CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity.
High temperatures could cause a fire.
INSTALLER: Leave this manual with the appliance, not inside the appliance.
CONSUMER: Retain this manual for future reference. Do not store inside the appliance.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Heat & Glo • SL-3X/5X/7X/9X-IFT (-G, -TG, -S) Installation Manual • 2633-980 Rev. B • 6/20
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
Decorative barrier front must be ordered separately at
time of appliance purchase. See Section 3.A.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heat&Glo SL-3X-IFT
Summary of Contents for Heat&Glo SL-3X-IFT
- Page 1 Installation Manual Installation and Appliance Setup CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity. High temperatures could cause a fire. INSTALLER: Leave this manual with the appliance, not inside the appliance. CONSUMER: Retain this manual for future reference. Do not store inside the appliance. NOTICE: DO NOT discard this manual! WARNING: FIRE OR EXPLOSION HAZARD...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Installation Standard Work Checklist
Date Installed: Lot/Address: Location of Fireplace: Installer: Circle appropriate Model / Refractory Type Dealer/Distributor Phone # Model: SL-3X-IFT SL-5X-IFT/LP-IFT SL-7X-IFT/LP-IFT SL-9X-IFT Serial #: Refractory: G (Glass) S (Stratford) TG (Tranquil Greige) WARNING! Risk of Fire or Explosion! Failure to install appliance according to these instructions could lead to a fire or explosion. -
Page 4: Product Specific And Important Safety Information
Product Specific and Important Safety Information A. Appliance Certification C. BTU Specifications Minimum Orifice Models MODELS: Maximum Input Size Input BTU/h (U.S. or Canada) BTU/h (DMS) SL-3X-IFT-G SL-3X-IFT-TG SL-3X-IFT-S Includes all refractory SL-5X-IFT-G SL-5X-IFT-TG SL-5X-IFT-S SKU’S (-G/-TG/-S) SL-5XLP-IFT-G SL-5XLP-IFT-TG SL-5XLP-IFT-S SL-3X-IFT 21,000 11,500... -
Page 5: Non-Combustible Materials Specification
E. Non-Combustible Materials Specification Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof. Materials that are reported as passing ASTM E 136, Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750 ºC shall be considered non-combustible materials. -
Page 6: Requirements For The Commonwealth Of Massachusetts
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed I. -
Page 7: Getting Started
Getting Started A. Design and Installation Considerations B. Good Faith Wall Surface WARNING! Risk of Fire or Explosion! Read all instruc- tions before starting the installation. FIREPLACE TO CEILING OPENING Direct vent gas appliances are designed to operate with all 127°F combustion air siphoned from outside of the building and 123°F... - Page 8 Good Faith Guidelines for TV Installations Above Appliance TV recessed into the wall TV on the wall TV Wall Bracket Item Minimum Dimensions 2.5 inches 2 inches minimum to 3 inches maximum 18 inches Wall Brkt + TV Thickness + 2.5 inches Mantel Appliance...
-
Page 9: Tools And Supplies Needed
C. Tools and Supplies Needed D. Inspect Appliance and Components Before beginning the installation be sure that the following WARNING! Risk of Fire or Explosion! Damaged parts tools and building supplies are available. could impair safe operation. DO NOT install damaged, in- complete or substitute components. -
Page 10: Framing And Clearances
Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. HEAT MANAGEMENT Ø SYSTEMS ACCESS Ø Ø ELECTRICAL ACCESS GAS LINE ACCESS Appliance Dimensions Table SL-3X-IFT SL-5X-IFT SL-7X-IFT SL-9X-IFT Location Inches Millimeters Inches Millimeters Inches... - Page 11 Decorative barrier front must be ordered at time of fireplace purchase. If decorative barrier front is not present, contact dealer. Note: See Section 10 for hearth, mantel and finishing requirements. Barrier Mesh: Integral to Decorative Barrier Front 1-5/8 2-5/8 25-1/16 26-3/4 SL-3X-IFT FS-3 28-7/8 25-1/8 1-5/8 2-5/8 27-1/8 28-3/4 SL-5X-IFT FS-5...
- Page 12 CLEAN FACE DECORATIVE BARRIER FRONT IMPORTANT! This fireplace requires an installed decorative barrier front to prevent direct contact with the hot viewing glass. DO NOT operate the fireplace with the barrier removed. Decorative barrier front must be ordered at time of fireplace purchase. If decorative barrier front is not present, contact dealer.
