Omcan 0920-HC Instruction Manual page 21

Model PT-Cn-1194-hC
Item No. Description
AF092 Cabinet for 50046
AF093 Right Door for 50046
AB197 Gasket for 50046
AA955 Left/Right Spring Hinge for 50046
AA388 Axis Cover for 50046
AA360 Bottom Left Hinge for 50046
AF070 Upper Right Hinge for 50046
AF094 Left Door for 50046
AB197 Gasket for 50046
AA359 Bottom Right Hinge for 50046
AB200 Upper Left Hinge for 50046
AF095 Top Board for 50046
AF096 Cutting Board for 50046
AB253 Fixer for Cutting Board for 50046
AF097 Back Cover for 50046
AF098 Lid for 50046
AB256 Dowel for 50046
AB257 Plastic Bolt for 50046
AB258 Nut for 50046
50046
Position Item No. Description
1 AB259 Split Pin for 50046
2 AF099 Evaporator Cover for 50046
3 AF100 Inner Drain Pan for 50046
4 26955 Evaporator for 50046
5 AF101 Fan Motor Installation Panel for 50046
6 AF102 Left Clapboard of Evaporator for 50046
7 AF103 Right Clapboard of Evaporator for 50046
8 AA128 Condenser Fan Motor for 50046
9 AF080 Stand Off Bracket for 50046
10 AB320 Thermostat Installation Board for 50046
11 AA123 Carel Controller PYGX1Z0502 for 50046
12 AF081 Pan Bracket-15 for 50046
13 AF082 Pan Bracket-25 for 50046
14 AF104 Castor Support for 50046
15 26246 Caster with Brake for 50046
16 26247 Caster without Brake for 50046
17 AF105 Assembling Panel Support for 50046
18 AF085 Compressor Unit Track for 50046
Compressor Unit Installation Board for
19 AF106
50046
Parts breakdown
Position Item No.
20 AB213
21 AB049
22 AA208
23 AA207
24 AB595
25 AB594
26 AA874
27 AE915
28 AF089
29 AF090
30 26884
31 AB220
32 AF107
33 AB169
34 AA133
35 AA135
36 AA379
37 AA596
38
21
Description Position
Condenser for 50046 39
Condenser Fan Motor for 50046 40
Condenser Fan Blade for 50046 41
Condenser Fan Motor Cover for 50046 42
Filter Fixer for 50046 43
Filter D25x160-B for 50046 44
Outer Drain Pan for 50046 45
Compressor (T6217Z) for 50046 46
K Strip-2 Holes for 50046 51
K Strip-3 Holes for 50046 52
K Clip for 50046 53
Shelf for 50046 54
Back Grill for 50046 55
Foaming Hole Cover for 50046 56
Drain Hose for 50046 57
Power Cord for 50046 58
Temperature Probe for 50046 59
Thermometer for 50046 60
