FOUNDATION SERIES - SINGLE SIDED
Co-linear Direct Vent Gas Fireplaces
Installation and Operating Manual
Natural Gas
FDN-4-SS
FDN-5-SS
FDN-6-SS
FDN-7-SS
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
—
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Please contact your Heat & Glo dealer with any questions or concerns.
Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19
Heat & Glo, a brand of Hearth & Home Technologies
7571 215
Street West, Lakeville, MN 55044
th
www.heatnglo.com
For the location of your nearest Heat & Glo dealer,
please visit www.heatnglo.com.
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heat&Glo FOUNDATION Series
Summary of Contents for Heat&Glo FOUNDATION Series
-
Page 1: What To Do If You Smell Gas
FOUNDATION SERIES - SINGLE SIDED Co-linear Direct Vent Gas Fireplaces Installation and Operating Manual Natural Gas FDN-4-SS FDN-5-SS FDN-6-SS FDN-7-SS Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference. WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information Electrical 29-35 A. Safety Icon Designations A. Field Wiring (At Install) B. Important Safety Considerations B. Field Wiring (Service and Troubleshooting) C. Requirements for the Commonwealth of C.1 Terminals 1 & 2 - LED Lights Massachusetts C.2 Terminals 3 &... -
Page 3: Safety Information
1 - SAFETY INFORMATION This fireplace complies with ANSI Z21.50-2016·CSA 2.22-2016 “VENTED DECORATIVE GAS APPLIANCES”. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSA B149.1 A. SAFETY ICON DESIGNATIONS Various safety icons appear throughout this installation manual. Please familiarize yourself with the icons making sure you understand the serious consequences that may occur if ignored or of handling the products inappropriately. IMPORTANT NOTE HOT GLASS WARNING This indicates additional instructions that you should consider... -
Page 4: Requirements For The Commonwealth Of
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed C. Requirements for the Commonwealth of in accordance with the provisions of 248 CMR 5.08(2)(a)1... -
Page 5: Fireplace Specifications
2 - FIREPLACE SPECIFICATIONS A. SINGLE SIDED DIMENSIONS Figure 2A FLUE B-VENT [305] 2X 1/2 2X 1 25/32 [13] [45] [76] [76] [381] 6 1/8 [156] INTAKE 6 1/8 ACCESS PANEL [305] COLLAR [156] 2 X 5/8 FRONT AND REAR 6 5/8 [16] INTAKE [168] [305] COLLAR... -
Page 6: Clearances
2 - FIREPLACE SPECIFICATIONS SPECIFICATIONS TABLE PROPANE Model # B-VENT REG PV IN-LINE PV BTU’S ORIFICE ORIFICE FDN-4-SS 4X2 SINGLE SIDED 8” 10” PVK-45 PVI-45 60,000 (3X) #43 (3X) #55 FDN-5-SS 5X2 SINGLE SIDED 8” 10” PVK-45 PVI-45 80,000 (4X) #43 (4X) #55 FDN-6-SS 6X2 SINGLE SIDED 10”... -
Page 7: Installation Overview
2 - FIREPLACE SPECIFICATIONS NOTE: The qualified installer should follow the procedure best suited for the installation. C. INSTALLATION OVERVIEW Framing should be built after the fireplace is installed or extra clearance must be planned for at the intake collar. Framing must allow for vent installation. If masonry (optional) will be used, prepare foundation for the masonry load. A lintel is required to support the added weight above the fireplace. Install hearth if desired. -
Page 8: Prepare The Fireplace
3 - PREPARE THE FIREPLACE CAUTION: FIREPLACE IS NOT LOAD-BEARING. NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED. A. STANDOFF INSTALLATION LOOSEN SCREW AND FOLD STAND- REMOVE SECOND SCREW LOOSENED SCREW PIVOT FOLDED STANDOFF Figure 3A.1 AND SECURE Figure 3A.2 STEP 1: Refer to Figure 3A.1 STEP 2: Refer to Figure 3A.2 The two (2) standoffs will be shipped in a flat state placed on the firebox Fold the center of the standoff up and both ends out at the perforated top. -
Page 9: Nailing Tab Installation
