Agora Models LAMBORGHINI MIURA Pack 12 Build Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Pack 12
B U I L D
I N S T R U C T I O N S
STAGE 92: FIT TING THE REAR
STAGE 96: AT TACHING THE
STAGE 99: PREPARING THE
NUMBER PLATE AND GRILLE
WHEELS AND ADDING THE
WINDSCREEN
BERTONE LOGO
STAGE 93: ASSEMBLING THE
STAGE 100: ATTACHING THE
BOOT COMPARTMENT AND
STAGE 97: ADDING THE
FRONT BODY, THE SIDE
INSTALLING THE REAR LIGHTS
BAT TERY COMPARTMENT
SKIRTS , THE NUMBER PLATE
AND THE SHIELD EMBLEM
AND ADDING DETAILS
STAGE 94: FIT TING THE
WINDOW GRILLE AND THE
STAGE 98: FITTING THE
INSTALLING THE BAT TERIES
BOOT COMPARTMENT
TAILPIPES AND CONNECTING
AND OPERATING THE
THE ELECTRICS
ELECTRICS
STAGE 95: FITTING THE REAR
BODY AND WHEEL ARCHES
The "Automobili Lamborghini" and "Automobili Lamborghini Bull and Shield" trademarks, copyrights,
designs and models are used under number from Automobile Lamborghini S.p.A, Italy.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LAMBORGHINI MIURA Pack 12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agora Models LAMBORGHINI MIURA Pack 12

Summary of Contents for Agora Models LAMBORGHINI MIURA Pack 12

  • Page 1 Pack 12 B U I L D I N S T R U C T I O N S STAGE 92: FIT TING THE REAR STAGE 96: AT TACHING THE STAGE 99: PREPARING THE NUMBER PLATE AND GRILLE WHEELS AND ADDING THE WINDSCREEN BERTONE LOGO STAGE 93: ASSEMBLING THE...
  • Page 2 Advice from the experts Spare screws are included with each part. Occasionally, you may be instructed to keep spare or unused screws for a later stage. Keep these spares in a safe place and label them correctly. Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary slightly.
  • Page 3 Stage 92: Fitting the Rear Number Plate and Grille In this stage, you’ll assemble the rear number plate and fit it, along with the grille and number plate lights, to the rear body. The parts supplied will be used in the next stage and can be kept aside for now.
  • Page 4 Stage 92: Fitting the Rear Number Plate and Grille Take the number plate lights and the number plate glass (supplied Press the pins of the glass into the holes of the lights. Test fit the with Stage 90). The glass has two pins (inset, arrows) which press into glass in as one side is flatter than the other –...
  • Page 5 Stage 92: Fitting the Rear Number Plate and Grille TYPE B With the lights in place, secure them using 2x Type B screws from Next take the boot lock (supplied with Stage 90, inset). This has a inside the body. shaped end for fitting into the hole (arrow) in the rear body located between the number plate lights.
  • Page 6 Stage 92: Fitting the Rear Number Plate and Grille Fit the plate by pressing its pins into the inner holes of the frame as Set the number plate aside for now. Take the rear grille (supplied with shown in the top image, then press the frame trim into the outer Stage 91) along with the rear body assembly.
  • Page 7 Stage 92: Fitting the Rear Number Plate and Grille TYPE D Using 4x Type D screws (supplied with Stage 91) secure the rear grille by driving the screws into the fixing points highlighted in the previous step. TYPE B Once the rear grille has been fixed, push the raised screw holes of the Turn the body around and secure the number plate using 2x Type B number plate into the two remaining holes in the rear body, between screws (supplied with Stage 91).
  • Page 8 Stage 92: Fitting the Rear Number Plate and Grille S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 9 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights You’ll now assemble the boot compartment, which houses the speaker for your model, using the parts provided and those from the previous stage. You’ll also fit the rear lights into the rear body. S T A G E 9 3 P A R T S L I S T Name Boot compartment cover...
  • Page 10 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights First you’ll assemble the boot compartment. Retrieve the boot Peel the backing paper from the adhesive cover as shown. compartment and adhesive cover (supplied with Stage 92). Note there is a square recess in the compartment (circled).