- Page 13 Barrier Mesh: Integral to Decorative Barrier Front 1 IN. to 6 IN. Overlap Fit Finishing-Refer to Figure 10.10 24-7/16 16-1/8 29-1/16 1-1/8 5-13/16 27-5/16 29-3/8 28-3/4 SL-3X-IFT CHA-28 27-7/16 18-1/8 32-1/16 1-1/8 5-13/16 29-3/8 32-3/4 30-13/16 SL-5X-IFT CHA-32 32-7/16 20-1/2...
- Page 14 Barrier Mesh: Integral to Decorative Barrier Front 1 IN. to 6 IN. Overlap Fit Finishing-Refer to Figure 10.10 24-7/16 16-1/8 29-1/16 1-1/8 5-13/16 27-5/16 29-3/8 28-3/4 SL-3X-IFT HAL-28 27-7/16 18-1/8 32-1/16 1-1/8 5-13/16 29-3/8 32-3/4 30-13/16 SL-5X-IFT HAL-32 32-7/16 21-1/4...
- Page 15 CHATEAU FORGE DECORATIVE BARRIER FRONT IMPORTANT! This fireplace requires an installed decorative barrier front to prevent direct contact with the hot viewing glass. DO NOT operate the fireplace with the barrier removed. Decorative barrier front must be ordered at time of fireplace purchase. If decorative barrier front is not present, contact dealer.
- Page 16 ARCADIA DECORATIVE BARRIER FRONT IMPORTANT! This fireplace requires an installed decorative barrier front to prevent direct contact with the hot viewing glass. DO NOT operate the fireplace with the barrier removed. Decorative barrier front must be ordered at time of fireplace purchase. If decorative barrier front is not present, contact dealer.
- Page 17 IRON AGE DECORATIVE BARRIER FRONT IMPORTANT! This fireplace requires an installed decorative barrier front to prevent direct contact with the hot viewing glass. DO NOT operate the fireplace with the barrier removed. Decorative barrier front must be ordered at time of fireplace purchase. If decorative barrier front is not present, contact dealer.
- Page 18 Provisions must be made in advance to ensure fit within the framing. Models Min. 39-1/2 55-7/8 62-1/4 16-1/4 48-1/2 68-3/4 13-1/2 7-1/2 SL-3X-IFT 1003 1419 1118 1581 1232 1746 59-1/2 62-1/4 16-1/4 48-1/2 68-3/4 15-1/16 7-1/2...
- Page 19 Appliance Appliance Appliance Opening Opening Opening Opening (Height) (Width) Ceiling Required (Width) (Width) (Depth) (Depth) 8-5/8 32-3/4 16-1/4 16-1/4 SL-3X-IFT 8-5/8 34-3/4 16-1/4 16-1/4 SL-5X-IFT 8-5/8 38-1/4 16-1/4 16-1/4 SL-7X-IFT 1067 8-5/8 40-1/4 16-1/4 16-1/4 SL-9X-IFT 1022 1245 * Adjust framing dimensions for interior chase sheathing (such as sheetrock) C** Add 12 inches when rear venting with one 90º...
-
Page 20: Constructing The Appliance Chase
C. Constructing the Appliance Chase NOTICE: Install appliance on hard metal or wood surfaces extending full width and depth. DO NOT install directly on carpeting, vinyl, or any combustible material other than wood. WARNING! Risk of Fire! Maintain specified air space clearances to appliance and vent pipe: •... -
Page 21: Termination Location And Vent Information
Termination Location and Vent Information A. Approved Pipe B. Vent Termination Minimum Clearances WARNING Approved Pipe - Rigid WARNING! Risk of Fire, Delayed Ignition or Asphyxi- Fire Risk. ation. This appliance requires a separate vent. DO NOT Maintain vent clearance to combustibles as vent to a pipe serving any other appliance. - Page 22 OVERHANG 6 in. (minimum) up to 20 in. 18 in. minimum 152 mm/508 mm 457 mm 20 in. and over 0 in. minimum Wood or Fuel Oil Termination Cap WALL *Gas Termination * If two gas terminations are present, they may be level (B = 0 inches) provided A is a minimum of 6 inches.
