infobit iMatrix H44VAW User Manual page 8

Level 1
MODE
RESO
VW
H BEZEL
V BEZEL
EDID
INPUT
AUDIOSEL
OUT
MODE
EXTAUDIO
MATRIX
LCD ONTIME
BAUD RATE
IP INFO
SET
BG PATTERN
REBOOT
RESET
Level 2
2×2 / 2×1 / 2×2-2 / 1×2 / 1×2-2 / 3×1 /
4×1 / 1×3 / 1×4
4K2K60W / 4K2K50W / 4K2K60 / 4K2K50 /
4K2K30 / 1080P60 / 1080P50 / 1080i60 /
1080i50 / WUXGA60_RB / 1360x768@60 /
1280x800@60 / 720P60 / 720P50 / XGA60
0-10
0-10
IN1 / IN2 / IN3 / IN4
IN1 / IN2 / IN3 / IN4
OUT1 / OUT2 / OUT3 / OUT4
BIND TO INPUT /
BIND TO OUTPUT /
AUDIO MATRIX
OUT1 / OUT2 / OUT3 / OUT4
OFF / ALWAYS ON / 15 SECONDS /
30 SECONDS / 60 SECONDS
4800 / 9600 / 19200 / 38400 /
57600 / 115200
DHCP:ON / OFF
BLACK SCREEN / BLUE SCREEN /
COLOR BAR / GRAY SCALE / CROSS /
CROSS HATCH
Y / N
Y / N
Level 3
6 / 38
Level 4
4K60, 2.0CH
4K60, 5.1CH
4K60, 7.1CH
4K30, 2.0CH
4K30, 5.1CH
4K30, 7.1CH
1080P, 2.0CH
1080P, 5.1CH
1080P, 7.1CH
WUXGA, 2.0CH
768P, 2.0CH
XGA, 2.0CH
USER1
USER2
COPY OUT1
COPY OUT2
COPY OUT3
COPY OUT4
ORIGINAL
EMBED
ENABLE
DISABLE
INPUT1
INPUT2
INPUT3
INPUT4