  • Page 11 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights Press the black pins of the reverse light support into the holes located Turn the compartment over and place it on your work surface. by the adhesive cover in the compartment, so that the glass is facing Align the boot profile (supplied with Stage 92) with it as shown.
  • Page 12 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights Set the boot compartment aside until it is needed in the next stage. Fit the rear light housings into the corresponding left and right holes Take the rear light lenses (supplied with Stage 92), the rear light in the rear body as shown by the arrows.
  • Page 13 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights Take one of the rear light LEDs (supplied with Stage 89 and 90) and Push the other rear light LED into the hole on the right-hand side push the bulb end through the hole next to the raised screw hole on in the same way.
  • Page 14 Stage 93: Assembling the Boot Compartment and Installing the Rear Lights Check that the lenses are fully inserted into the housings so that they are aligned correctly. S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 15 Stage 94: Fitting the Window Grille and the Boot Compartment Next you’ll fit the speaker into the boot compartment and then install it in the rear body. Afterwards, you’ll attach the characteristic rear window grille of your Lamborghini Miura. S T A G E 9 4 P A R T S L I S T Name Rear reinforcement structure Rear window grille...
  • Page 16 Stage 94: Fitting the Window Grille and the Boot Compartment Take the boot compartment assembled in Stage 93 and place it on Position the speaker (supplied with Stage 93) in the circular recess your work surface as shown. Note there is a circular recess for fitting inside the boot, so that the wiring leads to your left (arrow), as shown the speaker (circled).
  • Page 17 Stage 94: Fitting the Window Grille and the Boot Compartment TYPE B TYPE B Secure the speaker in place by driving 2x Type B screws (supplied with Now take the boot compartment cover (supplied with Stage 93) and Stage 93) through the holes of the support. place it over the speaker, with the raised screw holes facing down.
  • Page 18 Stage 94: Fitting the the Window Grille and the Boot Compartment Fit the pins of the hinge into the holes of the compartment Press firmly on the hinge until it sits flush with the raised holes. You (highlighted in steps 7 and 8), so that it is inclined towards the reverse can see that it is inclined towards the reverse light.
  • Page 19 Stage 94: Fitting the Window Grille and the Boot Compartment TYPE B Now take the rear reinforcement structure. Starting with the wide Fix the right-hand side of the structure to the right body bulkhead ends, push the structure against the compartment (arrows), then using a Type B screw.
  • Page 20 Stage 94: Fitting the Window Grille and the Boot Compartment S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 21 Stage 95: Fitting the Rear Body and Wheel Arches The last step for constructing the rear body is to fix the wheel arches. Once that’s done, you’ll mount it onto the main assembly. S T A G E 9 5 P A R T S L I S T Name Left rear wheel arch Right rear wheel arch...
  • Page 22 Stage 95: Fitting the Rear Body and Wheel Arches Take the rear body assembly and place it on your work surface upside down, along with the left and right wheel arches as shown. Locate the fixing points: three screw holes (arrows) and a rectangular recess (inset) located underneath the lip of the body (circled) on either side. Note the protruding tabs on the arches (blue arrows) that fit into the rectangular recesses.
  • Page 23 Stage 95: Fitting the Rear Body and Wheel Arches TYPE S TYPE B Take a second Type B screw and use it to secure the wheel arch to the Finally, use a Type S screw to fix the wheel arch to the rear body. Check body bulkhead.
  • Page 24 Stage 95: Fitting the Rear Body and Wheel Arches Now you’ll attach the rear body to the main assembly. Place the assembly as shown on your work surface, noting the hinges at the rear that were fitted in Stage 84 (arrows). Lay the rear body on top of the central body, starting at the rear and fitting it flush with the roof and B-pillars.
  • Page 25 Stage 95: Fitting the Rear Body and Wheel Arches Holding the bodies together, carefully flip the model upside down. Insert the two hinges highlighted in step 8 into the corresponding holes of the boot compartment (inset, circled), as indicated by the arrows. TYPE B TYPE B Secure the right-hand side hinge using a Type B screw.
