Command Code
Video Matrix Setting
Route input source to output
y (y=0~4, x=1~4)
y=0. output all
y=1. output 1
y=2. output 2
s output y in
y=3. output 3
source x!
y=4. output 4
x=1. input 1
x=2. input 2
x=3. input 3
x=4. input 4
Get output y selected input
source (y=0~4)
y=0. output all
r output y in
y=1. output 1
source!
y=2. output 2
y=3. output 3
y=4. output 4
Video Wall Setting
Set tv wall display mode
(x=1~9)
x=1. 2x2 mode
x=2. 2x1 mode
x=3. 2x1-2 mode
s tw mode x! x=4. 1x2 mode
x=5. 1x2-2 mode
x=6. 3x1 mode
x=7. 4x1 mode
x=8. 1x3 mode
x=9. 1x4 mode
r tw mode! Get tv wall display mode
Set tv wall horizontal bezel
s tw h bezel x!
(x=0~10,+,-)
r tw h bezel! Get tv wall row bezel
Set tv wall vertical bezel
s tw v bezel x!
(x=0~10,+,-)
r tw v bezel! Get tv wall vertical bezel
Set tv wall group y display
which source input (y=0~4,
x=1~4)
y=0. tv wall group all
y=1. tv wall group 1
s tw group y y=2. tv wall group 2
input x! y=3. tv wall group 3
y=4. tv wall group 4
x=1. hdmi input 1
x=2. hdmi input 2
x=3. hdmi input 3
x=4. hdmi input 4
Function Description Example Feedback
s output 1 in
output1->input1
source 1!
r output 1 in
output1->input1
source!
tv wall mode:
s tw mode 1!
2x2
tv wall mode:
r tw mode!
2x2
s tw h bezel tv wall horizontal
0! bezel: 0
tv wall horizontal
r tw h bezel!
bezel: 0
s tw v bezel tv wall vertical
0! bezel: 0
tv wall vertical
r tw v bezel!
bezel: 0
tv wall group 1
s tw group 1
input: hdmi input
input 1!
1
30 / 38
Default Setting
output1->input1
output2->input2
output3->input3
output4->input4
tv wall mode: 2x2
tv wall horizontal
bezel: 0
tv wall vertical
bezel: 0
tv wall group 1
input: hdmi input
1
