Warnings and Alarms
No. Description
75 Illegal Profile Sel.
76 Power Unit Setup
77 Reduced Power Mode
78 Tracking Error
79 Illegal PS config
80 Drive Initialized to Default Value
81 CSIV corrupt
82 CSIV parameter error
83 Illegal Option Combination
84 No Safety Option
88 Option Detection
89 Mechanical Brake Sliding
90 Feedback Monitor
91 Analog input 54 wrong settings
104 Mixing Fan Fault
163 ATEX ETR cur.lim.warning
164 ATEX ETR cur.lim.alarm
165 ATEX ETR freq.lim.warning
8 8
166 ATEX ETR freq.lim.alarm
243 Brake IGBT
244 Heatsink temp.
245 Heatsink sensor
246 Pwr.card supply
249 Rect. low temp.
250 New spare parts
251 New Type Code
Table 8.2 Alarm/Warning Code List
(X) Dependent on parameter
1)
Cannot be Auto reset via 14-20 Reset Mode

8.5 Fault Messages

The warning/alarm information below defines each
warning/alarm condition, provides the probable cause for
the condition, and details a remedy or troubleshooting
procedure.
WARNING 1, 10 Volts low
The control card voltage is below 10 V from terminal 50.
Remove some of the load from terminal 50, as the 10 V
supply is overloaded. Max. 15 mA or minimum 590 Ω.
This condition can be caused by a short in a connected
potentiometer or improper wiring of the potentiometer.
Troubleshooting
Remove the wiring from terminal 50. If the warning clears,
the problem is with the customer wiring. If the warning
does not clear, replace the control card.
8-4
®
VLT Automation Drive D-Frame
Instruction Manual
Warning Alarm/Trip
X
X
X
(X) (X)
X
X
X
X
X
X
(X) (X)
X X
X
X
X
X
X X
X X
X
X
X
WARNING/ALARM 2, Live zero error
This warning or alarm only appears if programmed by the
user in 6-01 Live Zero Timeout Function. The signal on one
of the analog inputs is less than 50% of the minimum
value programmed for that input. Broken wiring or faulty
device sending the signal can cause this condition.
Troubleshooting
®
MG34U222 - VLT is a registered Danfoss trademark
Alarm/Trip Lock Parameter Reference
14-59 Actual Number of
Inverter Units
4-34 Tracking Error Function
X
X
X
17-61 Feedback Signal
X
X
X
X Parameter group 0-7*
X
X
X
Check connections on all the analog input
terminals. Control card terminals 53 and 54 for
signals, terminal 55 common. MCB 101 terminals
11 and 12 for signals, terminal 10 common. MCB
Monitoring
S202
14-53
