infobit iMatrix H44VAW User Manual page 30

Command
Function Description
Code
Output Setting
Get output y hdcp status
(y=0~4)
y=0. output all
r output y
y=1. output 1
hdcp!
y=2. output 2
y=3. output 3
y=4. output 4
Get output y h mirror
(y=0~4, x=0,1)
y=0. output all
y=1. output 1
s output y
y=2. output 2
hmirror x!
y=3. output 3
y=4. output 4
x=0. h mirror off
x=1. h mirror on
Set output y v mirror
(y=0~4, x=0,1)
y=0. output all
y=1. output 1
s output y
y=2. output 2
vmirror x!
y=3. output 3
y=4. output 4
x=0. v mirror off
x=1. v mirror on
Get output y mirror status
(y=0~4)
y=0. output all
r output y
y=1. output 1
mirror!
y=2. output 2
y=3. output 3
y=4. output 4
Set output y stream
enable/disable (y=0~4,
x=0~1)
y=0. output all
s output y y=1. output 1
stream x! y=2. output 2
y=3. output 3
y=4. output 4
x=0. stream disable
x=1. stream enable
get output y stream status
(y=0~4)
y=0. output all
r output y
y=1. output 1
stream!
y=2. output 2
y=3. output 3
y=4. output 4
Example Feedback
r output 1 output 1 hdcp: hdcp
hdcp! 1.4
s output 1
output1 h mirror on
hmirror 1!
s output 1
output1 v mirror off
vmirror 0!
output 1 h mirror on,
v mirror off
output 2 h mirror on,
v mirror off
r output 0
mirror! output 3 h mirror on,
v mirror off
output 4 h mirror on,
v mirror off
s output 1 output 1 stream:
stream 1! enable
r output 1 output 1 stream:
stream! enable
28 / 38
Default Setting
output 1 h mirror off
output 2 h mirror off
output 3 h mirror off
output 4 h mirror off
output 1 v mirror off
output 2 v mirror off
output 3 v mirror off
output 4 v mirror off
enable