3 - PREPARE THE FIREPLACE B. NAILING TAB INSTALLATION Figure 3B.1 Figure 3B.2 Figure 3B.3 STEP 1: Refer to Figure 3B.1 STEP 2: Refer to Figure 3B.2 STEP 3: Refer to Figure 3B.3 & Figure 3B.4 The four (4) nailing flanges will be shipped in Bend the two (2) small tabs out on each Set each nailing flange in place and secure a flat state placed on the firebox sides. nailing flange at the perforated lines. -
Page 10: Framing
4 - FRAMING NOTE: Framing dimensions should allow for wall covering thickness and fireplace facing materials. When using a hearth, adjust rough opening size as necessary to maintain at least minimum clearance requirements. CAUTION: Install fireplace on metal, concrete or hard wood surface extending the full width and depth of fireplace. CAUTION: Vent cap location must be in compliance with guidelines in Section 8 of this manual. CAUTION: FIREPLACE IS NOT LOAD-BEARING. If masonry is to be used (optional), prepare the necessary foundation for the masonry load. When masonry construction is being used, a lintel must be used over top of fireplace to support the added weight. -
Page 11: Single Sided
4 - FRAMING SINGLE SIDED Figure 4 IMPORTANT: FIREPLACE IS NOT LOAD-BEARING. COMBUSTIBLE OR NON-COMBUSTIBLE BACKING MATERIAL (I.E. SHEETROCK) MINIMUM NON-COMBUSTIBLE ZONE OPEN AIR SPACE 6” [25] 1/2” Standoffs SINGLE SIDED IMPORTANT FRAMING NOTES: FRAMING SHOULD BE BUILT AFTER THE FIREPLACE IS INSTALLED OR EXTRA CLEARANCE MUST Model # BE PLANNED FOR AT THE INTAKE COLLAR AND FOR THICKNESS OF MATERIALS USED. -
Page 12: Mantel Requirements
5 - MANTEL REQUIREMENTS A. NON-COMBUSTIBLE ZONE - USING THE PROVIDED 1/2" STANDOFFS The fi replace has standoffs installed on the front of the fi replace standard from the factory. They are located on the upper left, center and right front of the fi replace and are to ensure that the 1/2" [12.7mm] required clearance to combustibles on the surface of the fi replace is maintained. -
Page 13: Non-Combustible Zone - Not Using The Provided
5 - MANTEL REQUIREMENTS B. NON-COMBUSTIBLE ZONE - NOT USING THE PROVIDED 1/2" STANDOFFS The fi replace has standoffs installed on the front of the fi replace standard from the factory. They are located on the left, center and right front hood of the fi replace and are to ensure that the 1/2" [12.7mm] required clearance to combustibles on the surface of the fi replace is maintained. -
Page 14: Glass Frame Assembly
6 - GLASS FRAME ASSEMBLY A. GLASS FRAME ASSEMBLY IDENTIFICATION GLASS UPPER GROOVE QUALITY SUCTION CUP LOWER FILLER STRIP SITS OVER GLASS CLIPS LOWER GROOVE GLASS CLIP Figure 6A Figure 6B.1 CAUTION: To prevent glass frame assembly from falling from fireplace and becoming damaged, follow the instructions exactly when removing and installing glass frame assembly. STOP: DO NOT operate this fireplace with the glass removed, cracked or broken. Replacement of glass assembly should be done by a licensed or qualified service person. WARNING! RISK OF INJURY! DO NOT remove glass until it is cooled to room temperature. Glass breakage could occur. NOTE: Glass removal and installation must be performed with two people. NOTE: GLASS MUST BE REMOVED USING QUALITY SUCTION CUPS. DO NOT attempt to remove the glass without using proper suction cups. -
Page 15: Install Glass Frame Assembly
6 - GLASS FRAME ASSEMBLY Refer to Glass Frame Assembly Identification Figures 6A & 6B.1 when installing and removing the glass frame assembly. B. INSTALL GLASS FRAME ASSEMBLY IMPORTANT: PLASTIC GLASS EDGE PROTECTORS The fireplace is shipped with a plastic edge protector on the outer pane of glass only. If the edge protector is not installed, the glass may rattle during operation. -
Page 16: Gas Line Specifications & Access
