Pack 02
B U I L D
I N S T R U C T I O N S
STAGE 05: THE FRONT BUMPER, OVERRIDERS ,
STAGE 08: THE ENGINE INTAKE HOSE
AND LICENSE PLATE
STAGE 09: THE CYLINDER HEAD COVER AND
STAGE 06: THE CRANKCASE AND
THE DISTRIBUTOR
THE OIL RADIATOR
STAGE 10: THE ALTERNATOR AND
STAGE 07: THE ENGINE CYLINDER HEAD
THE WATER PUMP
"MERCEDES-BENZ" and
are the intellectual property of Mercedes-Benz Group AG.
They are used by Agora Models under license.
