Rear View

Feature Description
Power Supplies Two redundant power supply modules, PWS1 on the right, PWS2 on the left
Fans Five system fans
Fans
Figure 1-3. SYS-110P-FRN2T: Rear View
Fans
Figure 1-4. 110P-FRDN2T: Rear View
System Features: Rear
13
Chapter 1: Introduction
Power Supply 2 Power Supply 1
Power Supply 2 Power Supply 1
