Programming

5 Programming

5.1 Introduction

The adjustable frequency drive is programmed for its
application functions using parameters. Parameters are
accessed by pressing either [Quick Menu] or [Main Menu]
on the LCP. (See 4.1 Local Control Panel for details on using
the LCP function keys). Parameters may also be accessed
through a PC using the MCT 10 Set-up Software (see
5.6.1 Remote Programming with MCT 10 Set-up Software).
The quick menu is intended for initial startup (Q2-** Quick
Set-up) and detailed instructions for common adjustable
frequency drive applications (Q3-** Function Set-up). Step-
by-step instructions are provided. These instructions enable
the user to walk through the parameters used for
programming applications in their proper sequence. Data
entered in a parameter can change the options available in
the parameters following that entry. The quick menu
presents easy guidelines for getting most systems up and
running.
The main menu accesses all parameters and allows for
advanced adjustable frequency drive applications.

5.2 Programming Example

Here is an example for programming the adjustable
frequency drive for a common application in open-loop
using the quick menu.
•
This procedure programs the adjustable
frequency drive to receive a 0–10 V DC analog
control signal on input terminal 53
•
The adjustable frequency drive will respond by
providing 20–50 Hz output to the motor propor-
tional to the input signal (0–10 V DC=20–50 Hz)
This is a common pump or fan application.
Press [Quick Menu] and select the following parameters
using the navigation keys to scroll to the titles and press
[OK] after each action.
®
VLT Automation Drive D-Frame
Instruction Manual
Figure 5.1
Figure 5.2
Figure 5.3
®
MG34U222 - VLT is a registered Danfoss trademark
1. Q3 Function Set-ups
2. Parameter Data Set
69.3%
Quick Menus
Q1 My Personal Menu
Q2 Quick Set-up
Q3 Function Set-ups
Q5 Changes Made
3. Q3-2 Open-loop Settings
28.4%
Function Setups
Q3-1 General Settings
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
4. Q3-21 Analog Reference
14.7%
Open Loop Settings
Q3-20 Digital Reference
Q3-21 Analog Reference
5.20A 1(1)
5
2.05A 1(1)
Q3
0.00A 1(1)
Q3-2