  • Page 26 Stage 95: Fitting the Rear Body and Wheel Arches Check the rear body opens and closes smoothly and that the fit is If it is necessary to adjust the closure, you must detach the rear part of flush between the two parts. the bodywork from the two hinges and adjust the two screws of the support plate shown in the photo.
  • Page 27 Stage 96: Attaching the Wheels and Adding the Bertone Logo In this stage you’ll fit the four wheels of your model to the wheel hubs and add the beautifully detailed Bertone logo and script to the left-hand side of the body. S T A G E 9 6 P A R T S L I S T Name Wheel rim...
  • Page 28 Stage 96: Attaching the Wheels and Adding the Bertone Logo Take the wheel rim and insert it into the tyre as shown. Push the rim fully into the tyre and work the edges until the lip of the tyre is flush with the rim on both sides. Take the main body assembly and place it on your work surface.
  • Page 29 Stage 96: Attaching the Wheels and Adding the Bertone Logo Retrieve the other three tyres assembled previously, along with 4x Type I screws (inset). On the inside of the wheel rims are two notches (arrows). The notches correspond with the two lugs on each of the outer brake pads (arrows).
  • Page 30 Stage 96: Attaching the Wheels and Adding the Bertone Logo TYPE I Fit one of the wheels onto the front left brake pad, aligning the Use one of the Type I screws to fix the wheel in place. Tighten the notches with the lugs.
  • Page 31 Stage 96: Attaching the Wheels and Adding the Bertone Logo TYPE I TYPE I On the other side of the model, fix the last two wheels in place using 2x Type I screws. Now take the Bertone logo and script. The script has two small silver On the left-hand side of the model, locate the two holes in the central pins on the back.
  • Page 32 Stage 96: Attaching the Wheels and Adding the Bertone Logo S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 33 Stage 97: Adding the Battery Compartment and the Shield Emblem For this stage you’ll work on the bottom floor panel by adding the battery compartment and fixing the switch in place. You’ll also fix the shield emblem onto the front body. S T A G E 9 7 P A R T S L I S T Name Bottom floor panel...
  • Page 34 Stage 97: Adding the Battery Compartment and the Shield Emblem Take the front body and place it on your work surface. Note the two Retrieve the emblem (supplied in Stage 4). There are two pins on the holes on the nose for fitting the emblem (circled). back of the emblem (inset, arrows).
  • Page 35 Stage 97: Adding the Battery Compartment and the Shield Emblem Next take the battery compartment with a switch. There are two Fit the battery compartment into the shaped hole in the bottom floor mounting points on the side (arrows). panel, aligning the mounting points with the raised screw holes. TYPE B TYPE B Start to secure the compartment in place by driving a Type B screw...
  • Page 36 Stage 97: Adding the Battery Compartment and the Shield Emblem TYPE O Next take the switch and fit it into the rectangular recess in the middle Secure the switch in place using 2x Type O screws. of the floor panel as shown. Ensure it is oriented correctly, with the two wire connections closer to the battery compartment (arrows).
  • Page 37 Stage 97: Adding the Battery Compartment and the Shield Emblem Turn the battery compartment cover upside down and fit the washer Turn the bottom floor panel over and locate the two slots by the over the shaft of the screw (arrow). battery compartment for inserting the cover (arrows).
  • Page 38 Stage 97: Adding the Battery Compartment and the Shield Emblem S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 39 Stage 98: Fitting the Tailpipes and Connecting the Electrics As well as fitting the tailpipes to the rear body, you’ll now connect up the wires coming from the rear body of your model to the circuit board. The side skirts supplied will be used in the final stage and can be kept aside for now.
  • Page 40 Stage 98: Fitting the Tailpipes and Connecting the Electrics Retrieve the main assembly and place it upside down on your work The tailpipes are supplied in bags marked ‘R’ for right and ‘L’ for left. surface with the rear end facing you. There are two pairs of holes on They have two silver pins (arrows) for fitting into the holes in the rear the rear body (arrows) for mounting the tailpipes.
