Appendix - Insulet Omnipod GO User Manual

Appendix

Pod Specifications
Size: 1.53" wide x 2.05" long x 0.57" high (3.9cm x 5.2cm x 1.45cm)
Weight (without insulin): 0.92 oz (26 grams)
Duration of use: up to 72 hours
Operating temperature range: Pod operating environment of
41°F to 104°F (5°C to 40°C).
Note: The Pod temperature equilibrates from 73°F to 100°F
(23°C to 38°C) when worn on the body.
Startup temperature: above 50°F (10°C)
Storage temperature range: 32°F to 86°F (0°C to 30°C)
Transport temperature range: -13°F to 140°F (-25°C to 60°C)
Warm-up time 32°F to 68°F (0°C to 20°C): 7 minutes
Cooldown time: No time is required for cooldown from maximum
storage temperature 86°F (30°C) to operating temperature.
Reservoir volume (deliverable): 180 units
Cannula insertion depth: 0.16-0.28 in (4-7 mm)
Depth of insulin infusion: ≥ 0.16 in (4 mm)
IP (Ingress Protection) rating for moisture and dust: IP28
(protected from touch by fingers and objects 12.5 millimeters or
larger; protected from water to a depth of up to 25 feet (7.6 meters) for
up to 60 minutes)
Insulin concentration: U-100
Alarm type:
Audible: Output: ≥ 45 db(A) at 1 meter
Visual: Output: tri-color LED (Red, Amber, Green)
Sterilizing agent: Sterilized using ethylene oxide
Operating relative humidity range: 20 to 85%, non-condensing
Storage relative humidity range: 20 to 85%, non-condensing
67