7 - GAS LINE SPECIFICATIONS & ACCESS This fireplace is manufactured for use with Natural Gas or Propane. CAUTION: Installation of the gas line must only be done by a qualified person in accordance with local building codes, if any. If not, follow ANSI Z223.1. NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½ psi. NOTE: The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas line at test pressures equal to or less than ½ psi (3.5 kPa). NOTE: For high altitude installations above 2000 feet, fireplace does not need to be derated. A. GAS LINE CONNECTION GAS LINE CONNECTION Propane Natural 11.0 inches W.C. 7.0 inches W.C. MINIMUM INLET GAS PRESSURE (recommended) (recommended) MAXIMUM INLET GAS PRESSURE 14.0 inches W.C. 10.0 inches W.C. MANIFOLD PRESSURE (HI) 10.0 inches W.C. -
Page 17: Gas And Electrical Access Panels
7 - GAS LINE SPECIFICATIONS & ACCESS B. GAS AND ELECTRICAL ACCESS PANELS Each fireplace will have four points of access for installation and service. There are access panels on the pilot side of the fireplace front, side and rear of the fireplace. Plan in advance of the installation which access location will be used and accommodate for it in the finish work to allow for easy access to service later. -
Page 18: Venting
8 - VENTING CAUTION: Consult the local and national installation codes to assure adequate combustion and ventilation air is available. NOTE: Flame height and appearance will vary depending upon venting configuration and type of fuel used. Venting requirements apply to both Natural and Propane gas. STOP: MAINTAIN ALL CLEARANCES AS STATED IN THIS INSTALLATION MANUAL. A. APPROVED VENTING IN-LINE Model # B-VENT OUTSIDE AIR POWER VENT AMP* POWER VENT FDN-4-SS 4X2 SINGLE SIDED 8" 10" PVK-45 PVI-45 FDN-5-SS 5X2 SINGLE SIDED 8”... - Page 19 Available Power Venting A power vent (PVK-45 or PVK-67) is approved for use with this appliance. It is crucial that all B-Vent pipe and elbow joints, and the longitudinal seam are sealed using a high temperature RTV Silicone and/or foil tape. NOTE: All pipe and elbow joints must be sealed. This includes the longitudinal seam on the pipe. High Temp RTV Silicone and/or foil tape MUST be used on each joint/seam.
- Page 20 Available In-Line Power Venting An in-line power vent (PVI-45 or PVI-67) is approved for use with this appliance. It is crucial that all B-Vent pipe and elbow joints, and the longitudinal seam are sealed using a high temperature RTV Silicone and/or foil tape. NOTE: All pipe and elbow joints must be sealed. This includes the longitudinal seam on the pipe.
- Page 21 IN-LINE POWERVENT PREPARATION - PVI-67 Perform the following steps when installing the PVI-67 on six foot and seven foot models. 1. Attach the provided 10 inch B-Vent collar to the intake side of the powervent. The intake side is located opposite the fan motor as shown in Figure 8A.6.
-
Page 22: Pitot Tube Information
B. PITOT TUBE INFORMATION Figure 8B There is a 1/4" pitot tube mounted in the center of the flue collar and is connected to the pressure switch (Figure 8B). This monitors the pressure in the flue and is necessary for proper operation. Take care to keep the end of the tube clean. -
Page 23: Vertical Terminations
8 - VENTING E. VERTICAL TERMINATIONS • The Foundation Series fireplace must terminate with the approved powervent termination cap. • NO SUBSTITUTION IS ACCEPTABLE. • Carefully follow the instructions included with the approved powervent termination cap. • DO NOT use an additional speed control on this powervent. • You must use the included Capacitor. F. HORIZONTAL TERMINATION VENT CAP LOCATION & CLEARANCES This gas appliance must not be connected to a chimney serving any other appliance. • DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed. -
Page 24: Horizontal Termination Vent Cap Location & Clearances
8 - VENTING F. HORIZONTAL TERMINATION VENT CAP LOCATION & CLEARANCES Inside Corner Outside Corner Recessed Location G = Combustible 24” (609.6mm) F = Combustible 12” (305 mm) = Non-combustible 12” (304.8mm) = Non-combustible 12” (305 mm) Balcony Balcony with perpendicular side wall with no side wall Q = Clearance from corner in recessed location = Combustible 24”... -
Page 25: Vertical Vent Cap Location & Clearances
