infobit iMatrix H44VAW User Manual page 31

Command Code
Output Setting
Set output no signal
background display mode
(x=1~6)
x=1. black screen
s output bg x! x=2. blue screen
x=3. color bar
x=4. gray scale
x=5. cross
x=6. cross hatch
Get output no signal
r output bg!
background display mode
EDID Setting
Set hdmi input x edid mode
(x=0~4,z=1~18)
x=0. all input
x=1. input1
x=2. input2
x=3. input3
x=4. input4
z=1. 4k60,2.0ch
z=2. 4k60,5.1ch
z=3. 4k60,7.1ch
z=4. 4k30,2.0ch
z=5. 4k30,5.1ch
s input x edid z! z=6. 4k30,7.1ch
z=7. 1080p,2.0ch
z=8. 1080p,5.1ch
z=9. 1080p,7.1ch
z=10. wuxga,2.0ch
z=11. 768p, 2.0ch
z=12. xga,2.0ch
z=13. user1
z=14. user2
z=15. copy out1
z=16. copy out2
z=17. copy out3
z=18. copy out4
Get input x edid mode
(x=0~4)
x=0. all input
r input x edid! x=1. input1
x=2. input2
x=3. input3
x=4. input4
Function Description Example Feedback
s output bg output background:
1! black screen
output background:
r output bg!
black screen
s input 1 input 1
edid 1! edid:4k60,2.0ch
r input 1 input 1
edid! edid:4k60,2.0ch
29 / 38
Default Setting
black screen
4k60,2.0ch
