Omcan 0920-HC Instruction Manual page 27

Model PT-Cn-0711-hC
Item No. Description
AF068 Cabinet for 50049
AF069 Door for 50049
AB250 Gasket for 50049
AA955 Left/Right Spring Hinge for 50049
AA388 Axis Cover for 50049
AA360 Bottom Left Hinge for 50049
AF070 Upper Right Hinge for 50049
AF135 Top Board for 50049
AF136 Cutting Board for 50049
AB253 Fixer for Cutting Board for 50049
AF137 Back Cover for 50049
AF138 Lid for 50049
AB256 Dowel for 50049
AB257 Plastic Bolt for 50049
AB258 Nut for 50049
AB259 Split Pin for 50049
AF075 Evaporator Cover for 50049
AF076 Inner Drain Pan for 50049
50049
Position Item No. Description
1 AA118 Evaporator for 50049
2 AF139 Fan Motor Installation Panel for 50049
3 AF078 Left Clapboard of Evaporator for 50049
4 AF079 Right Clapboard of Evaporator for 50049
5 AA128 Condenser Fan Motor for 50049
6 AF080 Stand Off Bracket for 50049
7 AB320 Thermostat Installation Board for 50049
8 AA123 Carel Controller PYGX1Z0502 for 50049
9 AF140 Pan Bracket-15 for 50049
10 AF141 Pan Bracket-25 for 50049
11 AF083 Castor Support for 50049
12 26246 Caster with Brake for 50049
13 26247 Caster without Brake for 50049
14 AF084 Assembling Panel Support for 50049
15 AF085 Compressor Unit Track for 50049
Compressor Unit Installation Board for
16 AF086
50049
17 AB159 Condenser for 50049
18 AF030 Evaporator Fan Motor for 50049
Parts breakdown
Position Item No.
19 AA208
20 AA207
21 AB595
22 AB594
23 AF087
24 AF088
25 AF089
26 AF090
27 26884
28 AB279
29 AF091
30 AB169
31 AA133
32 AA135
33 AA379
34 AA596
35
36
27
Description Position
Condenser Fan Blade for 50049 37
Condenser Fan Motor Cover for 50049 38
Filter Fixer for 50049 39
Filter D25x160-B for 50049 40
Outer Drain Pan for 50049 41
Compressor for 50049 42
K Strip-2 Holes for 50049 47
K Strip-3 Holes for 50049 48
K Clip for 50049 49
Shelf for 50049 50
Back Grill for 50049 51
Foaming Hole Cover for 50049 52
Drain Hose for 50049 53
Power Cord for 50049 54
Temperature Probe for 50049 55
Thermometer for 50049 56
