Omcan 0920-HC Instruction Manual page 31

Model PT-Cn-1194-h
Item No. Description
AF092 Cabinet for 50050
AF093 Right Door for 50050
AB197 Gasket for 50050
AA955 Left/Right Spring Hinge for 50050
AA388 Axis Cover for 50050
AA360 Bottom Left Hinge for 50050
AF070 Upper Right Hinge for 50050
AF094 Left Door for 50050
AB197 Gasket for 50050
AA359 Bottom Right Hinge for 50050
AB200 Upper Left Hinge for 50050
AF142 Top Board for 50050
AF143 Cutting Board for 50050
AB253 Fixer for Cutting Board for 50050
AF144 Back Cover for 50050
AF145 Lid for 50050
AB256 Dowel for 50050
AB257 Plastic Bolt for 50050
AB258 Nut for 50050
50050
Position Item No. Description
1 AB259 Split Pin for 50050
2 AF099 Evaporator Cover for 50050
3 AF100 Inner Drain Pan for 50050
4 26955 Evaporator for 50050
5 AF146 Fan Motor Installation Panel for 50050
6 AF102 Left Clapboard of Evaporator for 50050
7 AF103 Right Clapboard of Evaporator for 50050
8 AA128 Condenser Fan Motor for 50050
9 AF080 Stand Off Bracket for 50050
10 AB320 Thermostat Installation Board for 50050
11 AA123 Carel Controller PYGX1Z0502 for 50050
12 AF140 Pan Bracket-15 for 50050
13 AF141 Pan Bracket-25 for 50050
14 AF104 Castor Support for 50050
15 26246 Caster with Brake for 50050
16 26247 Caster without Brake for 50050
17 AF105 Assembling Panel Support for 50050
18 AF085 Compressor Unit Track for 50050
Compressor Unit Installation Board for
19 AF106
50050
Parts breakdown
Position Item No.
20 AB213
21 AB049
22 AA208
23 AA207
24 AB595
25 AB594
26 AA874
27 AE915
28 AF089
29 AF090
30 26884
31 AB220
32 AF107
33 AB169
34 AA133
35 AA135
36 AA379
37 AA596
38
31
Description Position
Condenser for 50050 39
Condenser Fan Motor for 50050 40
Condenser Fan Blade for 50050 41
Condenser Fan Motor Cover for 50050 42
Filter Fixer for 50050 43
Filter D25x160-B for 50050 44
Outer Drain Pan for 50050 45
Compressor (T6217Z) for 50050 46
K Strip-2 Holes for 50050 51
K Strip-3 Holes for 50050 52
K Clip for 50050 53
Shelf for 50050 54
Back Grill for 50050 55
Foaming Hole Cover for 50050 56
Drain Hose for 50050 57
Power Cord for 50050 58
Temperature Probe for 50050 59
Thermometer for 50050 60