-
Page 23: Vent Terminal Clearances
C. Vent Terminal Clearances = AREA WHERE TERMINAL IS NOT PERMITTED = AIR SUPPLY INLET = VENT TERMINAL H or i Electrical Service U.S.A. Installations: In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code. Canadian Installations: In accordance with the current CSA B149.1, Natural Gas and Propane Installation Code. U.S.A. -
Page 24: Use Of Elbows
D. Use of Elbows Diagonal runs have both vertical and horizontal vent as- pects when calculating the effects. Use the rise for the vertical aspect and the run for the horizontal aspect. See Figure 4.6. Two 45º elbows may be used in place of one 90º elbow. On 45º... -
Page 25: Use Of Flex Vent (Slp-Flex Series 6-5/8 Inch)
E. Use of Flex Vent (SLP-FLEX Series 6-5/8 Inch) The flex vent must be supported with the spacing between support intervals not exceeding 4 feet, with no more than 1/2 inch sag between supports. A support is required at each change in venting direction, and in any location where it is necessary to maintain the necessary clearance to combustibles. -
Page 26: Vent Diagrams
F. Vent Diagrams Measuring Standards: Vertical and horizontal measurements listed in the vent General Rules: diagrams and clearances for termination were made • SUBTRACT 3 ft from the total H measurement for each using the following standards: 90º elbow installed horizontally. •... - Page 27 Top Vent - Horizontal Termination H Maximum One Elbow V Minimum All Models Note: Use SLP Series 90º Elbow* 1 ft. 305 mm components only. 1/2 ft.* 152 mm 2 ft. 610 mm 1-1/2 ft.* 457 mm 3 ft. 914 mm Note: There MUST be a 25% 2-1/2 ft.* 762 mm...
- Page 28 Top Vent - Horizontal Termination - (continued) Two Elbows H Maximum V Minimum All Models 90º Elbow* NOT ALLOWED Note: Use SLP Series 1/2 ft.* 152 mm 1 ft. 305 mm components only. 1-1/2 ft.* 457 mm 2 ft. 610 mm 2-1/2 ft.* 762 mm 4 ft.
- Page 29 Top Vent - Horizontal Termination - (continued) Three Elbows Maximum Maximum Minimum Minimum All Models Note: Use SLP Series Elbow only** 1 ft. 305 mm 2 ft. 610 mm components only. 1/2 ft.** 152 mm 2 ft. 610 mm 4 ft. 1.2 m 1-1/2 ft.** 457 mm 3 ft.
- Page 30 Top Vent - Vertical Termination Exhaust Restrictor Instructions Exhaust restrictors are recommended for these vertically terminated products which have excessive draft. No Elbow Exhaust restrictors will compensate for high draft, and restore visual flame height. If the vent configuration has Note: Use SLP Series a total vertical of 15-60 feet, an exhaust restrictor may components only.
- Page 31 Top Vent - Vertical Termination - (continued) ALL MODELS Two Elbows Minimum Maximum Minimum Note: Use SLP Series 90º Elbow 1 ft. 305 mm components only. 1/2 ft. 152 mm 2 ft. 610 mm 1-1/2 ft. 457 mm 3 ft. 914 mm Note: There MUST be a 25% reduction in total H when...
- Page 32 Top Vent - Vertical Termination - (continued) Three Elbows ALL MODELS Maximum Minimum 90º Elbow 1-1/2 ft. 457 mm 1-1/2 ft. 457 mm Note: Use SLP Series components only. 1/2 ft.. 152 mm 1 ft. 305 mm 1-1/2 ft. 457 mm 2 ft.
- Page 33 Top Vent - Vertical Termination - (continued) Four 90º Elbows Note: There MUST be a 25% ALL MODELS reduction in total H when Min. Max. Min. Max. Min. using flex vent except when using the simple up and out 1-1/2 ft. 457 mm 4 ft.
- Page 34 Rear Vent - Horizontal Termination ALL MODELS No Elbow = 24 in. (610 mm) Maximum Note: Use DVP Series components only. Figure 4.20 Must use two 90º elbows for corner installations. The use Two 90º Elbows of two 90º elbows in a corner installation will affect space requirements.
- Page 35 Rear Vent - Horizontal Termination - (continued) Two Elbows ALL MODELS Maximum Minimum Maximum Back to Back 1-1/2 ft. 457 mm 1 ft. 305 mm 2-1/2 ft. 762 mm Elbows Note: Use DVP Series components only. 3-1/2 ft. 1.1 m 1 ft.
