with Pole Clamp (B) to the pole using M8x65mm Screws (S-B), M8 Nuts (S-C) and 5mm Allen Wrench (T-B).
- Page 5 STEP 3 Install Screws (M-A or M-B) and M5 Washers (M-C) to the top mounting holes of your monitor, making sure to leave 3mm of threads exposed. Align Screws (M-A or M-B) in the VESA plate. Secure using two more Screws (M-A or M-B) and M5 Washers (M-C) in the bottom two holes. Tighten all four screws using the Phillips end of 4mm Allen Wrench (T-A).
- Page 6 STEP 4 Adjust gas spring support in Arm (A) using 5mm Allen Wrench (T-B). Turning counter-clockwise increases support, and clockwise decreases. STEP 5 Remove the cable management covers from Arm (A) using the Phillips end of 4mm Allen Wrench (T-A). Run cables from monitors through bottom Arm (A), then reattach cable management covers.
- Page 7 STEP 6 Adjust the monitor tilt using 5mm Allen Wrench (T-B).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