8 - VENTING G. VERTICAL VENT CAP LOCATION AND CLEARANCES ROOF PITCH H (Min.) Ft. H (Min.) M FLAT TO 6/12 1.0* 0.30 OVER 6/12 TO 7/12 1.25* 0.38 OVER 7/12 TO 8/12 1.5* 0.46 OVER 8/12 TO 9/12 2.0* 0.61 OVER 9/12 TO 10/12 2.5* 0.76 OVER 10/12 TO 11/12 3.25 0.99 OVER 11/12 TO 12/12 1.22 OVER 12/12 TO 14/12 1.52 OVER 14/12 TO 16/12 1.83 OVER 16/12 TO 18/12... -
Page 26: Roof Termination Cap Installation-With And Without Damper
8 - VENTING H. ROOF TERMINATION CAP INSTALLATION - WITH AND WITHOUT OPTIONAL DAMPER Roof Termination Without Optional Mechanical Damper POWERVENT MOUNTING BRACKETS OR DRILL MOUNTING HOLES TO MATCH BASE INSULATION PAD MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE. PLACE FOIL SIDE UP. -
Page 27: Wall Termination-With And Without Damper
8 - VENTING I. WALL TERMINATION - WITH AND WITHOUT OPTIONAL DAMPER Wall Termination Without Optional Mechanical Damper FRAMING: 8" = 11-3/4" W X 11-3/4" H 10" = 13-1/4" W X 13-1/4" H DRILL 1/4” HOLES TO MATCH POWER VENT BASE INSULATION PAD MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE. PLACE FOIL SIDE OUT. -
Page 28: Intake Air
J. INTAKE AIR This fireplace has the options of air intake connections on the side or the bottom of the fireplace. This fireplace is approved for use with 10 inch rigid metal pipe or UL approved 10 inch Class 0 or Class 1 flex for intake air. Use Table 8J.1 for venting requirements if using UL approved 10 inch flex for intake air. - Page 29 9- ELECTRICAL A. FIELD WIRING (AT INSTALL) See Terminal Details in Section 9B and 9C. Figure 9A *Cap shown is from the PVK Series VAC AMP HP REPLACEMENT CAPACITOR PVK-45 1.2 1/9 601.0400.0064 PVK-67 1.4 1/7 604.0400.0064 PVI-45 604.0600.0064 PVI-67 5.3 13/16 604.0800.0064 JUNCTION BOX WITH CAPACITOR TO FAN Insulation Pad (Must be cut in center to accomodate GREEN vent size.
-
Page 30: Electrical
9 - ELECTRICAL B. FIELD WIRING (SERVICE & TROUBLESHOOTING) Figure 9B Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19... -
Page 31: Terminals 1 & 2 - Led Lights
9 - ELECTRICAL C.1 TERMINALS 1 & 2 - LED Lights Figure 9C.1 Terminals 1 & 2 C.2 TERMINALS 3 & 4 - Main Flame Figure 9C.2 Terminals 3 & 4 Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19... -
Page 32: Terminals 5 & 6 - Fireplace Power
9 - ELECTRICAL C.3 TERMINALS 5 & 6 - Fireplace Power Figure 9C.3 Terminals 5 & 6 C.4 TERMINALS 7 & 8 - Powervent Connection 120VAC POWERVENT / IN-LINE POWERVENT NEUTRAL POWERVENT / IN-LINE POWERVENT Figure 9C.4 Terminals 7 & 8 Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19... -
Page 33: Terminals 9 & 10 - Flue Damper Connection
9 - ELECTRICAL C.5 TERMINALS 9 & 10 - Flue Damper Connection NOTE: OPTIONAL IF A DAMPER IS NOT USED DO NOT CONNECT ANYTHING TO TERMINALS 9 & 10 Figure 9C.5 Terminals 9 & 10 Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19... -
Page 34: Terminals 11 & 12 - Flue Damper Prove
9 - ELECTRICAL C.6 TERMINALS 11 & 12 - Flue Damper Prove SEE NOTE NOTE: OPTIONAL IF A DAMPER IS NOT USED TERMINALS 11 AND 12 HAVE A JUMPER ACROSS THEM Figure 9C.6 Terminals 11 & 12 Heat & Glo • FDN-4-SS, FDN-5-SS, FDN-6-SS, FDN-7-SS Installation Manual • 16400-9800 Rev. H • 11/19... -
Page 35: Terminals 13 & 14 - Vacuum Switch
9 - ELECTRICAL C.7 TERMINALS 13 & 14 - Vacuum Switch FLUE VACUUM SWITCH MOUNTED INTO FLUE STREAM TERMINALS 13 AND 14 VACUUM SWITCH FACTORY WIRED TERMINAL #13 CONNECTS TO THE “COM” OR “NO” TERMINALS IN THE VACUUM SWITCH FOR FIREPLACE 1. TERMINAL #14 CONNECTS TO THE “COM” OR “NO” TERMINALS IN THE VACUUM SWITCH FOR FIREPLACE 1. -
Page 36: Finishing The Wall - Using The Provided 1/2" Standoffs
