Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
T-Harness is not compatible.
compatible
Vehicle Takeover
Firmware notes
The following settings must be made for the 2016 - 2019 Chevrolet Malibu Hybrid (Smart Key). The Remote Starters tachometer
Š
setting set Engine Checking Mode to OFF and Cranking Time (in seconds) to 4.0 seconds or similar.
Remote Start: Wait 10 seconds after remote start shutdown before remote starting the vehicle again.
Š
Remote Start Ready (RSR) installations
Š
Š Not compatible with vehicles equipped with a manual transmission.
Š Enables the interface module to remote start the vehicle completely on its own. Consequently, there is no need for an aftermarket
or an OEM remote starter in order to start the vehicle from a distance.
Key2GO is mandatory to control the immobilizer override in this firmware.
Š
SmartStart Compatible: SmartStart is equipped with D2D, which means it can be connected to an interface module and used in
Š
Remote Start Ready (RSR) mode without the use of a remote starter. See "Module programming" for more information.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
5
403.GM9 2.48 2022 Cadillac XT4 (Smart Key)
©2023 Directed. All rights
Refer to the Quick Reference Guide section for more details.
Keys required for 1 Keys required
programming for operation
