4.4 Cable and adaptator information

4.4 Cable and adaptor information

A large choice of cables and adaptors are compatible with the QuickVu. Please refer to the hardware
specifications chapter to find the most suitable cables for your operations.
4.5 Hardware specifications
4.5.1 Signal descriptions
For each type of signal, here are the levels and the impedance accepted by the QuickVu.
Analog SDTV
Type Levels
Composite 0,7 Vpp + 0,3 Vpp
S. Video Y = 0,7 Vpp + 0,3 Vpp
C = 0,7 Vpp
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
R, G, B = 0,7 Vpp
RGBS
Analog EDTV
Type Levels
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
R, G, B = 0,7 Vpp
RGBS
Analog HDTV
These formats are compatible with bi-level and tri-
level sync on 1 or 3 wires.
Type Levels
YUV Y = 0,7 Vpp ±0,3 Vpp
U = 0,7 Vpp ±0,3 Vpp
V = 0,7 Vpp ±0,3 Vpp
RGsB R = 0,7 Vpp ±0,3 Vpp
G = 0,7 Vpp ±0,3 Vpp
B = 0,7 Vpp ±0,3 Vpp
14
Impedance
75 Ω
75 Ω
75 Ω
75 Ω
R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Impedance
75 Ω
75 Ω
R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Impedance
75 Ω
75 Ω
Digital SDTV
Type
SD-SDI YUV - 10 bits – 4.2.2 - 270 Mb/s
No payload ID management
DVI RGB ou YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
Digital EDTV
Type
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
Digital HDTV
Type
HD-SDI YUV - 10 bits – 4.2.2 – 1,485Gb/s and
Input and output payload ID management
3G-SDI YUV - 10 bits – 4.2.2 – 2,97Gb/s and
Input and output payload ID management
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI® RGB or YUV – 8 bits – 4.4.4 or 4.2.2
Characteristics
Only A-level type
– 16/235 – TMDS
Characteristics
– 16/235 – TMDS
Characteristics
1,485/1.001Gb/s
Only A-level type
for HDTV format only
2,97/1.001Gb/s
Only A-level type
for HDTV format only
– 16/235 – TMDS
