infobit iMatrix H44VAW User Manual page 29

Command Code
Output Setting
Set output y resolution
(y=0~4, x=1~16)
y=0. output all
y=1. output 1
y=2. output 2
y=3. output 3
y=4. output 4
1. 4096x2160p60,
2. 4096x2160p50,
3. 3840x2160p60,
4. 3840x2160p50,
s output y res x! 5. 3840x2160p30,
6. 1920x1080p60,
7. 1920x1080p50,
8. 1920x1080i60,
9.1920x1080i50,
10. 1920x1200p60rb,
11.1360x768p60,
12.1280x800p60,
13.1280x720p60,
14.1280x720p50,
15.1024x768p60,
16. auto
Set output y color
space(y=0~4, x=1~4)
y=0. output all
y=1. output 1
y=2. output 2
s output y csc x! y=3. output 3
y=4. output 4
x=1. rgb444
x=2. ycbcr444
x=3. ycbcr422
x=4. ycbcr420
Get output y color space
status.(y=0~4)
y=0. output all
r output y csc! y=1. output 1
y=2. output 2
y=3. output 3
y=4. output 4
Set output hdcp (y=0~4,
x=1~4)
y=0. output all
y=1. output 1
y=2. output 2
s output y hdcp x! y=3. output 3
y=4. output 4
x=1. hdcp 1.4
x=2. hdcp 2.2
x=3. follow sink
x=4. follow source
Function Description Example Feedback
s output output 1 resolution:
1 res 3! 3840x2160p60
s output
output 1 csc: rgb444 rgb444
1 csc 1!
r output 1
output 1 csc: rgb444
csc!
s output output 1 hdcp: hdcp
1 hdcp 1! 1.4
27 / 38
Default Setting
3840x2160p60
follow sink
