B U I L D
STAGE 49: INSTALLING THE SILENCER
STAGE 50: LEFT FRONT WHEEL
STAGE 51: LEFT FRONT WHEEL
STAGE 52: LEFT FRONT WHEEL
Pack 07
I N S T R U C T I O N S
STAGE 53: LEFT FRONT WHEEL
STAGE 54: RIGHT REAR WHEEL
STAGE 55: RIGHT REAR WHEEL
STAGE 56: RIGHT REAR WHEEL
Advertisement
Related Manuals for Agora Models Pack 07
Summary of Contents for Agora Models Pack 07
- Page 1 Pack 07 B U I L D I N S T R U C T I O N S STAGE 49: INSTALLING THE SILENCER STAGE 53: LEFT FRONT WHEEL STAGE 50: LEFT FRONT WHEEL STAGE 54: RIGHT REAR WHEEL STAGE 51: LEFT FRONT WHEEL...
- Page 2 Advice from the experts Spare screws are included with each part. Occasionally, you may be instructed to keep spare or unused screws for a later stage. Keep these spares in a safe place and label them correctly. Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary slightly.
- Page 3 Stage 49: Installing the silencer In this stage you’ll assemble and attach the silencer that forms the middle part of the exhaust system. S T A G E 4 9 P A R T S L I S T Name Silencer upper half Silencer lower half Screws type AG06 x7...
- Page 4 Stage 49: Installing the silencer S T E P 1 Take the upper and lower half of the silencer and align them as shown, Place the upper half onto the lower half of the silencer, so that the noting that the holes and longer posts (circled) are closer to one end. long posts fit through the holes (circled).
- Page 5 Stage 49: Installing the silencer AG06 Push the pegs on the silencer assembly into the holes on the floor Flip over the floor panel assembly and secure the silencer assembly in panel assembly. place using 2 x AG06 screws as shown. S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
- Page 6 Stage 50: Left Front Wheel There is no assembly in this stage, unpack the wheel components and move straight to Stage 51. S T A G E 5 0 P A R T S L I S T Name Inner spokes x24 Wheel rim (outer) Inner spokes x24 Wheel rim...
- Page 7 Stage 51: Left Front Wheel The process for assembling this wheel is exactly the same as for your first and second wheel. Don’t forget, the trick is to adjust the tension on the spokes by gently pressing and twisting the wheel centre.
- Page 8 Stage 51: Left Front Wheel S T E P 1 Take the wheel centre and note that there is a small notch that aligns Fit the wheel centre onto the jig. with a corresponding tab on the jig (arrows). The jig is used here to assist with building the wheel and will be removed towards the end of the wheel-build.
- Page 9 Stage 51: Left Front Wheel Inner row Inner row Angled tip Narrow tooth Flat head Wide tooth Before you begin, note that the inner edge of the spoke retainer Pull the spoke through the hole and hook the tip around the nearest ring has a series of ‘teeth’, alternating in size (see picture 6).
- Page 10 Stage 51: Left Front Wheel This is how your wheel should look after fitting the first row of spokes. Check that all the spokes have been fitted to the innermost row of the wheel centre. Next, you will fit spokes to the uppermost row. Start in the same way, threading the tip of a spoke through a hole in The spoke tips will now face in the opposite direction to those fitted the uppermost row.
- Page 11 Stage 51: Left Front Wheel Repeat steps 11 & 12 to fit the second spoke in a hole adjacent to the Continue to fit all the spokes in the same way, all the way round the first spoke on the upper row. upper row, ensuring that they hook around a wide tooth.
- Page 12 Stage 51: Left Front Wheel Hold the retainer in position so that the spokes are secured as you fit Keep holding everything together as you fit the remaining an AG02 screw. 3 x AG02 screws. AG02 AG02 All four screws have been fitted and the spokes are now held securely Gently prise the wheel off the jig.
- Page 13 Stage 51: Left Front Wheel S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
- Page 14 Stage 52: Left Front Wheel In this stage you’ll continue to lace the spokes to create a beautiful work of art. S T A G E 5 2 P A R T S L I S T Name Wheel rim (inner) Spacer ring Spokes type B x12 Screws type AG03 x5...
- Page 15 Stage 52: Left Front Wheel S T E P 1 Take the spacer ring and align it over the wheel from Stage 51. There is Lower the ring onto the wheel and press firmly until it clicks into place. a hole on the ring with a corresponding peg on the wheel (arrows) to ensure the correct fit.
- Page 16 Stage 52: Left Front Wheel Wide tooth Turn the wheel over and check that the tip will hook onto a wide tooth Once you are happy that the first spoke is fitted correctly, thread the on the opposite side. If it doesn’t fit a wide tooth, start again, threading next spoke through an adjacent hole in the lower row, but this time, the spoke through the next diamond-shaped hole along.
- Page 17 Stage 52: Left Front Wheel The 12 spokes should poke out on the opposite side of the wheel like Fit the type B spokes to the outer row of the wheel centre, just above this. Leave them all loose for now. the type A spokes.
- Page 18 Stage 52: Left Front Wheel Continue to thread the type B spokes all the way around the outer row, Use a piece of cotton wool or kitchen paper to hold the pin ends of the pushing the spoke through alternate diamond-shaped openings. This spokes in place in the inner and outer rows of the wheel centre.
