infobit iMatrix H44VAW User Manual page 16

Select the Username and enter the password. The default password is:
Username User / Admin
Password user / admin
Click the Language drop-down list to select English or Simplified Chinese. Then click
the"LOGIN" button and the following Status page will appear.
■ Status Page
The Status page provides basic information about the Model, the installed firmware
version and the network settings of the device.
■ Input Page
You can do the following operations on the Input page:
① Input: Input channel of the device.
② Active: It indicates whether the channel is connected to a signal source. It is green
if connected, and gray if not connected.
③ Name: The input channel's name. You can modify it by entering the corresponding
name (max length: 31 characters) in the input box.
14 / 38