  • Page 41 Stage 98: Fitting the Tailpipes and Connecting the Electrics Locate the wire plugged into connection 7 (arrow) of the circuit board. Gently remove the plug in connection 7. Take the extension cable (supplied in Stage 97) and plug the male end Pass the female end of the extension cable under the crossbar and into connection 7 as shown.
  • Page 42 Stage 98: Fitting the Tailpipes and Connecting the Electrics You’ll now connect the wires from the rear body. Start with the right Continue to thread the wire by passing it under the rear lower rear light (white plug, black panel) and pass it under the exhaust pipe, suspension arm (arrow).
  • Page 43 Stage 98: Fitting the Tailpipes and Connecting the Electrics Guide the wire along the shaft and under the crossbar (arrow). Plug the right rear light wire into connection 12 (arrow). For the left rear light (white plug, black panel), take the end of the wire Lead the wire underneath the lower suspension arm (arrow).
  • Page 44 Stage 98: Fitting the Tailpipes and Connecting the Electrics Guide the wire under the frame and through into the central shaft Pass the wire under the crossbar, then plug into connection 11 (arrow). (arrow) and lead it towards the circuit board. Finally, take the speaker wire (white plug, brown panel) and guide it along the same path as the right rear light wire.
  • Page 45 Stage 98: Fitting the Tailpipes and Connecting the Electrics S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...
  • Page 46 Stage 99: Preparing the Windscreen After fitting the wheel hubs onto the rims, you’ll prepare the windscreen by fixing the glass into the trim. You’ll then place the “In rodaggio” sticker onto the glass, ready for the windscreen to be installed in the final stage.
  • Page 47 Stage 99: Preparing the Windscreen Place the main assembly onto your work surface. The outer rims of the wheel have a raised circle around the screws which will be used for fitting the wheel hubs (inset, arrow). Retrieve the four hub caps (supplied with Stage 96). Check the edges Fit one of the hub caps over the raised circle of one of the wheels as for excess paint and remove using a hobby knife if necessary.
  • Page 48 Stage 99: Preparing the Windscreen Fit the remaining hub caps to the other wheels in the same way. Now take the windscreen trim and lay it on your work surface as shown. The double-sided adhesive tape for fixing the windscreen must be applied to the lip on the inside (concave) part of the windscreen trim, as indicated by the arrows.
  • Page 49 Stage 99: Preparing the Windscreen Take the double-sided adhesive tape for fitting the windscreen and place it on your work surface in the orientation shown. There are two of each piece supplied so that if one gets damaged you can use the spare one. Arrange the double-sided adhesive around the trim as shown in the photo, paying attention to the numbering of the individual pieces shown in the left image.
  • Page 50 Stage 99: Preparing the Windscreen Now take the windshield, which is covered with protective films: one Press the side of the windscreen without the protective film into the transparent and one green. Remove the transparent protective sheet. trim. Start with the top corners (arrows), then press the screen into Be sure to handle the windscreen by holding it by the outer edges to the lip, working around the trim slowly so that the screen fits into the avoid leaving fingerprints on the unprotected surface.
  • Page 51 Stage 99: Preparing the Windscreen Take the sticker and carefully remove its backing paper. Hold the Place the sticker as shown in the windscreen’s upper corner on the sticker with tweezers to avoid damaging it once removed. passenger side. Make sure the area is clean of any dust or fingerprints before sticking.
  • Page 52 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details The final stage of your Lamborghini Miura build is to attach the front body and connect up the wiring. You’ll then fit the bottom floor panel and side skirts, add some final details around the model, then finish by applying the logo stickers...
  • Page 53 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details To begin the final stage of your build, retrieve the front body assembly. Place the main assembly nearby on your work surface and ensure the rear body is secured with masking tape (arrows).
  • Page 54 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Use masking tape to hold the front body in place, applying pieces Carefully turn the assembly over then fit the two mounting brackets around all sections that align with the central body. onto the screw holes in the frame (circled).
  • Page 55 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details To connect the headlights, first locate the plug from the left headlight Carefully lift up the radiator pipe and fit the plug through it (arrow). and pass it under the suspension arm (arrow)..