- Page 36 Rear Vent - Vertical Termination ALL MODELS One Elbow Minimum Maximum Elbow Only 1-1/2 ft. 457 mm Note: Use DVP Series components only. 1 ft. 305 mm 3-1/2 ft. 1.1 m 2 ft. 610 mm 5-1/2 ft. 1.7 m 3 ft. 914 mm 7-1/2 ft.
- Page 37 Rear Vent - Vertical Termination - (continued) Three Elbows ALL MODELS Maximum Minimum Maximum Note: Use DVP Series Back to Back 1-1/2 ft. 457 mm 1 ft. 305 mm 2-1/2 ft. 762 mm components only. Elbows 3-1/2 ft. 1.1 m 1 ft.
- Page 38 Coaxial to Colinear Venting OUTSIDE FACE OF WARNING! Risk of Fire! Coaxial to colinear venting con- FIREPLACE figuration may only be used in existing non-combustible chimney. Installation in any other venting application EXHAUST VENT PIPE could cause fire. The coaxial to colinear adapter (DV-46DVA-GCL) is ap- proved for installations into solid fuel masonry or factory TOP OF FIREPLACE built fireplaces that have been installed in accordance with...
- Page 39 Connecting the DV-46DVA-GCL Adapter to Appliance • Insert the two sections of flexible vent pipe down the existing chimney. WARNING! Risk of Fire, Explosion or Asphyxiation! • Attach one 3 ft section of stainless steel flex pipe to the Do NOT connect this gas appliance to a chimney flue exhaust collar on top of the DV-46DVA-GCL adapter with serving a separate solid fuel or gas burning appliance.
-
Page 40: Vent Clearances And Vent Framing
Vent Clearances and Vent Framing A. Vent Clearances to Combustibles WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles: • Between ceiling firestops • Between wall shield firestops • Around vent system Failure to keep insulation or other material away from vent pipe could cause overheating and fire. -
Page 41: Wall Penetration Framing/Firestops
(refer to 35-1/2 22-3/8 34-1/2 21-3/8 Inches Section 12.A) attached to them. SL-3X-IFT Millimeters • See Section 7.F for information for regarding the 24-3/8... -
Page 42: Ceiling Firestop/Floor Penetration Framing
C. Ceiling Firestop/Floor Penetra- tion Framing WARNING! Risk of Fire! DO NOT pack insu- lation around the vent. Maintain clearances to vent to prevent overheating. A ceiling firestop MUST be used between ATTIC ABOVE floors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. -
Page 43: Appliance Preparation
Appliance Preparation A. Vent Collar Preparation Note: Actual unit may look different than the fireplace shown CAUTION! Risk of Cuts, Abrasions or Flying Debris. in this section. Wear protective gloves and safety glasses during instal- lation. Sheet metal edges are sharp. NOTICE: Once appliance is set up for top or rear venting, it CANNOT be changed at a later time. - Page 44 NOTICE: Once the seal cap has been removed it CANNOT be reattached. 2 SCREWS Figure 6.7 To attach the first section of vent pipe, make sure to use the fiberglass gasket to seal between the first Figure 6.10 (Generic Fireplace Shown) Fold the center vent component and the outer fireplace wrap.
-
Page 45: Prepare For Heat Management
B. Prepare For Heat Management C. Securing and Leveling the Appliance NOTICE: Additional clearances are required for heat WARNING management systems installations. Provisions must be made in advance to ensure fit within the framing. Risk of Fire! • Heat management systems include Heat-Zone Gas and ®... -
Page 46: Non-Combustible Material Installation
D. Non-Combustible Material Installation WARNING! Risk of Fire! DO NOT remove factory-in- stalled non-combustible material. A non-combustible board is factory-installed above the fireplace opening. Do not remove. FACTORY-INSTALLED NON-COMBUSTIBLE BOARD DO NOT REMOVE 3 IN. Note: Diagonal dimensions (A) and (B) must be within 1/4 inch of each other. -
Page 47: Venting
Venting A. Assemble Vent Sections It is acceptable to use screws no longer than 1/2 in. (13 mm) to hold outer pipe sections together. If predrilling holes, (DVP Pipe Only) DO NOT penetrate inner pipe. WARNING! Risk of Fire or Explosion! Vent sections For 90º... - Page 48 Assemble Vent Sections (SLP Pipe Only) Note: Make sure that the seams are not aligned to prevent unintentional disconnection. WARNING! Risk of Fire or Explosion! Vent sections MUST be installed correctly. Improperly installed vent sections could leak or cause appliance to overheat. To attach the first vent component to the starting collars of the appliance: •...
