Table 5. Components – remote mount 575 volts (continued)
Kit Part
Number Mnemonic

Global Connector Harnesses

Figure 14. CAB01151 (39-inches) / CAB01153 (78-inches) global connector harness
CONNECTOR, DELPHI GT150,
4-PIN, MALE, TO CAB01149
OR CAB01150
Figure 15. CAB01155 (39-inches) / CAB01534 (78-inches) global connector harness
Figure 16. CAB01149 (39-inches) / CAB01150 (78-inches) global connector harness
CONNECTOR, DELPHI GT 150,
4-PIN, FEMALE, TO CAB01151
OR CAB01153
SO-SVN048A-EN
Part Number
NONE - UC800 Only for customers with existing UC800 controls
18800260100
18800270100 UC800/TD7 upgrade Kit without arm
507117990001 Optional AFD Drive Pedestal D1H Below 186 Amps
507118180001 Optional AFD Drive Pedestal D2H 186 Amps - 366 Amps
CONNECTOR, DELPHI GT150,
4-PIN, FEMALE, TO EXTENSION
CAB01149 OR CAB01150
Description
CONTROLS (one only)
UC800/TD7 upgrade Kit with arm
OPTIONAL PEDESTAL
CONNECTOR, DELPHI GT 150,
4-PIN, MALE, TO CAB01155 OR
Pre-Installation
QTY Package Label
Drive Mount hardware
1 - (label nuts and
screws only)
Drive Mount hardware
1 - (label nuts and
screws only)
CONNECTOR,
AMP,FEMALE,
TO UC800
ULTRASONIC
SOLIDIFIED END,
TO AFD
CAB01534
Serviceable
Component
23
