Omcan 0920-HC Instruction Manual page 19

Model PT-Cn-0920-hC
Item No. Description
AO056 Cabinet for 50034
AO057 Right Door for 50034
AO058 Gasket for 50034
AI945 Spring Hinge Board for 50034
AA388 Axis Cover for 50034
AA360 Bottom Left Hinge for 50034
AF070 Upper Right Hinge for 50034
AO059 Left Door for 50034
61468 Left Bottom Hinge for 50034
AB200 Upper Left Hinge for 50034
AO060 Top Board for 50034
AO061 Cutting Board for 50034
AB253 Fixer for Cutting Board for 50034
AO062 Back Cover for 50034
AO063 Lid for 50034
AB256 Dowel for 50034
AB257 Plastic Bolt for 50034
AB258 Nut for 50034
AB259 Split Pin for 50034
50034
Position Item No. Description
1 AO064 Evaporator Cover for 50034
2 AF100 Inner Drain Pan for 50034
3, 9 26955 Evaporator for 50034
4 AF101 Fan Motor Installation Panel for 50034
5 AO065 Left Clapboard of Evaporator for 50034
6 AO066 Right Clapboard of Evaporator for 50034
7 AA128 Condenser Fan Motor for 50034
8 AF080 Stand Off Bracket for 50034
10 AB320 Thermostat Installation Board for 50034
11 AL929 Thermostat for 50034
12 AF081 Pan Bracket-15 for 50034
13 AF082 Pan Bracket-25 for 50034
14 AO067 Castor Support for 50034
15 26246 Caster with Brake for 50034
16 26247 Caster without Brake for 50034
17 AO068 Assembling Panel Support for 50034
18 AF085 Compressor Unit Track for 50034
Compressor Unit Installation Board for
19 AF086
50034
20 AB159 Condenser for 50034
Parts breakdown
Position Item No.
21 AL932
22 AI391
23 AL933
24 AB595
25 AI968
26 AF087
27 AF088
28 AL934
29 AF089
30 AF090
31 26884
32 AN875
33 AO069
34 AB169
35 AA133
36 AA135
37 AA379
38 AA596
39
19
Description Position
Condenser Fan Motor for 50034 40
Blade of Condenser Fan Motor for 50034 41
Condenser Fan Cover for 50034 42
Filter Fixer for 50034 43
Filter for 50034 44
Outer Drain Pan for 50034 45
Compressor for 50034 46
Compressor Starting Kit for 50034 47 - 50
K Strip-2 Holes for 50034 51
K Strip-3 Holes for 50034 52
K Clip for 50034 53
Shelf for 50034 54
Back Grill for 50034 55
Foaming Hole Cover for 50034 56
Drain Hose for 50034 57
Power Cord for 50034 58
Temperature Probe for 50034 59
Thermometer for 50034 60