-
Page 49: Assemble Slip Sections
B. Assemble Slip Sections WARNING! Risk of Fire or Explosion! DO NOT break silicone seals on slip sections. Use care when remov- • Slide the inner flue of the slip section into the inner flue ing termination cap from slip pipe. If slip section seals of the pipe section and the outer flue of the slip section are broken during removal of the termination cap, vent over the outer flue of the pipe section. -
Page 50: Secure The Vent Sections
C. Secure the Vent Sections D. Disassemble Vent Sections WARNING! Risk of Fire, Explosion or Asphyxiation! • Rotate either section (see Figure 7.10) so the seams on Improper support could allow vent to sag and separate. both pipe sections are aligned as shown in Figure 7.11. Use vent run supports and connect vent sections per in- •... -
Page 51: Vertical Termination Requirements
E. Vertical Termination Requirements Assemble and Install Storm Collar Install and Seal Metal Roof Flashing CAUTION! Risk of Cuts, Abrasions or Flying Debris. Wear protective gloves and safety glasses during instal- • See minimum vent heights for various pitched roofs lation. -
Page 52: Horizontal Termination Requirements
Install Vertical Termination Cap F. Horizontal Termination Requirements • Attach the vertical termination cap by sliding the inner Heat Shield Requirements for Horizontal collar of the cap into the inner flue of the pipe section Termination while placing the outer collar of the cap over the outer WARNING! Risk of Fire! To prevent overheating and fire, flue of the pipe section. - Page 53 Install Horizontal Termination Cap (DVP and Note: When using termination caps with factory-supplied heat shield attached, no additional wall shield firestop is SLP Pipe) required on the exterior side of a combustible wall. WARNING! Risk of Fire! The telescoping flue section of the termination cap MUST be used when connecting vent.
-
Page 54: Electrical Information
Electrical Information Junction Box Wiring A. General Information If the box is being wired from the INSIDE of the appliance: WARNING! Risk of Shock! DO NOT wire 110-120 VAC to the ignition module or to the appliance wall switch. • Remove the screw attaching the junction box/receptacle Incorrect wiring will damage controls. - Page 55 Component Tray The electrical components are installed on the component tray. If it becomes necessary to remove the components, use the information in Figure 8.2 to remove them and reinstall them correctly on the component tray. The IFT-ECM is held in position by two placement tabs (front and rear) and one plastic pin on the component tray.
-
Page 56: Wiring Requirements
PVI-WH40 PVI-WH60 FLAME PVI-WH80 MODULATION PVI-WH100 CONTROL GREEN ORANGE (MAIN) (PILOT) NOT USED FOR SL-3X-IFT, SL-5X-IFT, SL-5XLP-IFT, EMBER LIGHTING SL-7X-IFT, SL-7XLP-IFT, SL-9X-IFT MODELS BLK (GROUND) APPLIANCE 6V DC MODELS. ON/OFF BATTERY PACK CONTROL (OPTIONAL) Figure 8.3 IntelliFire Touch Wiring Diagram... -
Page 57: Gas Information
Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available gas • Refer to Section 3 for location of gas line access in types. appliance. • Conversions must be made by a qualified service •... -
Page 58: Air Shutter Setting
(P) flames may be a little shorter and much brighter than a natural gas (NG) flame. • Pull the air handle out to open the air shutter. • Tighten the wing nut. Air Shutter Settings SL-3X-IFT (NG) 1/8 in. SL-3X-IFT (PROPANE) 1/4 in. SL-5X-IFT (NG) 1/4 in. -
Page 59: Burner Identification/Verification
See Figure 9.2 for burner identification chart. Notch patterns are located on bottom side of burner. DETAIL A NG /LP SL-3X-IFT SL-5X-IFT SL-7X-IFT SL-9X-IFT Figure 9.2 Burner Identification Heat & Glo • SL-3X/5X/7X/9X-IFT (-G, -TG, -S) Installation Manual • 2633-980 Rev. B • 6/20... -
Page 60: Finishing
Finishing A. Facing Material B. Installing a Television If installing a television (TV) above the appliance, see WARNING Section 2.B. Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Comply with all minimum clearances to combustibles as specified in this manual. -
Page 61: Mantel And Wall Projections
C. Mantel and Wall Projections Combustible Mantel Legs or Wall Projections Note: Clearance from opening WARNING! Risk of Fire! Comply with all minimum to perpendicular wall. clearances as specified. Framing closer than the minimums listed must be constructed entirely of non-combustible materials (i.e., steel studs, concrete board, etc.). - Page 62 3-1/2 IN. MIN. 12 IN. MIN. Figure 10.7 Rear Vent Non-Combustible Zone Above Appliance Figure 10.8 Top Vent Non-Combustible Zone Above Appliance Heat & Glo • SL-3X/5X/7X/9X-IFT (-G, -TG, -S) Installation Manual • 2633-980 Rev. B • 6/20...