  • Page 56 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Next retrieve the bottom floor panel. The switch has a loose plug Guide the wire under the crossbar as before and plug the switch into (arrow) to connect to the circuit board before fitting the panel.
  • Page 57 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details TYPE K TYPE K Fix the right-hand side using a Type K screw. Use a Type K screw to secure the left-hand side in the same way. TYPE B TYPE B Drive 2x Type B screws (supplied with Stage 97) into the raised screw holes either side of the floor panel.
  • Page 58 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details TYPE A Finish fixing the floor panel using 2x Type A screws (supplied with Stage 97) in the holes located either side of the battery compartment. Retrieve the two side skirts (supplied with Stage 98).
  • Page 59 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Before fitting them, note the fixing points for the skirts: on the lower Place the assembly upright on your work surface and open the driver’s edge there are two holes to be coupled to the floor pins (circled);...
  • Page 60 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Take the chassis and engine number plate (inset) and remove the Take the front number plate and its support. Check the number plate backing paper. Open the front hood and position the plate on the for any excess paint and remove if necessary.
  • Page 61 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details LOGO SCRIPT Apply the template to the right-hand side of the model, placing it Now take the double-sided adhesive tape for the Bertone logo and between the door and the rear of the body as shown.
  • Page 62 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Next take one of the pieces of adhesive tape for the Bertone logo and With the aid of the template, position the logo above the script. remove it from its backing.
  • Page 63 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Take the two door stop shims and the double-sided adhesive tape (top Next you’ll mount the windscreen. Place the main assembly on your image). Remove one of the circles of tape from its backing and stick it work surface with the front facing you.
  • Page 64 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Once the tape is in place, peel the paper off each piece to reveal the adhesive as shown. Press the pins highlighted in step 40 into the holes highlighted in step 39 to fit the windscreen. Push down firmly on the sections with double-sided tape to adhere the windscreen in place.
  • Page 65 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Using tweezers, take the two washer nozzles (inset) and push firmly Fit the remaining washer nozzle into the left-hand side hole in the to fit one of them into the right-hand side hole highlighted in the same way.
  • Page 66 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details The last few steps are to apply the logos to the rear of the model. First, take the rear logo templates and separate them from their backing. Apply them to the rear body as shown, using the rear lights as a guide for fitting them in place (arrows).
  • Page 67 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details Press firmly down on the two stickers to ensure they have adhered, then slowly remove the transparent film that protects the stickers using a pair of tweezers. You may wish to have a cocktail stick to hand in order to gently press the sticker back if any part of it begins to peel away with the film.
  • Page 68 Stage 100: Attaching the Front Body, the Side Skirts, the Number Plate and Adding Details S T A G E C O M P L E T E AGORAMODELS LAMBORGHINI MIURA...

  • Page 69: Electronic Functions

    Installing the Batteries and Operating the Electrics ELECTRONIC FUNCTIONS Button Location Function Engine ignition sound. Note that all functions below Ignition key require the key to be inserted to operate. Indicator/horn lever Headlights and rear lights (pull) Indicator/horn lever Horn sound (push) Accelerator pedal Accelerator sound...
  • Page 70 Installing the Batteries and Operating the Electrics To insert the batteries, turn the model over and remove the battery Insert three AAA batteries, orienting them as indicated by the compartment cover. To do this, you have to loosen the cover screw markings inside the battery compartment.
  • Page 71 Installing the Batteries and Operating the Electrics While either or both of the doors are open, the interior light on the roof Pressing the accelerator pedal (red arrow) will activate the acceleration will illuminate. sound. By pressing on the brake pedal (blue arrow), the rear lights will illuminate (inset).
  • Page 72 Build Complete! Build Complete! We hope you have enjoyed building your Lamborghini Miura P400 S. Don’t forget, when you choose your next model the first Pack is absolutely free! Go to agoramodels.com for more details. Warning: to keep your model in pristine condition please keep out of direct sunlight. AGORAMODELS LAMBORGHINI MIURA...
