Pack 07
B U I L D
I N S T R U C T I O N S
STAGE 46: ASSEMBLING THE ENGINE OIL
STAGE 51: ASSEMBLING AND AT TACHING
RECOVERY TANK, TRANSMISSION LINE AND
THE REAR LEFT TYRE
BONNET LIFT ARM
STAGE 52: FIT TING THE SECOND
STAGE 47: FIXING THE BONNET LIFT ARM
REINFORCEMENT BAR
TO THE UPPER FRAME
STAGE 53: ASSEMBLING AND AT TACHING
STAGE 4 8: AT TACHING THE LEFT TRIPOD BAR
THE REAR RIGHT TYRE
AND THE LEFT TAIL LIGHT
STAGE 54: CONSTRUCTING THE
STAGE 49: AT TACHING THE UPPER FRAME
COCKPIT BULKHEAD
TO THE LOWER FRAME
STAGE 50: FIT TING THE FIRST
REINFORCEMENT BAR
