5.3 LCD Display Navigation
The buttons on the the front panel are used for LCD display navigation, including
INPUT(1~4), OUTPUT(1~4), MATRIX, MULTIVIEWER, VIDEOWALL, MENU, ENTER,
UP, DOWN, POWER, LOCK.
Menu items are as follows:
Level 1
RESO
OUTPUT
CSC
STREAM
H MIRROR
V MIRROR
MODE
ASPECT
MV
PIP POSITION
PIP SIZE
Level 2
OUT1 / OUT2 / OUT3 / OUT4
OUT1 / OUT2 / OUT3 / OUT4
OUT1 / OUT2 / OUT3 / OUT4
OUT1 / OUT2 / OUT3 / OUT4
OUT1 / OUT2 / OUT3 / OUT4
SINGLE / PIP / DUAL /
TRIPLE-1 / TRIPLE-2 /
TRIPLE-3 / QUAD-1 /
QUAD-2 / QUAD-3 /
USER-1 / USER-2 / USER-3
FULL / 16:9
UPPER LEFT
LOWER LEFT
UPPER RIGHT
LOWER RIGHT
SMALL / MIDDLE /
LARGE
Level 3
4K×2K60W,
4K×2K50W,
4K×2K60,
4K×2K50,
4K×2K30,
1080P60,
1080P50,
1080i60,
1080i50,
WUXGA60_RB,
1360×768@60,
1280×800@60,
720P60,
720P50,
XGA60,
AUTO
RGB 444
YUV 444
YUV 422
YUV 420
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
5 / 38
Level 4
