Warnings and Alarms
ALARM 31, Motor phase V missing
Motor phase V between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase W.
ALARM 33, Inrush fault
Too many power-ups have occurred within a short time
period. Let the unit cool to operating temperature.
WARNING/ALARM 34, Fieldbus communication fault
The serial communication bus on the communication
option card is not working.
WARNING/ALARM 36, Mains Failure
This warning/alarm is only active if the supply voltage to
the adjustable frequency drive is lost and 14-10 Mains
Failure is NOT set to [0] No Function. Check the fuses to the
8 8
adjustable frequency drive and line power supply to the
unit.
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
the table below is displayed.
Troubleshooting
Cycle power
Check that the option is properly installed
Check for loose or missing wiring
It may be necessary to contact your Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
No. Text
0 Serial port cannot be initialized. Contact your
Danfoss supplier or Danfoss Service Department.
256-258 Power EEPROM data is defective or too old
512 Control board EEPROM data is defective or too
old.
513 Communication time out reading EEPROM data
514 Communication time out reading EEPROM data
515 Application oriented control cannot recognize the
EEPROM data.
516 Cannot write to the EEPROM because a write
command is on progress.
517 Write command is under timeout
518 Failure in the EEPROM
519 Missing or invalid barcode data in EEPROM
783 Parameter value outside of min/max limits
8-8
®
VLT Automation Drive D-Frame
Instruction Manual
No.
1024-1279
1281
1282
1283
1284
1299
1300
1301
1302
1315
1316
1317
1318
1379
1380
1381
1382
1536
1792
2049
2064-2072
2080-2088
2096-2104
2304
2305
2314
2315
2316
2324
2325
2326
2327
2330
®
MG34U222 - VLT is a registered Danfoss trademark
Text
A CAN message that has to be sent couldn't be
sent.
Digital signal processor flash timeout
Power micro software version mismatch
Power EEPROM data version mismatch
Cannot read digital signal processor software
version
Option SW in slot A is too old
Option SW in slot B is too old
Option SW in slot C0 is too old
Option SW in slot C1 is too old
Option SW in slot A is not supported (not allowed)
Option SW in slot B is not supported (not allowed)
Option SW in slot C0 is not supported (not
allowed)
Option SW in slot C1 is not supported (not
allowed)
Option A did not respond when calculating
platform version
Option B did not respond when calculating
platform version
Option C0 did not respond when calculating
platform version.
Option C1 did not respond when calculating
platform version.
An exception in the application oriented control is
registered. Debug information written in LCP
DSP watchdog is active. Debugging of power part
data, motor oriented control data not transferred
correctly.
Power data restarted
H081x: option in slot x has restarted
H082x: option in slot x has issued a power-up wait
H983x: option in slot x has issued a legal power-
up wait
Could not read any data from power EEPROM
Missing SW version from power unit
Missing power unit data from power unit
Missing SW version from power unit
Missing lo_statepage from power unit
Power card configuration is determined to be
incorrect at power-up
A power card has stopped communicating while
line power is applied
Power card configuration is determined to be
incorrect after the delay for power cards to
register.
Too many power card locations have been
registered as present.
Power size information between the power cards
does not match.