-
Page 63: Decorative Barrier Front Dimensions For Finishing
D. Decorative Barrier Front Dimensions for Overlap Fit Front - ARC,CHA,HAL, CHAF & FSI Finishing (1-6 Inch Finishing) Only decorative barrier front certified for use with this appliance model may be used. Contact your dealer for NON-COMBUSTIBLE NON-COMBUSTIBLE a list of decorative barrier fronts that may be used. Once FINISHING MATERIAL FINISHING MATERIAL 6 IN. -
Page 64: Appliance Setup
3. Gently push the back refractory toward the back of the firebox until the refractory contacts the firebox. Note: The SL-3X-IFT and SL-5X-IFT rear brick refractory will be a rectangular shape without “legs.” See Figure 11.2. Heat & Glo • SL-3X/5X/7X/9X-IFT (-G, -TG, -S) Installation Manual • 2633-980 Rev. B • 6/20... - Page 65 REAR REFRACTORY “LEGS” REAR REFRACTORY “LEGS” Figure 11.2 Install Rear Refractory Piece 4. Install left refractory panel until it contacts the back Figure 11.4 Install Top Refractory Panel wall refractory. See Fig 11.3. Figure 11.3 Install Left Refractory Panel Figure 11.5 Install Right Refractory Panel 5.
- Page 66 Install Glass Refractory Note: The lower glass bracket spans the entire width of the back wall of the firebox and rests above the side 1. Remove lower glass brackets from the top refractory lower glass brackets. See Figure 11.10, Detail A. packaging.
- Page 67 REAR UPPER GLASS BRACKET REAR UPPER GLASS BRACKET SCREW HOLES BEND THESE FEATURES Figure 11.13 Bend Upper Glass Brackets (Upper Right Bracket Shown) UPPER GLASS BRACKETS UPPER GLASS BRACKETS 5. Install the rear glass panel by placing the lower edge into the rear lower glass bracket.
- Page 68 7. Install left glass panel by inserting the glass panel from the front. Slide panel into the bottom glass bracket between the bent up tab and return bend as shown in Figure 11.7. This will create a gap between the glass and the firebox. Slide the panel back until it contacts the rear glass panel.
- Page 69 Install and Paint Teco-Sil 1. Remove Teco-Sil rock from its shipping location. 2. Install theTeco-Sil into the ember tray. 3. Fog the Teco-Sil to the desired look, using high temperature black paint (Hearth & Home Technologies part number TUP-GBK-12). See below for fogging tips.
- Page 70 LOG PLACEMENT Install Logs Log Set Assembly: LOGS-SL3X, LOGS-SL5X, INSTRUCTIONS LOGS-SL7X, LOGS-SL9X Models: SL-3X, SL-5X, SL-7X, SL-9X, SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT SL-3X/5X/7X/9X-IFT (-G, -TG, -S) Install Logs Log Placement Tips • The rear left log, rear right log and small burner CAUTION: Logs are fragile, handle with care.
- Page 71 SL-3X Models: The rear right log will be positioned Install Rear Logs to maintain about a 1 inch rear gap between the rear 1. Remove large rear left log from the packaging and install right log and the back wall refractory. The rear right the log by locating it on the back left log pin(s).
- Page 72 Install Front Logs INDENTATIONS-RIGHT LOG INDENTATIONS-RIGHT LOG 4. Remove small burner log from packaging. This log has two holes on the bottom. These holes correspond to two log pins located on the burner top. Place the small burner log on the two log pins. See Figure 6. When properly placed, this log will rest on both the burner and ember tray/Teco-Sil.