- Page 19 Stage 52: Left Front Wheel Spokes A and B are correctly hooked in place around the teeth. Take the inner wheel rim and align the four screw holes, and the pin with its corresponding hole (arrows). Prepare 4 x AG03 screws and a screwdriver.
- Page 20 Stage 52: Left Front Wheel S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
- Page 21 Stage 53: Left Front Wheel In this stage you’ll fix the left front wheel to the subframe. S T A G E 5 3 P A R T S L I S T Name Tyre Washer Screws type AM07 x2 Tyre Washer AM07 x2...
- Page 22 Stage 53: Left Front Wheel S T E P 1 Take the completed wheel from Stage 52. Prepare a hot water bath by Carefully remove the tyre from the water bath using tongs or tweezers filling a small bowl with boiling water. Soak the tyre in the water for 2 - the tyre will be very hot! Shake off any excess water and dab on minutes.
- Page 23 Stage 53: Left Front Wheel The tyre has now been fully fitted to the wheel and is now ready to fix Holding the wheel as shown, align the two lugs on the wheel centre to the front subframe assembly from Stage 37. with the two notches in the left front axle.
- Page 24 Stage 53: Left Front Wheel AM07 Secure the washer and left wheel in place using a type AM07 screw. S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
- Page 25 Stage 54: Right Rear Wheel There is no assembly in this stage, unpack the wheel components and move straight to Stage 55. S T A G E 5 4 P A R T S L I S T Name Inner spokes x24 Wheel rim (outer) Inner spokes x24 Wheel rim...
- Page 26 Stage 55: Right Rear Wheel In this stage you’ll begin assembling the rear right wheel. The process is exactly the same as for the previous wheels. S T A G E 5 5 P A R T S L I S T Name Spoke retainer ring Wheel centre...
- Page 27 Stage 55: Right Rear Wheel S T E P 1 Take the wheel centre and note that there is a small notch that aligns Fit the wheel centre onto the jig. with a corresponding tab on the jig (arrows). The jig is used here to assist with building the wheel and will be removed towards the end of the wheel-build.
- Page 28 Stage 55: Right Rear Wheel Outer row Inner row Angled tip Narrow tooth Flat head Wide tooth Before you begin, note that the inner edge of the spoke retainer Pull the spoke through the hole and hook the tip around the nearest ring has a series of ‘teeth’, alternating in size (see picture 6).
- Page 29 Stage 55: Right Rear Wheel This is how your wheel should look after fitting the first row of spokes. Check that all the spokes have been fitted to the innermost row of the wheel centre. Next, you will fit spokes to the uppermost row. Start in the same way, threading the tip of a spoke through a hole in The spoke tips will now face in the opposite direction to those fitted the uppermost row.
- Page 30 Stage 55: Right Rear Wheel Repeat steps 11 & 12 to fit the second spoke in a hole adjacent to the Continue to fit all the spokes in the same way, all the way round the first spoke on the upper row. upper row, ensuring that they hook around a wide tooth.
- Page 31 Stage 55: Right Rear Wheel Hold the retainer in position so that the spokes are secured as you fit Keep holding everything together as you fit the remaining an AG02 screw. 3 x AG02 screws. AG02 AG02 All four screws have been fitted and the spokes are now held securely Gently prise the wheel off the jig.
- Page 32 Stage 55: Right Rear Wheel S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
- Page 33 Stage 56: Right Rear Wheel Continue to lace the spokes exactly as before. The tyre will be supplied in Stage 57 in your next Pack. S T A G E 5 6 P A R T S L I S T Name Spacer ring Wheel rim (inner)
- Page 34 Stage 56: Right Rear Wheel S T E P 1 Take the spacer ring and align it over the wheel from Stage 55. There is Lower the ring onto the wheel and press firmly until it clicks into place. a hole on the ring with a corresponding peg on the wheel (arrows) to ensure the correct fit.
- Page 35 Stage 56: Right Rear Wheel Wide tooth Turn the wheel over and check that the tip will hook onto a wide tooth Once you are happy that the first spoke is fitted correctly, thread the on the opposite side. If it doesn’t fit a wide tooth, start again, threading next spoke through an adjacent hole in the lower row, but this time, the spoke through the next diamond-shaped hole along.
- Page 36 Stage 56: Right Rear Wheel The 12 spokes should poke out on the opposite side of the wheel like Fit the type B spokes to the outer row of the wheel centre, just above this. Leave them all loose for now. the type A spokes.
- Page 37 Stage 56: Right Rear Wheel Continue to thread the type B spokes all the way around the outer row, Use a piece of cotton wool or kitchen paper to hold the pin ends of the pushing the spoke through alternate diamond-shaped openings. This spokes in place in the inner and outer rows of the wheel centre.
- Page 38 Stage 56: Right Rear Wheel Spokes A and B are correctly hooked in place around the teeth. Take the inner wheel rim and align the four screw holes, and the pin with its corresponding hole (arrows). Prepare 4 x AG03 screws and a screwdriver.
- Page 39 Stage 56: Right Rear Wheel S T A G E C O M P L E T E AGORAMODELS JAGUAR E-TYPE...