10 - FINISHING A. FINISHING THE WALL - USING THE PROVIDED 1/2" STANDOFFS NOTE: REFER TO DIMENSIONS SECTION FOR ALLOWABLE FINISHING DIMENSIONS REQUIRED TO FIT THE GLASS PANELS INTO THE FIREPLACE. FINISHING MATERIALS MUST NOT OVERLAP THE FRAMING DIMENSIONS REFERENCED IN SECTION 2.A. NEVER COVER THE GLASS WITH FINISHING MATERIALS. NOTE: DO NOT PIERCE ANY OF THE BLACK PAINTED SURFACES WITH SCREWS, RIVETS, ETC. THIS INCLUDES THE 3" BLACK TOP AND BOTTOM GLASS TRIM AND ANY PAINTED SIDES ADJACENT TO THE GLASS. NOTE: REFER TO MANTEL REQUIREMENTS: NON-COMBUSTIBLE ZONE USING PROVIDED 1/2" STANDOFFS FOR MORE INFORMATION (SECTION 5A). WARNING! Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Figure 10A.1 Comply with all minimum clearances to combustibles as specifi... -
Page 37: Finishing The Wall -Not Using The Provided 1/2" Standoffs
10 - FINISHING B. FINISHING THE WALL - NOT USING THE PROVIDED 1/2" STANDOFFS NOTE: REFER TO DIMENSIONS SECTION FOR ALLOWABLE FINISHING DIMENSIONS REQUIRED TO FIT THE GLASS PANELS INTO THE FIREPLACE. FINISHING MATERIALS MUST NOT OVERLAP THE FRAMING DIMENSIONS REFERENCED IN SECTION 2.A. NEVER COVER THE GLASS WITH FINISHING MATERIALS. NOTE: DO NOT PIERCE ANY OF THE BLACK PAINTED SURFACES WITH SCREWS, RIVETS, ETC. THIS INCLUDES THE 3" BLACK TOP AND BOTTOM GLASS TRIM AND ANY PAINTED SIDES ADJACENT TO THE GLASS. NOTE: REFER TO MANTEL REQUIREMENTS: NON-COMBUSTIBLE ZONE NOT USING PROVIDED 1/2" STANDOFFS FOR MORE INFORMATION (SECTION 5B). -
Page 38: Lighting & Shutdown
11 - LIGHTING & SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING STOP: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. UE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air. It is important to make sure the termination cap remains unobstructed at all times from snow, ice, leaves or other debris. •... -
Page 39: If The Fireplace Does Not Light
11 - LIGHTING & SHUTDOWN STOP! Read safety information on previous page and front cover of this manual before continuing. NOTE: This fi replace is equipped with an ignition device which automatically lights the pilot. DO NOT try to light the pilot by hand. B. IF THE FIREPLACE DOES NOT LIGHT Turn off the fi replace at switch. Turn off all electrical power to fi replace. Wait fi ve (5) minutes to allow any gas that may have accumulated inside fi rebox to escape. -
Page 40: Pressure Testing
12 - PRESSURE TESTING NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½ psi. NOTE: The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas line at test pressures equal to or less than ½ psi (3.5 kPa). INLET PRESSURE TEST The valve has an allen-plug on the inlet and outlet. Install a barb fitting on the tap you want to measure. Light the fireplace, check the pressure. Turn off fireplace; reinstall plug. Check for leaks. -
Page 41: Maintenance
14 - MAINTENANCE The appliance is required to be inspected at least once a year by a professional service person. The compartment below firebox (behind lower access panel) must be cleaned at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. It is imperative that the burner be cleaned once a year. VALVE AND ELECTRICAL ACCESS There is an access panel in the floor of the firebox should more extensive service be needed. Using the suction cups, remove the inner and outer glass panels. Remove the glass media or natural stones on the end with the pilot. Remove the screws on the mesh screen and remove the mesh screen. Remove the Phillips head screws on the LED “U” shaped metal tray and gently fold metal tray over the burners. Remove the 6 screws on the solid access panel and remove panel. NOTE: INSTALLATION AND REPAIR SHOULD BE DONE ONLY BY QUALIFIED SERVICE PERSON. -
Page 42: Replacement Parts List
C. REPLACEMENT PARTS LIST PART PART NUMBER PART PART NUMBER Replacement Capacitor - PVK-45 601.0400.0064 Gas Valve SV9501 Pilot 112-5000 Replacement Capacitor - PVK-67 604.0400.0064 Vacuum Switch 112-5003 Replacement Capacitor - PVI-45 604.0600.0064 Transformer, 24 VAC 112-5002 Replacement Capacitor - PVI-67 604.0800.0064 Orifice, NG #43 16400-2043... -
Page 43: Limited Lifetime Warranty
Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture. - Page 44 WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
