infobit iMatrix H44VAW User Manual page 35

Command Code
Multi-viewer Setting
Set user define windows
display mode (x=1~3)
s user x mode! 1. user 1 mode
2. user 2 mode
3. user 3 mode
Get user define windows
r user mode!
display mode
Set output audio source
(x=0~4)
0. follow window 1 selected
s mv output source
audio x! 1. input 1 audio
2. input 2 audio
3. input 3 audio
4. input 4 audio
r mv output
Get output audio source
audio!
Set multi-viewer resolution
(x=1~15)
1. 4096x2160p60,
2. 4096x2160p50,
3. 3840x2160p60,
4. 3840x2160p50,
5. 3840x2160p30,
6. 1920x1080p60,
s mv res x! 7. 1920x1080p50,
8. 1920x1080i60,
9.1920x1080i50,
10. 1920x1200p60rb,
11.1360x768p60,
12.1280x800p60,
13.1280x720p60,
14.1280x720p50,
15.1024x768p60
r mv res! Get multi-viewer resolution r mv res!
Embedded Audio Setting
Set input x audio
selected source hdmi or
embed analog audio
(x=0~4, z=0~1)
x=0. all input
s input x as z! x=1. input 1
x=2. input 2
x=3. input 3
x=4. input 4
z=0. hdmi original audio
z=1. embed analog audio
Function Description Example
s user 1 mode! user 1 mode
r user mode! user1 mode
output audio:
s mv output follow window 1
audio 0! selected source
s mv output output audio:
select input 1
audio 1!
audio
output audio:
r mv output
follow window 1
audio!
selected source
multi-viewer
s mv res 3!
resolution:
3840x2160p60
multi-viewer
resolution:
3840x2160p60
input 1 select
s input 1 as 1! hdmi original
audio
33 / 38
Feedback Default Setting
user 1 mode
output audio:
follow window 1
selected source
3840x2160p60
3840x2160p60
hdmi
original
audio
