Startup and Commissioning
3. Press the navigation keys to scroll to parameter
group 0-0* Basic Settings and press [OK].
0.0%
Operation / Display
0-0 Basic Settings
*
0-1 * Set-up Opperations
0-2 LCP Display
*
0-3 LCP Custom Readout
*
Figure 3.2
4. Press the navigation keys to scroll to
0-03 Regional Settings and press [OK].
0.0%
Basic Settings
0-03 Regional Settings
[0] International
Figure 3.3
5. Press the navigation keys to select International
or North America as appropriate and press [OK].
(This changes the default settings for a number
of basic parameters. See 5.5 Parameter Menu
Structure for a complete list.)
6. Press [Quick Menu] on the LCP.
7. Press the navigation keys to scroll to parameter
group Q2 Quick Set-up and press [OK].
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q5 Changes Made
Q6 Loggings
Figure 3.4
8. Select language and press [OK]. Then enter the
motor data in 1-20 Motor Power [kW] /1-21 Motor
Power [HP] to 1-25 Motor Nominal Speed. The
information can be found on the motor
nameplate.
®
VLT Automation Drive D-Frame
Instruction Manual
0.00A 1(1)
0-
**
0.00A 1(1)
0-0
*
13.0A 1(1)
®
MG34U222 - VLT is a registered Danfoss trademark
•
1-20 Motor Power [kW] or 1-21 Motor
Power [HP]
•
1-22 Motor Voltage
•
1-23 Motor Frequency
•
1-24 Motor Current
•
1-25 Motor Nominal Speed
0.0 Hz
Motor Setup
1 - 21 Motor Power [kW]
4.0 kW
Figure 3.5
9. A jumper wire should be in place between
control terminals 12 and 27. If this is the case,
leave 5-12 Terminal 27 Digital Input at factory
default. Otherwise select No Operation. For
adjustable frequency drives with an optional
bypass, no jumper wire is required.
10. 3-02 Minimum Reference
11. 3-03 Maximum Reference
12. 3-41 Ramp 1 Ramp Up Time
13. 3-42 Ramp 1 Ramp Down Time
14. 3-13 Reference Site. Linked to Hand/Auto* Local
Remote.
This concludes the quick set-up procedure. Press [Status]
to return to the operational display.
