Analog way QuickVu User Manual page 15

Analog computer
Type Levels
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
R, G, B = 0,7 Vpp
RGBS
S = 0,3 Vpp 75Ω or S = TTL
R, G, B = 0,7 Vpp
RGBHV
4.5.2 Supported video formats
The QuickVu can support all the following video formats:
SDTV formats
Standard
NTSC
PAL
SECAM
EDTV formats
Standard
480p
576p
HDTV formats
Standard
720p
1035i
1080i
1080sF
1080p
Cinema formats
Format
DCDM
4.5.3 Computer formats
Important: The maximum pixel clock frequency is 165 MHz. Supported formats include 1920x1200 @ 60hz
RB, 1600x1200 @60hz RB, 2048x1152 @60hz RB.
4.5.4 Input Computer formats
The QuickVu inputs support GTF (version 1.1), CVT (version 1.1) and DMT (version 1.0 rev 12) standards. All
others non-standard formats are supported via the custom format capability of the framework.
Impedance
75 Ω
R, G, B = 75 Ω
R, G, B = 75 Ω
H = TTL and V = TTL
Size Vertical frequency
525/480i 59.94Hz/60Hz
625/576i
625/576i
Size Vertical frequency
525/480p 59.94Hz/60Hz
625/576p
Size
1280 x 720 23.97Hz/24Hz/25Hz/29,97Hz/30Hz/50Hz/59.94Hz/60Hz
1920 x 1035
1920 x 1080
1920 x 1080
1920 x 1080 23.97Hz/24Hz/25Hz/29,97Hz/30Hz/50Hz/59.94Hz/60Hz
Size
2048 x 1080
Digital computer
Type
DVI
HDMI®
Horizontal frequency
15,735 KHz
50Hz 15.625 KHz
50Hz 15.625 KHz
Horizontal frequency
31.47 KHz
50Hz 31.25 KHz
Vertical frequency
59.94Hz/60Hz
50Hz/59.94Hz/60Hz
50Hz/59.94Hz/60Hz
Vertical frequency
24Hz
4.5.2 Supported video formats
Characteristics
RGB – 8 bits – 4.4.4 – 0/255 - TMDS
RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 0/255 – TMDS
15
