6.2 Full Pinout Table

The full pinout of the Arduino Due is available in the following tables.

6.2.1 Board's 24-Pin Header

Pin Function
1 NC
2 IOREF
3 Reset
4 +3V3
5 +5V
6 GND
7 GND
8 VIN
9 A0
10 A1
11 A2
12 A3
13 A4
14 A5
15 A6
16 A7
17 A8
18 A9
19 A10
20 A11
21 DAC0
22 DAC1
23 CANRX
24 CANTX
9 / 27
Type Description
NC Not Connected
IOREF Reference for digital logic voltage - connected to 3.3 V
Reset Reset
Power +3V3 Power Rail
Power +5V Power Rail
Power Ground
Power Ground
Power Voltage Input
Analog Analog input 0 / GPIO
Analog Analog input 1 / GPIO
Analog Analog input 2 / GPIO
Analog Analog input 3 / GPIO
Analog Analog input 4 / GPIO
Analog Analog input 5 / GPIO
Analog Analog input 6 / GPIO
Analog Analog input 7 / GPIO
Analog Analog input 8 / GPIO
Analog Analog input 9 / GPIO
Analog Analog input 10 / GPIO
Analog Analog input 11 / GPIO
Analog Digital to Analog Converter 0
Analog Digital to Analog Converter 1
Digital CAN Bus Receiver
Digital CAN Bus Transmitter
