Clearances - Heat&Glo FOUNDATION FDN-4-PIER Installation And Operating Manual

MODEL # DESCRIPTION
FDN-4-PIER
FDN-5-PIER
FDN-6-PIER
FDN-7-PIER
B. CLEARANCES
WARNING: NON-COMBUSTIBLE ZONE: USE ONLY NON-COMBUSTIBLE MATERIAL IN THIS AREA FOR ENTIRE WIDTH OF
FIREPLACE. DO NOT USE WOOD, SHEETROCK, ETC., IN THIS ZONE. SEE FIGURE 2B
NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED.
Refer to Section 5 (Non-Combustible Zone) and Section 10 (Finishing) for more information.

CLEARANCES

From unit left & right sides
To flooring under fireplace
Unit top to ceiling
Unit side to adjacent sidewall
From appliance front*
Heat & Glo • FDN-4-PIER, FDN-5-PIER, FDN-6-PIER, FDN-7-PIER Installation Manual • 16400-9803 Rev. o • 4/21
6
2 - FIREPLACE SPECIFICATIONS
B-VENT
4X2 PIER 8"
5X2 PIER 8"
6X2 PIER 10"
7X2 PIER 10"
SPECIFICATIONS TABLE
OA REG PV IN-LINE PV
10" PVK-45
10" PVK-45
10" PVK-67
10" PVK-67
BTU'S NG ORIFICE
PVI-45 60,000 (3X) #43
PVI-45 80,000 (4X) #43
PVI-67 100,000 (5X) #43
PVI-67 120,000 (6X) #43
1"
0
6"
1"
*See note below
PROPANE
ORIFICE
(3X) #55
(4X) #55
(5X) #55
(6X) #55
25mm
0
152mm
25mm
