infobit iMatrix H44VAW User Manual page 28

Function Description
Command Code
System Setting
r beep! Get buzzer state
Lock/unlock front panel
s lock z! button, z=0~1 (z=0 lock
off,z=1 lock on)
Get panel button lock
r lock!
state
Set lcd screen remain
on time, z=0~4 (0:off
s lcd on time z!
1:always, 2:15s, 3:30s,
4:60s)
Get the backlight status
r lcd mode!
of lcd screen
Set the logo name
s logo1 displayed on the first line
****************! of lcd screen,the max
character is 16
s reboot! Reboot the device
s reset! Reset to factory defaults
Output Setting
Set output display mode
(x=0~2)
s display mode
x=0 matrix mode
x!
x=1 video wall mode
x=2 multi-viewer mode
r display mode! Get output display mode
Get output y resolution
(y=0~4)
y=0. output all
r output y res! y=1. output 1
y=2. output 2
y=3. output 3
y=4. output 4
Example Feedback
r beep! beep on / beep off
panel button lock on
s lock 1!
panel button lock off
panel button lock on/
r lock!
off
s lcd on
lcd on 30 seconds
time 3!
r lcd
lcd always on
mode!
s logo1
logo1:Matrix Switch
Matrix
Switch!
reboot...
4x4 hdmi seamless
matrix
s reboot! system initializing...
initialization finished!
mcu fw version: x.xx.xx
web gui: x.xx.xx
reset to factory defaults
4x4 hdmi seamless
matrix
s reset! system initializing...
initialization finished!
mcu fw version: x.xx.xx
web gui: x.xx.xx
s display
display mode: matrix
mode 0!
r display
display mode: matrix
mode!
r output 1 output 1 resolution:
res! 3840x2160p60
26 / 38
Default Setting
panel button lock
off
lcd on 30
seconds
matrix
