Omcan 0920-HC Instruction Manual page 25

Model PT-Cn-1778-hC
Item No. Description
AF123 Cabinet for 50048
AF093 Right Door for 50048
AB197 Gasket for 50048
AA955 Left/Right Spring Hinge for 50048
AA388 Axis Cover for 50048
AA360 Bottom Right Hinge for 50048
AF070 Upper Right Hinge for 50048
AF094 Left Door for 50048
AB363 Gasket 720x635mm for 50048
AA359 Bottom Right Hinge for 50048
AB200 Upper Left Hinge for 50048
AF124 Top Board for 50048
AF125 Cutting Board for 50048
AB253 Fixer for Cutting Board for 50048
AF126 Back Cover for 50048
AF127 Lid for 50048
AB256 Dowel for 50048
AB257 Plastic Bolt for 50048
AB258 Nut for 50048
AB259 Split Pin for 50048
50048
Position Item No. Description
1 AF128 Evaporator Cover for 50048
2 AF116 Inner Drain Pan for 50048
3 AA171 Evaporator for 50048
4 AF117 Fan Motor Installation Panel for 50048
5 AF129 Left Clapboard of Evaporator for 50048
6 AF130 Right Clapboard of Evaporator for 50048
7 AA128 Condenser Fan Motor for 50048
8 AF080 Stand Off Bracket for 50048
9 AB320 Thermostat Installation Board for 50048
10 AA124 Power Switch for 50048
11 AA123 Carel Controller PYGX1Z0502 for 50048
12 AF081 Pan Bracket-15 for 50048
13 AF082 Pan Bracket-25 for 50048
14 AF131 Pan Bracket-90 for 50048
15 AF132 Castor Support for 50048
16 26246 Caster with Brake for 50048
17 26247 Caster without Brake for 50048
18 AF133 Assembling Panel Support for 50048
19 AF085 Compressor Unit Track for 50048
Compressor Unit Installation Board for
20 AF106
50048
Parts breakdown
Position Item No.
21 AB213
22 AB049
23 AA208
24 AA207
25 AB595
26 AB594
27 AA874
28 26230
29 AF089
30 AF090
31 26884
32 AB460
33 AF134
34 AB169
35 AA133
36 AA135
37 AA379
38 AA596
39
40
25
Description Position
Condenser for 50048 41
Condenser Fan Motor for 50048 42
Condenser Fan Blade for 50048 43
Condenser Fan Motor Cover for 50048 44
Filter Fixer for 50048 45
Filter D25x160-B for 50048 46
Outer Drain Pan for 50048 47
Compressor - NLE10CN for 50048 48
K Strip-2 Holes for 50048 53
K Strip-3 Holes for 50048 54
K Clip for 50048 55
Shelf for 50048 56
Back Grill for 50048 57
Foaming Hole Cover for 50048 58
Drain Hose for 50048 59
Power Cord for 50048 60
Temperature Probe for 50048 61
Thermometer for 50048 62