-
Page 73: Intellifire Touch ® Control System Setup
E. IntelliFire Touch Control System Setup G. Fixed Glass Assembly Removal and Re- ® placement • Detailed instructions for electrical wiring and connec- tions are provided in Section 8. WARNING! Risk of Asphyxiation! Handle fixed glass assembly with care. Inspect the gasket to ensure it is •... -
Page 74: Reference Materials
Reference Materials A. Vent Components Diagrams Effective Length Pipe Inches Millimeters 10-1/2 in. (267 mm) DVP4 45 ° Effective Height/Length DVP6 DVP12 4-7/8 in. DVP24 (124 mm) 10-7/8 in. DVP36 (276 mm) DVP Pipe (see chart) DVP48 1219 DVP45 (45º Elbow) DVP6A 3 to 6 76 to 152... - Page 75 A. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 76 A. Vent Components Diagrams (continued) 31 in. (787 mm) 13-1/4 in. (337 mm) 24-5/8 in. (625 mm) 27-1/2 in. 24-5/8 in. (699 mm) (625 mm) 13-1/4 in. (337 mm) RF12 Roof Flashing Roof Flashing 11-7/8 in. 5 in. (302 mm) (127 mm) 13-7/8 in.
- Page 77 A. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. (38 mm) 12 in. 305 mm 14 in. 17-3/4 in. (356 mm) (451 mm) 7-1/4 in. (184 mm) 12-1/2 in. 6 in. (318 mm) 152 mm 5-1/4 in. (133 mm) 12 in.
- Page 78 A. Vent Components Diagrams (continued) 8-1/8 in. 13 in. (206 mm) (330 mm) Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3° 87° 15 in. (381 mm) 10-1/2 in. 267 mm 10-7/8 in.
- Page 79 A. Vent Components Diagrams (continued) TOP VIEW Required Wire Harness and PVV-SLEEVE Lengths Available Part Number 10 ft. PV Wire Harness PVI-WH10 20 ft. PV Wire Harness PVI-WH20 40 ft. PV Wire Harness PVI-WH40 13-11/16 IN. 60 ft. PV Wire Harness PVI-WH60 80 ft.
- Page 80 Optional Wire Harness DESCRIPTION PART NUMBER 10 FT PV Wire Harness PVI-WH10 13-5/8 IN. 346 mm 20 FT PV Wire Harness PVI-WH20 EFFECTIVE LENGTH 32 IN. (813 mm) MIN. 40 FT PV Wire Harness PVI-WH40 35 IN. (889 mm) MAX. 60 FT PV Wire Harness PVI-WH60 80 FT PV Wire Harness...
- Page 81 A. Vent Components Diagrams (continued) Top View 6-1/4 IN. 159 mm 1-1/2 IN. 38 mm Front View Side View 2-1/4 IN. 15-1/2 IN. 57 mm 394 mm 4-3/4 IN. 121 mm 8 IN. 14 IN. 9-1/2 IN. 203 mm 356 mm 241 mm 5-1/4 IN.
- Page 82 A. Vent Components Diagrams (continued) 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP45 168 mm 45° Elbow 9-7/8 in.
- Page 83 A. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 84 A. Vent Components Diagrams (continued) 12 in. 305 mm 14 in. 13 in. 356 mm 330 mm 12-1/2 in. 1-5/16 in. 318 mm 10-9/16 in. 13 in. 34 mm 269 mm 330 mm SLP-CCS-BK SLP-DCF-BK SLP-TVHW Cathedral Ceiling Ceiling Firestop Vertical Support Box-Black Black...
- Page 85 8 IN. (203 mm) 15 IN. (381 mm) 12 IN. (305 mm) SLP-HHW2 Horizontal High Wind Termination Cap Figure 12.12 SLP series Vent Components COAXIAL to COLINEAR VENTING LINK-DV30B 768-380A DV-46DVA-GCL Flex Liner Kit Required Stainless Steel Flex Pipe Coaxial/Colinear Appliance Connector DVP-2SL Adapter Figure 12.13 Coaxial to Colinear Vent Components...
-
Page 86: Accessories
Optional Heat Management Systems Kits B. Accessories Install approved accessories per instructions included After a qualified service technician has installed the heat management system, follow the instructions supplied with with accessories. Contact your dealer for a list of ap- proved accessories. the kit for operation.
