Multifunctional Thin Client PC Mount
Instruction Manual
SKU: MOUNT-PC05C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pc05c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-PC05C
Summary of Contents for Vivo MOUNT-PC05C
- Page 1 Multifunctional Thin Client PC Mount Instruction Manual SKU: MOUNT-PC05C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pc05c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Remove knobs from mount (A) and separate the mount. - Page 4 STEP 2 OPTION A: POLE MOUNT Attach larger half of mount to pole using the pole mount bracket (C) and M5x25 screws (F). Apply one adhesive pad (D) to the assembled mount and two pads to the inner face of the other half. Reattach halves using previously removed knobs.
- Page 5 STEP 2 (Continued) OPTION B: UNDER DESK MOUNT Apply one adhesive pad (D) to the larger half of mount and two pads to the inner face of the other half. Use outer four holes on mount to mark drilling locations on the underside of the desk.
- Page 6 STEP 2 (Continued) OPTION C: VESA MOUNT Attach smaller half of mount to VESA mount using four M4x12 screws (G), washers (H) and nuts (I). Apply two adhesive pads (D) to the assembled mount and one pad to the inner face of the other half.
- Page 7 STEP 2 (Continued) If also installing a monitor, with the strap (B) fit into the slot, attach larger half of mount to monitor using four M4x12 screws (G). Reattach halves using previously removed knobs. Place PC into mount, adjust to fit, and tighten knobs. Secure PC using the strap.
